NOMINAL SIZE
A (mm)
6lt x 6
6lt x 8
1929
6lt x 10
6lt x 12
NOMINAL SIZE
B (mm)
1990
2610
3230
10ft extension
3850
12ft extension
A (mm)
6ft extension
8ft extension
-
B (mm)
1860
2480
3100
3720

Advertisement

loading
Need help?

Need help?

Do you have a question about the 6' DWARF Lean-To and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Robinsons 6' DWARF Lean-To

Summary of Contents for Robinsons 6' DWARF Lean-To

  • Page 1 NOMINAL SIZE NOMINAL SIZE A (mm) B (mm) A (mm) B (mm) 6ft extension 6lt x 6 1990 1860 8ft extension 6lt x 8 2610 2480 1929 6lt x 10 3230 10ft extension 3100 6lt x 12 3850 12ft extension 3720...
  • Page 2 Thank you for purchasing your new Robinsons greenhouse. We recommend you familiarise yourself with the instructions and read all safety information before you commence assembly. This instruction manual is also available online at www.robinsonsgreenhouses.co.uk in our technical help section should you need to reprint it. Should you require any additional advice you can always call us on 01782 385409.
  • Page 3 They attach to the building during the glazing process (8) like a piece of glass with a black separator above and below them. LOUVRE Robinsons integral cantilever staging and shelving attaches to the inside of the greenhouse frame using either square head bolts (insert four into each side glazing bar ’D609’ during construction of the sides OPTIONAL (1)) or rectangular ‘crop head’...
  • Page 4 Section Section Part Section Size Part Section Size (mm) (mm) 1000 D043 1894 RUBBER (1m) D021 2514 D022 3134 D174 D023 3754 D975 1897 D974 2517 D976 1897 D979 3137 D973 2517 D978 3757 D981 3137 D604 1316 D977 3757 D609 1160 D962...
  • Page 5 Section Section Part Section Size Part Section Size (mm) (mm) D541 1915 D090 + D347 lock = D618 1144 1824 D301 D969 D971 D987 1370 D094 1824 D991 1260 D547 1915 1/2/3 D620 1144 D096 + D217 wheel = D814 1883 D307 D986...
  • Page 7 Feed glazing rubber into each glazing bar and PARTITION trim to length. Notice that some channels are ONLY REFER TO only used on a partition. Applying a lubricant to SEPARATE MANUAL the aluminium channels will speed up insertion. PARTITION ONLY REFER TO SEPARATE MANUAL...
  • Page 8 6 X 1 DWARF Part No Quantity D975 1897 D043 1894 D975 D609 1160 D604 1316 D174 10mm 15mm D043 Rubber 1000 8 X 1 DWARF Part No Quantity D974 2517 D021 2514 D974 D609 1160 D604 1316 D174 10mm 15mm D021 Rubber...
  • Page 9 D604 10mm D609 TRANSIT BOLT ON 15mm DIAGONALS D609 D604 15mm...
  • Page 10 Part No Quantity DOOR ON Part No Quantity DOOR ON Part No Quantity LEFT RIGHT D605(R) D174 D606(L) EXTERNAL EXTERNAL VIEW VIEW D608 1160 D608 1160 D227 D628 D628 M6X10 D632L D632R D950R 1915 D950L 1915 M6X15 D955 2037 D955 2037 M6NUT D956...
  • Page 11 D950R / D950R / D950R / D950L D950L D950L D955 / D956 D985 D608 D608 D174 D955 / D956 D605(R) / D606(L) D955 D955 D605(R) / D606(L) D628...
  • Page 12 Part No mm Quantity DOOR ON Part No Quantity DOOR ON Part No Quantity LEFT RIGHT D608 1160 D174 D608 1160 EXTERNAL EXTERNAL VIEW VIEW D950L 1915 D950R 1915 D227 D961 1894 D961 1894 M6X10 D962 1890 D962 1890 D985 1480 D985 1480...
  • Page 13 D950R / D950L D950R / D950L D985 D962 D950R / D608 D950L D992 / D993 D962 D992 / D993 D985 D608 D961 D961 D961...
  • Page 14 EQUAL...
  • Page 15 6’ 8’ 10’ 12’ Part No Quantity Part No mm Quantity Part No Quantity Part No Quantity D976 1897 D973 2517 D981 3137 D977 3757 D951 1915 D951 1915 D951 1915 D951 1915 D962 1890 D113 2510 D918 3130 D034 3750 RUBBER RUBBER...
  • Page 16 D234 D234 EQUAL...
  • Page 17 6x6 6x8 6x10 6x12 Part No Quantity SYSCR3 D119 SYRAWL No 10 x 3”...
  • Page 18 Part No mm Quantity Part No mm Quantity D220 D866 PLUS SCREW D205 D863L D863R BOLM6X11 SYNUTM6 D862 D1208 8 X 12 S/T 1 of - FS6017 610 x 610 8 x 19 S/T pane FS6018 D863R D863R D866 D863L D866 D1208 1 of -...
  • Page 19 D862 D863L D862 FLIP VIEW D119...
  • Page 20 Part No mm Quantity Part No mm Quantity D079 PLUS BOLM6X11 FLUFF D114 BOLM6X15 SYBOLM6 X11CROP SYNUTM6 D114 D079 D114 FLIP VIEW...
  • Page 21 D963 GLASS D964 GLASS D964 GLASS...
  • Page 22 Part No mm Q Part No mm Q D090 + D347 lock = D232 D301 1824 1 D233 D911 555 x 812 1824 1 P053 pane D094 D096 + D217 wheel = D225 D307 D912 4000 D840B 555 x 922 D095 pane D263...
  • Page 23 D911 555 x 812 pane D912 D232 555 x 922 pane D912 555 x 922 pane D307 D225 D097 D225 D840B D840B D840B P053...
  • Page 24 D972 D970 PART Section Size (mm) D971 D969 D541 1915 D618 1144 D969 D971 D987 1370 D991 1260 D547 1915 D619 D989 D836 D836 D620 1144 D986 D620 D814 D814 D814 1883 D986 1480 D544 1915 D619 1144 D836 1883 D970 D972 D988...
  • Page 25 ROOF PANES OVERLAP PART Size (mm) 6’ 8’ 10’ 12’ D1216 610 X 1162 D964 R 610 X 1312 D963 610 X 630 D1208 610 X 610 D911 555 X 812 D912 555 X 922 D965 ANGLE D966 ANGLE D967 ANGLE D968 ANGLE...
  • Page 26 D220 D220...
  • Page 27 D862 D079...
  • Page 28 Part No Part No D163 D864 D845 D084 1270 BOLM6X15 SYNUTM6 D083 1270 D845 D845 D955 D836 D956 D814 D163 D955 D845 D956...
  • Page 29 N/A 4 D084 D083 D864 N/A 4 D955 D163 D956 D864 D955 D956 D845...
  • Page 30 Part No D860 D087 D087 D860 D860 D087...
  • Page 31 Part No D842 D112 SYBOLM6 X11CROP D112 Part No Quantity FS6018 D312 D204L O4mm D204R through FS6018 metal only FS6018 D204R D312...
  • Page 32 O7mm...
  • Page 33 Part No Quantity D168L D168R (handle) D165 D166 FS6013 D166 D166 D168L D168R D165 D165 INTERNAL VIEW D729TG - 100 x 525 panes x 6 PINCH ALL GLASS RETAINERS BEFORE GLAZING D165...
  • Page 34 3 slat Example: 2x 4’ shelves ‘ST0304’ = 8’ run 10mm crop D2013 D608 15mm 10mm 10mm D609 D608 D2014 10mm crop D2002 =1240mm D2002 =1240mm D2014 D2021 D2003 =1860mm...
  • Page 35 7 slat Example: 2x 4’ staging ‘ST0704’ = 8’ run D608 D2045 D2043 D609 D608 10mm D2044 crop 10mm crop 10mm 10mm 10mm D2046 D2046 D2047 D2043 D2045 D2044 D2042 D2042 D2042 D2002 =1240mm 10mm 10mm D2002 =1240mm FINISH START D2003 =1860mm D2002...
  • Page 36 D214 D119 D201 D119 D208 D608 D211 D608 D202 D841 D119 D211 D207 D608...
  • Page 37 Part No Part No D522 D512 1210 D163 D150 2510 D845 D086 BOLM6X15 2510 SYNUTM6 D085 N/A 5 D150 D088 D086 D512 D085 D861 N/A 8 FS6018 D552 D512 D163 15mm D508 D508...
  • Page 38 Part No mm Q Part No mm Q D232 1824 1 D094 D233 D911 D090 + D347 lock = D301 D911 555 x 812 1824 1 P053 555 x 812 pane D092 + D156 strike = pane D303 1824 1 D225 1824 1 D093...
  • Page 39 D911 555 x 812 pane D912 D232 555 x 922 pane D912 555 x 922 pane D307 D225 D097 D225 D840B P053...
  • Page 40 I will make the necessary amendments. Whilst the information contained in this booklet is accurate at the time of publication, changes in the course of Robinsons policy of improvement through development and design might not be indicated. We point out this fact to avoid any infringements of the Trade Descriptions Act and also to advise that Robinsons Greenhouses reserve the right to change specifications and materials without prior notice.
