OWNER'S /
OPERATOR'S
MANUAL
MODEL NO.'s
HPD-16 HSS/P
(S/N 4215 and above)
HPD-22Q HSS/P
(S/N 5501 and above)
HPD-26Q HSS/P
(S/N 1501 and above)
CAUTION
For Safe Operation
Read Rules And
Instructions Carefully
SI NO LEEINGLES, PIDA AYUDA
A AIGUIEN QUE SI LO LEA
PARA QUE LE TRADUZCA LAS
MEDIDAS DE SEGURIDAD.
THE FOLLOWING SAFETY PRECAUTIONS SHOULD BE THOROUGHLY UNDERSTOOD
1. Select an area for assembly that is clean and free of any
debris which might cause persons working on the
assembly to trip.
2. Do not lift heavy parts or assemblies. Use crane, jack,
tackle, fork trucks or other mechanical devices.
3. Preview the assembly instructions in your operator's
manual before proceeding further.
4. If the assembly instructions call for parts or assemblies to
be blocked up, use only blocking material that is in good
condition and is capable of handling the weight of the
assembly to be blocked. Also insure that the blocking
material is on a clean, dry surface.
5. Never put hands, or any part of body, under blocked up
assemblies if at all possible.
SKID STEER MOUNTED
HYDRAULIC POST DRIVERS
w/ Hydraulic Power Package
Safety Instructions
Tractor Preparation
Operating Instructions
CAUTION
BEFORE ATTEMPTING TO BEGIN ASSEMBLING THIS MACHINE
Assembly & Mounting
Maintenance
Repair Parts
6. After completing assembly, thoroughly inspect the
machine to be sure that all nuts, bolts, hydraulic fittings
or any other fastened assemblies have been thoroughly
tightened.
7. Before operating the machine, thoroughly read the
operation section of your operator's manual.
8. Before operating, read the maintenance section of your
operator's manual to be sure that any parts requiring
lubrication, such as gearboxes, are full, to avoid any
possible damage.
9. Before operating equipment – If you have any
questions regarding the proper assembly or
operation, contact your dealer or representative.
Advertisement
Table of Contents
Related Manuals for Worksaver HPD-16 HSS/P
Summary of Contents for Worksaver HPD-16 HSS/P
- Page 1 OWNER’S / OPERATOR’S MANUAL MODEL NO.’s HPD-16 HSS/P (S/N 4215 and above) HPD-22Q HSS/P (S/N 5501 and above) HPD-26Q HSS/P (S/N 1501 and above) SKID STEER MOUNTED CAUTION HYDRAULIC POST DRIVERS For Safe Operation w/ Hydraulic Power Package Read Rules And...
-
Page 2: Table Of Contents
Like all mechanical products, it will require cleaning and upkeep. Lubricate the Post Driver as specified. Use only genuine Worksaver, Inc. service parts. Substitute parts will void the warranty and may not meet stan- dards required for safe and satisfactory operation. Record the model and serial number of your Post Driver here: Model:________________________________________ Serial Number:_______________________________ RETAIL CUSTOMER’S RESPONSIBILITY... -
Page 3: Warranty
2. If the unit has been subjected to misapplication, abuse, misuse, negligence, fire or other accident. 3. If parts not made or supplied by Worksaver have been used in connection with the unit, if, in sole judge- ment of Worksaver such use affects its performance, stability, or reliability. -
Page 4: Safety Information
To the Owner/Operator/Dealer All implements with moving parts are potentially hazardous. There is no substitute for a cautious, safe-minded opera- tor who recognizes the potential hazards and follows reasonable safety practices. The manufacturer has designed this implement to be used with all its safety equipment properly attached to minimize the chance of accidents. BEFORE YOU START!! Read the safety messages on the implement and shown in your manual. - Page 5 SAFETY INSTRUCTIONS (continued) EQUIPMENT SAFETY GUIDELINES Safety of the operator is one of the main concerns in designing and developing a new piece of equipment. Designers and manufacturers build in as many safety features as possible. However, every year many accidents occur which could have been avoided by a few seconds of thought and a more careful approach to handling equipment.
- Page 6 SAFETY INSTRUCTIONS (continued) PREPARATION Never operate the power unit and post driver until you and the operator have read and completely understand this manual, the power unit operator’s manual, and each of the safety messages found on the safety signs on the power unit and post driver.
- Page 7 SAFETY INSTRUCTIONS (continued) OPERATIONAL SAFETY The use of this equipment is subject to certain hazards which cannot be protected against by mechanical means or product design. All operators of this equipment must read and understand this entire manual, pay- ing particular attention to safety and operating instructions, prior to using. If there is something in this manual you do not understand, ask your supervisor, or your dealer, to explain it to you.
- Page 8 SAFETY INSTRUCTIONS (continued) OPERATIONAL SAFETY (continued) Check that this attachment is securely mounted to the loader. Failure to install lock pins or have the latching mechanism engage could result in injury or death. Do not allow children or others to ride on the power unit with an operator. Riders are subject to injury such as being struck by foreign objects or being thrown off.
- Page 9 SAFETY INSTRUCTIONS (continued) TRANSPORT SAFETY Comply with state and local laws governing highway safety and movement of machinery on public roads. The use of flashing amber lights is acceptable in most localities. However, some localities prohibit their use. Local laws should be checked for all highway lighting and marking requirements. When driving the skid steer unit and equipment on the road or highway under 20 mph (32 kph) at night or during the day, use flashing amber warning lights and a slow moving vehicle (SMV) identification emblem.
- Page 10 SAFETY INSTRUCTIONS (continued) MAINTENANCE SAFETY Good maintenance is your responsibility. Poor maintenance is an invitation to trouble. Before working on this machine, drive to a level area, disengage the PTO, lower implement (or if working underneath, raise and block securely), shut off the engine, set the brakes, and remove the ignition keys. Remove hydraulic pressure prior to doing any maintenance.
- Page 11 SAFETY INSTRUCTIONS (continued) STORAGE SAFETY Following operation, or when unhooking, stop the power unit, set the brakes, lower ram to lowest position and engage transport lock pin, shut off the engine, relieve hydraulic pressure and remove the ignition keys. Store the unit in an area away from human activity. Do not park equipment where it will be exposed to livestock for long periods of time.
-
Page 12: Safety Signs
SAFETY SIGNS BE CAREFUL! Use a clean, damp cloth to clean safety decals. Avoid spraying to close to decals when using a pressure washer; high-pressure water can enter through very small scratches or under edges of decals causing them to peel or come off. Cylinder Locking Strap - Remove before using Post Driver 101202... -
Page 13: Safety Signs
SAFETY SIGNS NOTE: If Safety Sign is missing or damaged, replace immediately. 101358 REMEMBER: If Safety Signs have been damaged, removed, become illegible or parts replaced without Signs, new Safety Signs must be applied. New Safety Signs are available from your authorized distributor or factory. - Page 14 INSTRUCTIONS These instructions are for the models HPD-16 HSS/P, The hydraulic valve that operates the driving ram is a HPD-22Q HSS/P, and HPD-26Q HSS/P skid steer convertible valve and is shipped ready for OPEN center mounted hydraulic post drivers. hydraulic systems. Do not change this valve to a closed- center valve.
- Page 15 INSTRUCTIONS (continued) ASSEMBLY & MOUNTING allow the ram to lower (approximately 10 inches) and replace the transport lock pin. This should be done The following procedure is recommended for assem- with the Driver laying on the shipping pallet. The ram bling the Skid Steer Mounted Post Driver.
- Page 16 INSTRUCTIONS (continued) ASSEMBLY HYDRAULIC CONNECTIONS (continued) 5. Install the hydraulic package. Refer to Figure B for Check all hose and fitting connections. Make sure the correct location and orientation of components. hoses are not twisted or kinked and that they will not be pinched during operation of the post driver or the skid Some of the hydraulic fittings on the new post drivers steer unit.
- Page 17 INSTRUCTIONS (continued) ASSEMBLY LUBRICATION (continued) NOTE: Route the hoses to the skid steer so that they The Post Driver is designed with “SPECIAL” polyethylene will not be pinched or caught by the movement of the slide blocks for long, trouble-free operation. positioning mount •...
- Page 18 INSTRUCTIONS (continued) POST HOLDER MOUNTING Refer to page 28 and become familiar with the parts of the Post Holder and the description of parts. Locate the two holes in the left side of the support channel. These holes are directly opposite the valve mount bracket holes.
- Page 19 INSTRUCTIONS (continued) MODELS HSS ATTACHMENT TO PRIME MOVER —————————————————— WARNING Improper attachment of the post driver could result in injury or death. Do not operate this product until you have positive indication that the attachment is securely mounted. 1. Position the attachment on a level surface. Figure 3.
-
Page 20: Operating Instructions
OPERATING INSTRUCTIONS BEFORE YOU START OPERATION Review the assembly instructions to be sure the Driver Observe all operating and safety instructions in this is properly assembled and plumbed correctly for your manual and those on the Post Driver before using this machine. - Page 21 OPERATING INSTRUCTIONS (continued) OPERATION • When driving posts on a slope, always have the post (continued) driver facing uphill. • Only use a skid steer equipped with a ROPS cab or roll-over protective structure. CAUTION • Use particular care when working on inclines and hill- NEVER hold the post with your hand.
- Page 22 OWNER SERVICE STORING THE POST DRIVER MAINTENANCE AND ADJUSTMENTS Following operation, or when disconnecting the post driver, stop the skid steer unit, set the brakes, lower the WARNING loader, lower the driver ram to it’s lowest position and engage the transport lock pin. Install the two locking Before servicing the machine, engage the parking straps on the angle cylinders and make sure the adjustable legs are positioned correctly.
-
Page 23: Service Instructions
SERVICE INSTRUCTIONS (continued) MAINTENANCE AND NOTE: These instructions are for the HPD-16 Models ADJUSTMENTS (continued) only. RAM CONTROL HYDRAULIC VALVE The hydraulic ram control valve supplied with the Post Driver is “convertible” to accommodate both open-center FIG. G and closed-center hydraulic systems. The control valve is shipped “ready”... - Page 24 SERVICE INSTRUCTIONS (continued) MAINTENANCE AND 4. Lower the cylinder with the valve (Photo N). ADJUSTMENTS 5. Remove the step nut from the cylinder rod using the (continued) 1 1/2" wrench and the 5/8" wrench on the rod flats 3. Remove the hydraulic cylinder from the carriage. (Photo 0).
-
Page 25: Specifications
SERVICE INSTRUCTIONS (continued) QUICK-CHANGE SPRING REPLACEMENT – MAINTENANCE AND HPD-22Q and 26Q MODELS ADJUSTMENTS (continued) The Models HPD-22Q and HPD-26Q have the new SPRING REPLACEMENT – MODELS 16 ONLY longer lasting springs with the new Quick Change spring 1. Lower the driving ram so the springs are in their assembly mounting. -
Page 26: Trouble-Shooting
TROUBLE-SHOOTING GUIDE PROBLEM POSSIBLE CAUSE POSSIBLE REMEDY DRIVER DOES NOT 1. Quick-connect couplers not properly con- Hydraulic motor on post driver is designed to DRIVE A POST nected. turn in only one direction. Reverse hydraulic con- trol lever or switch hoses. 2. - Page 27 TROUBLE-SHOOTING GUIDE (continued) PROBLEM POSSIBLE CAUSE POSSIBLE REMEDY POST VEERS OFF AT 1. Top of post is not cut “square,” causing the Re-cut top of post “square.” AN ANGLE WHILE post to drive at an angle. BEING DRIVEN 2. Bottom of post is cut at an angle or post is Re-cut bottom of post.
-
Page 28: Trouble-Shooting
TROUBLE-SHOOTING GUIDE (continued) PROBLEM POSSIBLE CAUSE POSSIBLE REMEDY DRIVER RAM RAISES 1. Post driver control valve “UP” limit screw Adjust limit screw (see page 19). VERY FAST AND HITS needs adjusting. TOP URETHANE BUMPERS 2. Skid steer model has high volume Set throttle at lower speed to reduce volume of hydraulic oil pump. - Page 29 POST HOLDER ATTACHMENT PARTS DRAWING & LIST...
- Page 30 HPD-16 PARTS DRAWING HPD-16 Effective with S/N 4215...
- Page 31 HPD-16 PARTS LIST...
- Page 32 HPD-22Q PARTS DRAWING HPD-22Q Effective with S/N 5501...
- Page 33 HPD-22Q PARTS LIST...
- Page 34 HPD-26Q PARTS DRAWING HPD-26Q Effective with S/N 1501...
- Page 35 HPD-26Q PARTS LIST...
- Page 36 HYDRAULIC ADJUSTMENT SKID STEER MOUNT PARTS DRAWING...
-
Page 37: Parts Lists
HYDRAULIC ADJUSTMENT SKID STEER MOUNT PARTS LIST... - Page 38 HYDRAULIC POWER PACKAGE PARTS DRAWING (Skid Steer Application)
- Page 39 HYDRAULIC POWER PACKAGE PARTS LIST (Skid Steer Application)
- Page 40 HYDRAULIC CONTROL VALVE AND MOUNTING BRACKET PARTS DRAWING...
- Page 41 HYDRAULIC CONTROL VALVE AND MOUNTING BRACKET PARTS LIST...
- Page 42 SI NO LEEINGLES, PIDA AYUDA A HOLIDAY FROM ACCIDENTS A AIGUIEN QUE SI LO LEA PARA QUE LE TRADUZCA LAS MEDIDAS DE SEGURIDAD. MAY 2014 WORKSAVER, INC. P.O. BOX 100 LITCHFIELD, IL 62056-0100 (217) 324-5973 WEB: http:// www.worksaver.com E-MAIL: sales@worksaver.com WS-PH019-OG...
