NOMINAL SIZE
A (mm)
8lt x 6
8lt x 8
2549
8lt x 10
8lt x 12
NOMINAL SIZE
B (mm)
1990
2610
3230
3850
A (mm)
6ft extension
-
B (mm)
1860

Advertisement

loading
Need help?

Need help?

Do you have a question about the 8 DWARF Lean-To and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Robinsons 8 DWARF Lean-To

Summary of Contents for Robinsons 8 DWARF Lean-To

  • Page 1 NOMINAL SIZE NOMINAL SIZE A (mm) B (mm) A (mm) B (mm) 8lt x 6 1990 6ft extension 1860 8lt x 8 2610 2549 8lt x 10 3230 8lt x 12 3850...
  • Page 2 Thank you for purchasing your new Robinsons greenhouse. We recommend you familiarise yourself with the instructions and read all safety information before you commence assembly. This instruction manual is also available online at www.robinsonsgreenhouses.co.uk in our technical help section should you need to reprint it. Should you require any additional advice you can always call us on 01782 385409.
  • Page 3 They attach to the building during the glazing process (9) like a piece of glass with a black separator above and below them. LOUVRE Robinsons integral cantilever staging and shelving attaches to the inside of the greenhouse frame using either square head bolts (insert four into each side glazing bar ’D609’ during construction of the sides OPTIONAL (1)) or rectangular ‘crop head’...
  • Page 4 Section Section Part Section Size Part Section Size (mm) (mm) D043 1894 D021 2514 D925 2545 D022 3134 D023 3754 1000 RUBBER (1m) D975 1897 D974 2517 D174 D979 3137 D976 1897 D978 3757 D973 2517 D604 1316 D981 3137 D609 1160 D977...
  • Page 5 Section Part Section Size Section Part Section Size (mm) (mm) D618 1144 D090 + D819 D347 lock = 1824 D821 D301 D929 2553 D969 D987 1370 D092 + D991 1260 D156 strike = 1824 D303 D986 1480 D999 1590 D610 1160 D093 1824...
  • Page 7 Feed glazing rubber into each glazing bar and PARTITION trim to length. Notice that some channels are ONLY REFER TO only used on a partition. Applying a lubricant to SEPARATE MANUAL the aluminium channels will speed up insertion. PARTITION ONLY REFER TO SEPARATE MANUAL...
  • Page 8 6 X 1 DWARF Part No Quantity D975 1897 D043 1894 D975 D609 1160 D604 1316 D174 10mm 15mm D043 Rubber 1000 8 X 1 DWARF Part No Quantity D974 2517 D021 2514 D974 D609 1160 D604 1316 D174 10mm 15mm D021 Rubber...
  • Page 9 D604 10mm D609 TRANSIT BOLT ON 15mm DIAGONALS D609 D604 15mm...
  • Page 10 Part No mm Quantity DOORS ON Part No Quantity DOORS ON Part No mm Quantity LEFT RIGHT D600 1270 D174 D600 1270 EXTERNAL EXTERNAL VIEW VIEW D604 1316 D604 1316 D227 D605(R) D606(L) M6X10 D608 1160 D608 1160 D632L D632R M6X15 D925 2545...
  • Page 11 D925 D925 D955 / D957 D608 D604 D608 D174 D605(R) / D925 D606(L) D997 D955 D955 / D957 D605(R) / D606(L) D600...
  • Page 12 Part No Quantity DOORS ON Part No Quantity DOORS ON Part No Quantity LEFT RIGHT D037 2510 D174 D037 2510 EXTERNAL EXTERNAL VIEW VIEW D113 2510 D113 2510 D227 D604 1316 D604 1316 M6X10 D608 1160 D608 1160 D925 2545 D925 2545 M6X15...
  • Page 13 D925 D925 D997 D113 D608 D604 D925 D113 D993 / D608 D997 D985 D037 D037 D037...
  • Page 14 EQUAL...
  • Page 15 6’ 8’ 10’ 12’ Part No Quantity Part No mm Quantity Part No mm Quantity Part No Quantity D976 1897 D973 2517 D981 3137 D977 3757 D927 2545 D927 2545 D927 2545 D927 2545 D593 1897 D594 2517 D595 3137 D596 3757 RUBBER...
  • Page 16 D234 D234 EQUAL...
  • Page 17 8x6 8x8 8x10 8x12 Part No Quantity SYSCR3 D119 SYRAWL No 10 x 3” There are various methods for attaching your greenhouse frame to its wall. Drill through the vertical wall bars with a 7mm drill/hammer drill using a 7mm masonry bit, Use 3” screws to secure the wall bars.
  • Page 18 Part No mm Quantity Part No mm Quantity D220 D866 PLUS FS6060 SCREW D863L D205 D863R BOLM6X11 SYNUTM6 D862 D1208 8 X 12 S/T 1 of - FS6017 610 x 610 8 x 19 S/T pane FS6018 D863R D863R D866 D863L D866 D1208...
  • Page 19 D862 D863L D862 FLIP VIEW D119...
  • Page 20 Part No mm Quantity Part No mm Quantity D079 PLUS BOLM6X11 FLUFF D114 BOLM6X15 SYBOLM6 X11CROP SYNUTM6 D114 D079 D114 FLIP VIEW...
  • Page 21 D963 GLASS D936 GLASS D936 GLASS...
  • Page 22 Part No mm Q Part No mm Q D232 1824 1 D094 D233 D911 D090 + D347 lock = D301 D911 1824 1 555 x 812 P053 555 x 812 pane D092 + D156 strike = pane D303 1824 1 D225 1824 1 D093...
  • Page 23 D911 555 x 812 pane D912 D232 555 x 922 pane D912 555 x 922 pane D307 D225 D097 D225 D840B P053...
  • Page 24 D831 PART Section Size D846 (mm) D970 D821 D618 1144 D819 D969 D819 D821 D929 2553 D969 D987 1370 D991 1260 D986 1480 D999 1590 D610 1160 D620 1144 D814 1883 D924 2553 D998 D614 D836 D836 D614 1162 D619 1144 D999 D610...
  • Page 25 ROOF PANES OVERLAP PART Size (mm) 6’ 8’ 10’ 12’ D1216 610 X 1162 D936 610 X 1945 D963 610 X 630 D1208 610 X 610 D911 555 X 812 D912 555 X 922 D937 ANGLE D966 ANGLE D967 ANGLE D968 ANGLE D965...
  • Page 26 D220 D220...
  • Page 27 D862 D079...
  • Page 28 Part No Part No D150 D865 1210 D163 D845 D086 2510 BOLM6X15 SYNUTM6 D085 25100 1 D845 D845 D955 D836 D957 D814 D163 D955 D845 D957...
  • Page 29 D150 D086 D085 D865 N/A 4 D955 D163 D957 D864 D955 D957 D845...
  • Page 30 Part No D861 D088 D088 D861 D861 D088 Please note that you will need to detach (three nuts and bolts) your upper door track assembly momentarily from the D864 header in order to slide on the door adjacent to the back wall.
  • Page 31 Part No D930 D223/B D819 D821 D969 D821 D831 D846 D930 D970 D937 D819 D831 D223 D968 D969 D846 D970 N/A 2 NOTCH DOWN Part No Quantity FS6018 D312 D204L O4mm D204R through FS6018 metal only FS6018 D204R D312...
  • Page 32 O7mm...
  • Page 33 Part No Quantity D168L D168R (handle) D165 D166 FS6013 D166 D166 D168L D168R D165 D165 INTERNAL VIEW D729TG - 100 x 525 panes x 6 PINCH ALL GLASS RETAINERS BEFORE GLAZING D165...
  • Page 34 3 slat Example: 2x 4’ shelves ‘ST0304’ = 8’ run 10mm crop D2013 D608 15mm 10mm 10mm D609 D608 D2014 10mm crop D2002 =1240mm D2002 =1240mm D2014 D2021 D2003 =1860mm...
  • Page 35 7 slat Example: 2x 4’ staging ‘ST0704’ = 8’ run D608 D2045 D2043 D609 D608 10mm D2044 crop 10mm crop 10mm 10mm 10mm D2046 D2046 D2047 D2043 D2044 D2045 D2042 D2042 D2042 D2002 =1240mm 10mm 10mm D2002 =1240mm FINISH START D2003 =1860mm D2002...
  • Page 36 D214 D119 D201 D119 D208 D608 D211 D608 D202 D841 D119 D211 D207 D608...
  • Page 37 Part No Part No D522 D512 1210 D163 D150 2510 D845 D086 BOLM6X15 2510 SYNUTM6 D085 N/A 5 D150 D088 D086 D512 D085 D861 N/A 8 FS6018 D522 D512 D163 15mm D508 D508...
  • Page 38 Part No mm Q Part No mm Q D232 1824 1 D094 D233 D911 D090 + D347 lock = D301 D911 555 x 812 1824 1 555 x 812 P053 pane D092 + D156 strike = pane D303 1824 1 D225 1824 1 D093...
  • Page 39 D911 555 x 812 pane D912 D232 555 x 922 pane D912 555 x 922 pane D307 D225 D097 D225 D840B P053...
  • Page 40 I will make the necessary amendments. Whilst the information contained in this booklet is accurate at the time of publication, changes in the course of Robinsons policy of improvement through development and design might not be indicated. We point out this fact to avoid any infringements of the Trade Descriptions Act and also to advise that Robinsons Greenhouses reserve the right to change specifications and materials without prior notice.
