- Page 1 USER MANUAL MODEL: KWC-1 Wireless Charging Spot P/N: 2900-300504 Rev 9 www.kramerAV.com...
-
Page 2: Table Of Contents
Introduction Getting Started Overview Defining KWC-1 Power Cord Options Installing KWC-1 Drilling a Hole in the Table Mounting KWC-1 in the Table Connecting Cables Using KWC-1 Using Wireless Charger Directly Using Wireless Charger with Receiver Technical Specifications KWC-1 – Contents... -
Page 3: Introduction
Kramer Electronics Ltd. Introduction Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been providing a world of unique, creative, and affordable solutions to the vast range of problems that confront video, audio, presentation, and broadcasting professionals on a daily basis. In recent years, we have... -
Page 4: Overview
If your mobile device does not support wireless charging, you can connect it to a Kramer wireless charging receiver (sold separately) and then place it on the charging spot. -
Page 5: Defining Kwc-1
Kramer Electronics Ltd. Defining KWC-1 This section defines KWC-1. Figure 1: KWC-1 Wireless Charging Spot Feature Function Outer Rim Fits over the table surface inserted into the table cutout. Charging Spot For mobile device wireless charging. Mounting Bracket For securing the unit to the table surface. -
Page 6: Power Cord Options
Kramer Electronics Ltd. Power Cord Options You can order any of the following power cords to use with a modular KWC-1: Power Cord Type Description 6ft/110V (North America) C-AC/US (110V) 91-000099 6ft/125V (Japan) C-AC/JP (125V) 91-000699 6ft/220V (Europe) C-AC/EU (220V) -
Page 7: Installing Kwc-1
The thickness of the table should be 3in (76mm) or less. 2. Clean the table surface. Take care not to damage the table. Kramer Electronics is not responsible for any damage caused to the table. Mounting KWC-1 in the Table To mount the unit: 1. -
Page 8: Connecting Cables
KWC-1 (f). Connecting Cables Connect KWC-1 to the power adapter and the power adapter to the mains electricity (the power cord is purchased separately, see Power Cord Options on page 4). KWC-1 – Installing KWC-1... -
Page 9: Using Kwc-1
You can charge only one mobile device at a time. To use the wireless charger directly: 1. Make sure that the charging spot power cable is connected. 2. Place it on the charging spot until it is fully charged. KWC-1 – Using KWC-1... -
Page 10: Using Wireless Charger With Receiver
Avoid using the receivers in extreme temperatures or high humidity. Kramer KWC-MUSB and KWC-LTN wireless charging receivers (sold separately) can be used with Kramer Wireless Charging (KWC) products for mobile devices that DO NOT have a built-in wireless charging receiver. -
Page 11: Technical Specifications
WEIGHT: Gross weight: 0.75kg (1.65lbs) approx. ACCESSORIES: Mounting bracket, power adapter, power adapter bracket OPTIONS: Wireless charging receivers, power cords (see Power Cord Options on page 4) Specifications are subject to change without notice at www.kramerav.com KWC-1 – Technical Specifications... - Page 12 Electronics products, this product must be insured during shipment, with the insurance and shipping charges prepaid by you. If this product is returned uninsured, you assume all risks of loss or damage during shipment. Kramer Electronics will not be responsible for any costs related to the removal or re- installation of this product from or into any installation.
- Page 13 SAFETY WARNING Disconnect the unit from the power supply before opening and servicing For the latest information on our products and a list of Kramer distributors, visit our Web site where updates to this user manual may be found. We welcome your questions, comments, and feedback.
