where to Go for More information
For information about
How to configure the system
New features, enhancements, known issues, and late-breaking news
How to manage the Data Domain operating system
How to install and use the DD Boost software and plug-in
How to replace Data Domain hardware components
How to use third-party applications
How to configure mixed ES20 and ES30 systems
Specifications
Model
DD4500 with Extended Retention
ES30
Operating Temperature
Operating Humidity
Non-operating Temperature
Operating Acoustic Noise
Site requirements
Requirement
Vertical Space in Standard
19", Four Post Rack
Air Conditioning
Temperature Controls
Ventilation and Airflow
Front Bezel Clearance
Back Panel Clearance
Power / Grounding
contact information
tEcHnical contactS
To resolve issues with Data Domain products, contact your contracted support
provider or visit us online at https://my.datadomain.com.
Copyright © 2009 - 2013 EMC Corporation. All Rights Reserved.
EMC believes the information in this publication is accurate as of its publication date. The information is subject to change without notice.
THE INFORMATION IN THIS PUBLICATION IS PROVIDED "AS IS." EMC CORPORATION MAKES NO REPRESENTATIONS OR WARRANTIES
OF ANY KIND WITH RESPECT TO THE INFORMATION IN THIS PUBLICATION, AND SPECIFICALLY DISCLAIMS IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
System Heat Output
Watts
BTU/hr
800
2730
235
800
50° to 95° F (10° to 35° C), derate 1.1° C per 1000 feet, above 7500 feet up to 10,000 feet
20% to 80%, non-condensing
-40° to +149° F (-40° to +65° C)
DD4500: Sound power, L
: 7.52 bels. Sound pressure, L
WAd
Expansion Shelves: Sound power, L
Description and Specification
DD4500 with Extended Retention Software Controller: 4U. Expansion Shelf: 3U.
Do not use a two-post rack. See the included slide rail and installation documentation instructions for installing in a rack.
Use air conditioning that can cope with the maximum BTU/hr thermal rating.
Use adequate temperature control with a gradient (change) not to exceed 20° C in an hour.
In a closed or multi-unit rack, ensure that the unit has adequate airflow through the front bezel and back panel and that the
ambient air temperature requirements are met. Ensure that the front bezel and back panel clearances are met. Ensure that
cables at rear of unit do not obstruct exhaust airflow. If installing in a closed cabinet, ensure that the front and rear doors
have at least 65% open area to ensure adequate airflow for cooling.
1.56 inches (4.0 cm) of unobstructed clearance.
5 inches (12.7 cm) of unobstructed clearance.
AC power outlets provided with an earth ground conductor (safety ground). A safe electrical earth connection must be
provided to each power cord. Voltage: 200-240 V~. Frequency: 50 to 60 Hz.
Go to
https://my.datadomain.com/US/en/documentation.jsp
EMC Data Domain Operating System Initial Configuration Guide
EMC Data Domain Operating System Release Notes for your software release
EMC Data Domain Operating System Administration Guide for your software release
EMC Data Domain Boost for OpenStorage Administration Guide for your platform
Part Installation Guides
Integration Documentation and Compatibility Matrices
ES30 Hardware Guide
Power
(VA)
Weight
800
80 lb / 36.3 kg
280
68 lb / 30.8 kg
: 56.4 dB. (Declared noise emission per ISO 9296.)
pAm
: 6.5 bels, Sound pressure, L
WAd
corPoratE contactS
2421 Mission College Blvd.
Santa Clara, CA 95054
866.WE.DDUPE (866.933.3873) or 408.980.4800
sales@datadomain.com
Use, copying, and distribution of any EMC software described in this publication requires an applicable software license.
EMC, Data Domain, and Global Compression are registered trademarks or trademarks of EMC Corporation in the United States and/or
other countries. All other trademarks used herein are the property of their respective owners.
300-119-201 Rev. 02
Rack Mounted Dimensions
WxDxH
17.5 in / 44.5 cm
33 in / 84 cm
19 in / 48.3 cm
14 in / 35.5 cm
: 48.5 dB. (Declared noise emission per ISO 9296.)
pAm
for
7 in / 17.8 cm
5.25 in / 13.3 cm
