OWNER'S /
OPERATOR'S
MANUAL
MODEL NO.'s
614HC
624HC
714HC
724HC
814HC
824HC
914HC
924HC
(#030800001 AND UP)
CAUTION
For Safe Operation
Read Rules And
Instructions Carefully
SI NO LEEINGLES, PIDA AYUDA
A AIGUIEN QUE SI LO LEA
PARA QUE LE TRADUZCA LAS
MEDIDAS DE SEGURIDAD.
THE FOLLOWING SAFETY PRECAUTIONS SHOULD BE THOROUGHLY UNDERSTOOD
1. Select an area for assembly that is clean and free of any
debris which might cause persons working on the
assembly to trip.
2. Do not lift heavy parts or assemblies. Use crane, jack,
tackle, fork trucks or other mechanical devices.
3. Preview the assembly instructions in your operator's
manual before proceeding further.
4. If the assembly instructions call for parts or assemblies to
be blocked up, use only blocking material that is in good
condition and is capable of handling the weight of the
assembly to be blocked. Also insure that the blocking
material is on a clean, dry surface.
5. Never put hands, or any part of body, under blocked up
assemblies if at all possible.
POST HOLE DIGGERS
Safety Instructions
Tractor Preparation
Operating Instructions
CAUTION
BEFORE ATTEMPTING TO BEGIN ASSEMBLING THIS MACHINE
614HC & 624HC
814HC & 824HC
HYDRAULIC
6. After completing assembly, thoroughly inspect the
machine to be sure that all nuts, bolts, hydraulic fittings
or any other fastened assemblies have been thoroughly
tightened.
7. Before operating the machine, thoroughly read the
operation section of your operator's manual.
8. Before operating, read the maintenance section of your
operator's manual to be sure that any parts requiring
lubrication, such as gearboxes, are full, to avoid any
possible damage.
9. Before operating equipment – If you have any
questions regarding the proper assembly or
operation, contact your dealer or representative.
714HC & 724HC
914HC & 924HC
Assembly & Mounting
Maintenance
Repair Parts
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Worksaver 614HC
Summary of Contents for Worksaver 614HC
- Page 1 OWNER’S / OPERATOR’S MANUAL MODEL NO.’s 614HC 614HC & 624HC 714HC & 724HC 624HC 714HC 724HC 814HC 824HC 914HC 924HC 814HC & 824HC 914HC & 924HC (#030800001 AND UP) CAUTION HYDRAULIC For Safe Operation POST HOLE DIGGERS Read Rules And...
-
Page 2: Table Of Contents
Like all mechanical products, it will require cleaning and upkeep. Lubricate the Digger as specified. Use only genuine Worksaver, Inc. service parts. Substitute parts will void the warranty and may not meet standards required for safe and satisfactory operation. Record the model and serial number of your Post Hole... -
Page 3: Warranty
3. If the unit has been subjected to misapplication, abuse, misuse, negligence, fire or other accident. 4. If parts not made or supplied by Worksaver have been used in connection with the unit, if, in sole judge- ment of Worksaver such use affects its performance, stability, or reliability. -
Page 4: Safety Information
To the Owner/Operator/Dealer All implements with moving parts are potentially hazardous. There is no substitute for a cautious, safe-minded opera- tor who recognizes the potential hazards and follows reasonable safety practices. The manufacturer has designed this implement to be used with all its safety equipment properly attached to minimize the chance of accidents. BEFORE YOU START!! Read the safety messages on the implement and shown in your manual. - Page 5 SAFETY INSTRUCTIONS (continued) EQUIPMENT SAFETY GUIDELINES Safety of the operator is one of the main concerns in designing and developing a new piece of equipment. Designers and manufacturers build in as many safety features as possible. However, every year many accidents occur which could have been avoided by a few seconds of thought and a more careful approach to handling equipment.
- Page 6 SAFETY INSTRUCTIONS (continued) SAFETY TRAINING Safety is a primary concern in the design and manufacture of our products. Unfortunately, our efforts to provide safe equipment can be wiped out by a single careless act of an operator. It is the operator’s respon- sibility to read and understand ALL Safety and Operating instructions in the manual and to follow these.
- Page 7 SAFETY INSTRUCTIONS (continued) OPERATIONAL SAFETY This Post Hole Digger was designed for one-man operation from the operator’s seat. It is the responsibility of the operator to see that no one is within twenty-five feet (25’) of the digger when it is started. Do not operate the digger with another person near, or in contact with, any part of the digger, PTO driveline, or auger.
- Page 8 SAFETY INSTRUCTIONS (continued) OPERATIONAL SAFETY (continued) Before you operate the digger, check over all pins, bolts and connections to be sure all are securely in place. Replace any damaged or worn parts immediately. Consult local utility companies to make certain there are no buried gas lines, electrical cables, etc., in the work area before beginning operation.
- Page 9 SAFETY INSTRUCTIONS (continued) OPERATIONAL SAFETY (continued) Operate loader from operator’s seat only. Remain at controls until operating cycle is complete. Stop loader gradually when lowering or lifting loads. Operate loader controls smoothly, avoid jerky operation. Allow for additional length of loader and attachment on power unit while turning. Be sure that people, livestock, or pets are not standing near the machine while operating.
- Page 10 SAFETY INSTRUCTIONS (continued) MAINTENANCE SAFETY Good maintenance is your responsibility. Poor maintenance is an invitation to trouble. Before working on this machine, drive to a level area, relieve hydraulic pressure, lower implement (or if work- ing underneath, raise and block securely), shut off the engine, set the brakes, and remove the ignition keys. Keep all persons away from operator control area while performing adjustments, service, or maintenance.
- Page 11 SAFETY INSTRUCTIONS (continued) TRANSPORT SAFETY Comply with state and local laws governing highway safety and movement of farm machinery on public roads. The use of flashing amber lights is acceptable in most localities. However, some localities prohibit their use. Local laws should be checked for all highway lighting and marking requirements. When driving equipment on the road or highway under 20 mph (32 kph) at night or during the day, use flash- ing amber warning lights and a slow moving vehicle (SMV) identification emblem.
-
Page 12: Safety Signs
SAFETY SIGNS LOCATED ON GEARBOX OUTPUT SHIELD LOCATED ON POST HOLE DIGGER BOOM OR FRAME... - Page 13 SAFETY SIGNS (continued) LOCATED AT TOP OF AUGER CENTER TUBE HOW TO INSTALL SAFETY SIGNS: Be sure that the installation area is clean and dry. Be sure temperature is above 50°F (10°C). Decide on the exact position before you remove the backing paper.
-
Page 14: Preparation Instructions
• The use of any loader attachment is NOT recom- mended on tractors with a tricycle wheel arrange- MODELS 614HC and 624HC are 3-pt. mounted post ment. Tricycle type tractors are unstable for front hole diggers that will fit most Category I and Category II loader use. - Page 15 With the gearbox in a level position, fill to the side inspection hole with a 3 PT. MODELS 614HC and 624HC good 90 wt. gear lubricant. Gearbox holds 86 fluid oz.
- Page 16 INSTRUCTIONS (continued) ASSEMBLY AND MOUNTING CAUTION CLAMP-ON MODELS 814HC and 824HC Do not operate this equipment without shields properly installed. This is for your protection, and the Check your loader to make sure it is in good working manufacturer recommends the use of these shields order.
- Page 17 MODEL 914HC and 924HC (continued) Bolt the steel plate counterweights to the counterweight bracket. The hoses and fittings are included on the Model 614HC and 624HC (3 pt. models). They are also included for the 914HC and 924HC models. With these models, the...
-
Page 18: Operating Instructions
OPERATING INSTRUCTIONS PREPARATION PROCEDURE IT IS ESSENTIAL THAT EVERYONE INVOLVED IN THE ASSEMBLY, OPERATION, TRANSPORT, MAIN- • Thoroughly read and understand your Operator’s TENANCE, AND STORAGE OF THIS EQUIPMENT BE Manuals. AWARE, CONCERNED, PRUDENT, AND PROPERLY TRAINED IN SAFETY. • Before beginning operation, clear area of objects that wrap around the auger or might be thrown. - Page 19 OPERATING INSTRUCTIONS (continued) OPERATION The Hydraulic Post Hole Digger is designed to operate (continued) in both forward and reverse rotation simply by reversing the oil flow. This works to the operator’s advantage when • Use particular care when working on inclines and hill- encountering a root or rock and the auger stalls.
- Page 20 OPERATING INSTRUCTIONS (continued) OPERATION (continued) CAUTION Underground utilities – Contact appropriate agencies to determine if hazardous items are buried WARNING under the digging site BEFORE DIGGING! Be certain underground utilities have been called to locate Remain on the power unit’s seat while operating the underground electric, gas, telephone, and other post hole digger.
-
Page 21: Owner Service / Specifications
SPECIFICATIONS ROUTINE MAINTENANCE MODELS 614HC, 714HC, 814HC and 914HC Low Volume Drive Motor DAILY CHECKS: Maximum Auger Diameter ..... 14”... -
Page 22: Trouble-Shooting Guide
TROUBLE-SHOOTING GUIDE PROBLEM: AUGER WILL NOT DIG PROBLEM: BENT AUGER FLIGHTING OR BENT AUGER Possible Solutions: Possible Solutions: • Teeth dull – sharpen or replace. • Power unit moved while auger was turning in hole – • Ground too dry and hard – order optional down force always set brakes on power unit and make sure it is kit, or wait until it rains. - Page 23 TROUBLE-SHOOTING GUIDE (continued) PROBLEM: 3 PT. POST HOLE DIGGER WON’T LIFT PROBLEM: GEARBOX FAILURE HIGH ENOUGH Possible Solutions: Possible Solution: • No oil in gearbox. • Tractor is a “low profile model” (one that is low to the • Oil not changed per instructions. ground).
- Page 24 AUGER TEETH MOUNTING PATTERNS HEAVY DUTY AUGER REPAIR PARTS (WITH THREADED CENTER POINT)
- Page 25 HEAVY DUTY AUGER REPAIR PARTS (WITH BOLT-IN CENTER POINT) NOTE: Auger Tooth Mounting Pattern same as shown on page 23.
-
Page 26: Parts Lists
HYDRAULIC GEARBOX PARTS LIST... - Page 27 614HC & 624HC PARTS LIST For Units Manufactured After S/N 030800001...
- Page 28 714HC & 724HC PARTS LIST For Units Manufactured After S/N 030800001...
- Page 29 814HC & 824HC PARTS LIST For Units Manufactured After S/N 030800001...
-
Page 30: Parts Lists
914HC & 924HC PARTS LIST For Units Manufactured After S/N 030800001... - Page 31 3. MODEL NUMBER 4. NAME OF ITEM 714HC 724HC 814HC MAKE EVERY DAY 824HC A HOLIDAY 914HC FROM ACCIDENTS! 924HC (#030800001 AND UP) APRIL 2014 WORKSAVER, INC. P.O. BOX 100 LITCHFIELD, IL 62056-0100 (217) 324-5973 WEB: http:// www.worksaver.com E-MAIL: sales@worksaver.com WS-PH018-OG...
