7: Calibrating the
appropriate settings
automatically
(AUTO CALIBRATION)
This receiver is equipped with D.C.A.C.
(Digital Cinema Auto Calibration)
Technology which allows you to perform
automatic calibration as follows:
• Check the connection between each speaker
and the receiver.
• Adjust the speaker level.
• Measure the distance of each speaker to your
listening position.
You can also adjust the speaker levels and
balance manually. For details, see
"8: Adjusting the speaker levels and balance
(TEST TONE)" (page 33).
Before you perform Auto
Calibration
Before you perform the auto calibration, set up
and connect the speakers (page 15–17).
• The AUTO CAL MIC jack is used for the
supplied optimizer microphone only. Do not
connect other microphones to this jack.
Doing so may damage the receiver and the
microphone.
• During the calibration, the sound that comes
out of the speakers is very loud. Pay
attention to the presence of children or to the
effect on your neighborhood.
• Perform the auto calibration in a quiet
environment to avoid the effect of noise and
get a more accurate measurement.
• If there are any obstacles in the path between
the optimizer microphone and the speakers,
the calibration cannot be performed
correctly. Remove any obstacles from the
measurement area to avoid measurement
error.
30
US
?/1
MASTER VOLUME
MULTI CHANNEL DECODING
DISPLAY INPUT MODE
INPUT SELECTOR
SPEAKERS
(OFF/A/B/A+B)
AUTO CAL MIC
MEMORY/ TUNING
ENTER MODE TUNING 2CH A.F.D. MOVIE MUSIC
AUTO CAL
VIDEO 3 IN/PORTABLE AV IN
PHONES
VIDEO L AUDIO R
1
Connect the supplied optimizer
microphone to the AUTO CAL
MIC jack on the front panel.
2
Set up the optimizer
microphone.
Place the optimizer microphone at your
listening position. Use a stool or tripod so
that the optimizer microphone remains at
the same height as your ears.
Tip
When you face the speaker towards the optimizer
microphone, you will get a more accurate
measurement.
Optimizer microphone
MUTING
