Exploded Views & Parts Lists - Generac Power Systems PM-DCP Owner's Manual

7
A B
1 1
2 2
14 1 0 1 0
1 8
J
ITEM PART NO.
1 0A6985
2 0A6388D
4 040213
5 0A6990
6 036901
7 0A6988
8 0A6733
10 061284
11 032300
12 044299
13 061286
14 065511
16 056892
17 025034
18 0E5620
19 022985
20 022155
21 022188
22 0F0168
23 0D4462
12 Generac ® Power Systems, Inc.
20-light Remote Annunciator
Assembly - Drawing No. 0F0169
8
E
C
1
1 2
2
3
1 0 11 1 3
12
QTY.
1
1
6
1
4
1
1
3
1
1
1
1
4
2
1
4
4
4
1
1
1
2 3
17
DESCRIPTION
PANEL ANNUNCIATOR REAR
ASSY, 20LT MODBUS ANNUN G-PNL
PCB SUPPORT SNAP-IN 1/4"
SUPPORT, PC BOARD
SCREW PPHM #6-32 X 3/8
PANEL ANNUNCIATOR FRONT
DECAL ANNUNCIATOR PANEL
SWITCH ROCKER SPST 10@125V SPD
HOLDER FUSE
FUSE 1A X AGC1
SOUNALERT, BUZZER
PLUG PANEL PLASTIC 1/2"
SCREW CRIMPTITE 10-24 X 3/8
PLUG STEEL 1.0625
HARNESS,10 WIRE REMOTE ANN
WASHER FLAT #6 ZINC
WASHER LOCK #6
NUT HEX #6-32 STEEL
DECAL MODEL NO. 04996-0
DECAL,WIRING,REMOTE ANNUNCIATOR
4
1 6
2
5
6 1 9 2 0 21
22
