Summary of Contents for Robinsons Extensions 6ft
- Page 1 NOMINAL SIZE (mm) 6ft extension 1860 8ft extension 2480...
-
Page 2: Key Description
WD40 or similar can be applied to the door wheels and lower door guides. Guarantee Your new Robinsons greenhouse is guaranteed for 10 years against faulty manufacture of the framework. This does not include glazing, mov- ing parts, accidental damage or wind damage. KEY DESCRIPTION... - Page 3 THE FOLLOWING DIMENSIONS ARE THE EXACT EXTERNAL BASE DIMENSIONS FOR THE ROBINSONS RANGE. We cannot emphasis how important it is to have a proper base for your Robinsons Greenhouse to be erected upon. It is essential that the BASE IS FLAT, LEVEL AND SQUARE AS WELL AS BEING SUBSTANTIAL enough to take the weight of the greenhouse including its 4mm glass.
- Page 4 FREE-STANDING ROBINSONS EXTENSIONS VERY IMPORTANT INFORMATION: If you have been supplied with an extension (i.e. your building is longer than 12’), your main building will differ in that the roof end and corner glazing bars (on the end to which the extension will be fitted) are replaced with standard side and roof glazing bars from the extension module kit. These should be fitted using 15mm bolts.
- Page 5 LEAN-TO ROBINSONS EXTENSIONS VERY IMPORTANT INFORMATION: If you have been supplied with an extension (i.e. your building is longer than 12’), your main building will differ in that the roof end and corner glazing bars (on the end to which the extension will be fitted) are replaced with standard side and roof glazing bars from the extension module kit. These should be fitted using 15mm bolts.
- Page 6 IMPORTANT: Extended buildings should have transparent all-weather silicone applied to the join between a standard ridge and an extension ridge/s to minimise leaks. This is often easier to do before glazing as access is easier. It is also advisable to repeat the process at gutter level on the gutter rear flanges though the gutter water channel itself is best sealed towards the end of con-...
- Page 7 D132 D133 D027 D134 D135 D004 D140 D136 D736 D137 D139 15mm D157 D138 FS6504 FS6006 D138 D132 D132 D133 D133 D134 D134 D140 D140 FS6006 D736 D736 D131 D673 FS6504 D784 15mm D132 D132 15mm D146 D158 D146 D158 D133 D133 D134...
- Page 8 D020 D010 D114 D028R D017R D158 D020 D010 D029R D024R D114 15mm D114 D126 D114 D028R D017R 15mm D158 15mm D029R D024R...
- Page 9 D114 D917 D962 D916R D114 D917 D919R D951 D114 15mm D114 15mm D114 D951 D916R D962 D114 D919R 15mm D126...
- Page 10 D114 D917 D962 D916R D114 D138 D982 D917 D919R D927 D114 15mm D114 FS6504 FS6006 15mm D114 D916R D927 D138 D962 D114 D919R 15mm D126 D982...
- Page 11 D170 (FOIL COVERED TAPE) D171 D119 D079 D114 A ‘D079’ slam bar can be attached to an A-frame using the standard ‘D114’ slam plate, pinching it between the roof bar and the roof A-frame reinforcing channel. D174 Or alternatively you can utilise some of the spare base brackets ‘D174’...
- Page 12 900mm up from bottom of base rail. Fitting Robinsons slatted shelving and staging using the instructions is usually quite straight forward. However if you have chosen a greenhouse which includes A-frames or a partition then fitting the staging becomes more complicated.
- Page 16 I will make the necessary amendments. Whilst the information contained in this booklet is accurate at the time of publication, changes in the course of Robinsons policy of improvement through development and design might not be indicated. We point out this fact to avoid any infringements of the Trade Descriptions Act and also to advise that Robinsons Greenhouses reserve the right to change specifications and materials without prior notice.
