Contents Introduction Getting Started Overview Typical Applications Defining the TBUS-204 Pop-up Table Connection Bus Installing the TBUS-204 Cutting an Opening in the Table Inserting the TBUS-204 through the Cut-Out Opening Connecting the Cables Technical Specifications TBUS-204 - Introduction...
Kramer Electronics Ltd. Introduction Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been providing a world of unique, creative, and affordable solutions to the vast range of problems that confront the video, audio, presentation, and broadcasting professional on a daily basis. In recent years, we have...
European Advanced Recycling Network (EARN) and will cover any costs of treatment, recycling and recovery of waste Kramer Electronics branded equipment on arrival at the EARN facility. For details of Kramer’s recycling arrangements in your particular country go to our recycling pages at www.kramerav.com/support/recycling.
Kramer Electronics Ltd. Defining the TBUS-204 Pop-up Table Connection Bus This section defines the TBUS-204. Figure 1: Defining the Parts of the TBUS-204 Pop-up Table Connection Bus Feature Function Pop-up Lid Covers the connecting surface, leaving the table surface neat and tidy.
Page 6
When a single power socket is connected, consumption should not exceed 5A. When both power sockets are connected, the total consumption should not exceed 6A. 5V-2A USB Charging Port Use to charge a device. TBUS-204 - Defining the TBUS-204 Pop-up Table Connection Bus...
1. Before cutting the opening using the cut-out template, check the latest cut-out dimensions from the Kramer website at www.kramerav.com/downloads/TBUS-204. 2. Place the included cut-out template (that is included with your TBUS-204) on the surface of the table exactly where you want to install the TBUS-204.
If needed, you can download a full-scale template from the Kramer website at www.kramerav.com/downloads/TBUS-204. Take care not to damage the table. Kramer Electronics is not responsible for any damage caused to the table. Inserting the TBUS-204 through the Cut-Out Opening To insert and secure the TBUS-204, do the following: 1.
Make sure that when: • A single power socket is connected, consumption should not exceed 5A. • Both power sockets are connected, the total consumption should not exceed 6A. Figure 5: Connecting TBUS-204 TBUS-204 - Installing the TBUS-204...
(8.5" x 8.2" x 7.5") Net Weight 1.1kg (2.4lbs) approx. Net Weight with Mounting Brackets 1.4kg (3.1lbs) approx. Shipping Weight 1.7 kg (3.8lbs) approx. Accessories Included Clamp set, metal cut-out template Specifications are subject to change without notice at www.kramerav.com TBUS-204 - Technical Specifications...
Page 11
What Kramer Electronics Will Do Kramer Electronics will, at its sole option, provide one of the following three remedies to whatever extent it shall deem necessary to satisfy a proper claim under this limited warranty: Elect to repair or facilitate the repair of any defective parts within a reasonable period of time, free of any charge for the necessary parts and labor to complete the repair and restore this product to its proper operating condition.
Page 12
SAFETY WARNING Disconnect the unit from the power supply before opening and servicing For the latest information on our products and a list of Kramer distributors, visit our Web site where updates to this user manual may be found. We welcome your questions, comments, and feedback.
