where to Go for More information
For information about
How to configure the system
New features, enhancements, known issues, and late-breaking news
about your Data Domain software release
How to manage the Data Domain operating system
How to install and use the OpenStorage (OST) software and plug-in
How to replace Data Domain hardware components
How to use third-party applications
Specifications
System Heat Output
Model
Watts
DD660
575
ES20
450
Operating Temperature
Operating Humidity
Non-operating Temperature
Operating Acoustic Noise
Site requirements
Requirement
Vertical Space in Standard
19", Four Post Rack
Air Conditioning
Temperature Controls
Ventilation and Airflow
Front Bezel Clearance
Back Panel Clearance
Power / Grounding
contact information
tEcHnical contactS
To resolve issues with Data Domain products, contact your contracted support
provider or visit us online at https://my.datadomain.com.
Copyright © 2009 - 2010 EMC Corporation. All Rights Reserved.
EMC believes the information in this publication is accurate as of its publication date. The information is subject to change without notice.
THE INFORMATION IN THIS PUBLICATION IS PROVIDED "AS IS." EMC CORPORATION MAKES NO REPRESENTATIONS OR WARRANTIES
OF ANY KIND WITH RESPECT TO THE INFORMATION IN THIS PUBLICATION, AND SPECIFICALLY DISCLAIMS IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
Power (VA)
BTU/hr
100-120 / 200-240 V~
1962
1536
50° to 95° F (10° to 35° C)
20% to 80%, non-condensing
-40° to +149° F (-40° to +65° C)
DD660: Max 7.0 BA Sound Power at rear of unit when all drives seek simultaneously;
ES20: Max 58 dB LpA average measured at bystander positions
Description and Specification
DD660 Controller: 2U. ES20 Expansion Shelf: 3U.
Do not use a two-post rack. See the included slide rail and installation documentation instructions for installing in a rack.
Use air conditioning that can cope with the maximum BTU/hr thermal rating.
Use adequate temperature control with a gradient (change) not to exceed 30° C in an hour.
In a closed or multi-unit rack, ensure that the unit has adequate airflow through the front bezel and back panel and that the
ambient air temperature requirements are met. Ensure that the front bezel and back panel clearances are met. If installing in
a closed cabinet, ensure that the front and rear doors have at least 65% open area to ensure adequate airflow for cooling.
1.56 inches (4.0 cm) of unobstructed clearance.
5 inches (12.7 cm) of unobstructed clearance.
Two AC power outlets with an earth ground conductor (safety ground). A safe electrical earth connection must be provided
to each power cord. Voltage: 100-120 V~ or 200-240 V~. Frequency: 50 to 60 Hz.
Go to https://my.datadomain.com/US/en/documentation.jsp for
Initial Configuration Guide
Release Notes for your software release
DD OS Administration Guide for your software release
OpenStorage (OST) Administration Guide for your platform
Part Installation Guides
Integration Documentation and Compatibility Matrices
Weight
lb / kg
575
66 / 30
450
78 / 35.5
corPoratE contactS
2421 Mission College Blvd.
Santa Clara, CA 95054
866.WE.DDUPE (866.933.3873) or 408.980.4800
sales@datadomain.com
Use, copying, and distribution of any EMC software described in this publication requires an applicable software license.
EMC, Data Domain, and Global Compression are registered trademarks or trademarks of EMC Corporation in the United States and/or
other countries. All other trademarks used herein are the property of their respective owners.
761-0005-0004 Revision B
Rack Mounted Dimensions
WxDxH in (cm)
19 (48.3)
29.5 (74.9)
19 (48.3)
23.25 (59)
3.5 (8.9)
5.16 (13.1)
