Contents General Information ....................3 Manufacturer .......................3 Information regarding the operating instructions ..........3 Further documents ....................3 Conformity with standards and regulations ............3 Explanation of the symbols .................4 Symbols in these operating instructions .............4 Warning notes .....................4 Symbols on the device ..................5 Safety notes ......................5 Operating instructions storage ................5 Safe use ......................5...
• Data sheet For documents in additional languages, see www.r-stahl.com. Conformity with standards and regulations See certificates and EC Declaration of Conformity: www.r-stahl.com. The device has IECEx approval. For certificate please refer to the IECEx homepage: http://iecex.iec.ch/ 224618 / FL6S60300010 GRP Flameproof Visual Signal - 5 Joule 2018-05-24·BA00·III·en·02...
Explanation of the symbols Explanation of the symbols Symbols in these operating instructions Symbol Meaning Tips and recommendations on the use of the device General danger Danger due to explosive atmosphere Danger due to energised parts = Strobe = Earth = Telephone initiate Warning notes Warnings must be observed under all circumstances, in order to minimize the risk due to...
Safety notes CAUTION Danger to persons Non-compliance with the instruction can result in light injuries to persons. NOTICE Avoiding material damage Non-compliance with the instruction can result in material damage to the device and / or its environment. Symbols on the device Symbol Meaning CE marking according to the current applicable directive.
Function and device design Modifications and alterations DANGER Explosion hazard due to modifications and alterations to the device! Non-compliance results in severe or fatal injuries. • Do not modify or alter the device. No liability or warranty for damage resulting from modifications and alterations.
Technical data Technical data Explosion Protection Global (IECEx) Gas and dust IECEx BAS 14.0064 IEC 60079-0: 2011 / IEC 60079-1: 2007 / IEC 60079-31: 2013 Ex d IIB T* Ta -** ... +** °C Gb Ex d IIC T* Ta -** ... +** °C Gb Ex tb IIIC T*** °C Ta -** ...
Mounting / Installation Connection 2.5 mm terminals For further technical data, see www.r-stahl.com. Transport and storage • Transport and store the device only in the original packaging. • Store the device in a dry place (no condensation) and vibration-free. • Do not drop the device.
Mounting and installation Mounting and installation Dimensions / fastening dimensions Dimensional Drawings (All Dimensions in mm [inches]) - Subject to Alterations 189 [7,44] 9 [ 0,35] 178,50 [7,03] Ø Ø [1,26] [3,74] 17149E00 16920E00 GRP Visual Signal Series FL6S GRP Visual Signal Series FL6S with L-Bracket without L-Bracket ø9 [...
Mounting and installation Mounting / dismounting, operating position DANGER Risk of explosion! Risk of injuries and material damage! • Terminal sleeves are fitted, they must be gas-tight and applied with a suitable tool. DANGER Explosion hazard! Risk of injuries and material damage! •...
Page 11
Mounting and installation 7.2.2 Installation with mounting bracket • Fix bracket to wall • Attach device 17161E00 17225E00 1 End cap 2 PCB Termination board 3 PCB and Xenon flash tube 4 Seal 5 Strobe flange 6 Cheese-head screws M5 x 25 17158E00 •...
Page 12
Mounting and installation 7.2.3 Reassembly of Enclosure • Lift strobe flange towards device. • Connect PCB using the plug. • Install strobe flange. • Replace cheese-head screws M5 x 25 (see information below) and tighten the screws with a tightening torque of 4 Nm. 7.2.4 Electrical Connection Key Components 1 Plug for flash PCB...
Page 13
Mounting and installation Cable Connection • The terminals accept wires of 2.5 mm or 14 to 18 AWG. Interconnection of devices parallel Up to 10 devices with common supplies may be connected as a single system loop. See wiring diagrams for further information. Circuit diagrams Line monitoring for devices with DC •...
Mounting and installation 7.2.5 Earth Connection 17191E00 Earth connection Use of metallic cable glands A slip on earth tag is provided with each device. This should be connected to the external earth stud detailed above. Device material The GRP material used for the device enclosure has electrically conductive properties. The material is antistatic and prevents build-up of electrical charges on its surface.
If an error occurs please re-visit the earlier sections of this document. If the error cannot be eliminated using the mentioned procedures: • Contact R. STAHL Schaltgeräte GmbH. For fast processing, have the following information ready: • Type and serial number •...
Maintenance and repair Maintenance and repair WARNING Risk of electric shock or malfunctioning of the device due to unauthorized work! Non-compliance can result in severe injuries and material damage. • Work performed on the device must only be carried out by appropriately authorized and qualified electricians.
• Only return or package the devices after consulting R. STAHL! Contact the responsible representative from R. STAHL. R. STAHL's customer service is available to handle returns if repair or service is required. • Contact customer service personally. • Go to the www.r-stahl.com website.
Malfunction or damage to the device due to the use of non-original components. Non-compliance can result in material damage. • Use only original accessories and spare parts from R. STAHL Schaltgeräte GmbH. For accessories and spare parts, see data sheet on our homepage www.r-stahl.com.
