Where to Go for More Information
For information about
How to configure the system
New features, enhancements, known issues, and late-breaking news
about your Data Domain software release
How to manage the Data Domain operating system
How to install and use the DD Boost software and plug-in
How to replace Data Domain hardware components
How to use third-party applications
Specifications
Model
DD160 with 7 Disk Drives
DD160 with 12 Disk Drives
Operating Temperature
Operating Humidity
Non-operating Temperature
Operating Acoustic Noise
Site Requirements
Requirement
Vertical Space In Standard
19", Four Post Rack
Air Conditioning
Temperature Controls
Ventilation and Airflow
Front Bezel Clearance
Back Panel Clearance
Power / Grounding
System Heat Output
Watts
BTU/hr
311
1061
339
1157
50° to 95° F (10° to 35° C), derate 1.1° C per 1000 feet, above 7500 feet up to 10,000 feet
20% to 80%, non-condensing
-40° to +149° F (-40° to +65° C)
Max 7.9 Bel, Sound Power at 25° C when all drives seek simultaneously
DD160 Controller
2U. Do not use a two-post rack. See the included rail and installation documentation instructions to install in a rack.
Use air conditioning that can cope with the maximum BTU/hr thermal rating.
Use adequate temperature control with a gradient (change) not to exceed 30° C in an hour.
In a closed or multi-unit rack, ensure that the unit has adequate airflow through the front bezel and back panel and that the
ambient air temperature requirements are met. Ensure that the front bezel and back panel clearances are met. If installing in
a closed cabinet, ensure that the front and rear doors have at least 65% open area to ensure adequate airflow for cooling.
1.56 inch (4 cm) of unobstructed clearance.
5 inches (12.7 cm) of unobstructed clearance.
Two AC power outlets with an earth ground conductor (safety ground). A safe electrical earth connection must be provided
to each power cord. Voltage: 100-120 V~ or 200-240 V~. Frequency: 50 to 60 Hz.
Go to
https://support.emc.com
Initial Configuration Guide
Release Notes for your software release
EMC Data Domain Operating System Administration Guide
EMC Data Domain Boost for OpenStorage Administration Guide
Part Installation Guides
Integration Documentation and Compatibility Matrices
Power (VA)
Weight
100-120 / 200-240 V~
lb / kg
330
49 / 22.2
373
57 / 25.8
Rack Mounted Dimensions
WxDxH in (cm)
19 (48.3)
22 (55.9)
19 (48.3)
22 (55.9)
3.5 (8.9)
3.5 (8.9)
