KIRLOSKAR Non-Clog Submersible Series Instructions On Installation, Operation And Maintenance Manual

KIRLOSKAR Non-Clog Submersible Series Instructions On Installation, Operation And Maintenance Manual

Hide thumbs

Advertisement

Table of Contents

1
This is a proprietary document of Kirloskar Brothers Limited, YAMUNA' Survey No. 98/ 3 to 7, Baner, Pune – 411045, India.
1 Sept 2018
NS IOM MANUAL

Advertisement

Table of Contents
loading

Related Manuals for KIRLOSKAR Non-Clog Submersible Series

Summary of Contents for KIRLOSKAR Non-Clog Submersible Series

  • Page 1 This is a proprietary document of Kirloskar Brothers Limited, YAMUNA’ Survey No. 98/ 3 to 7, Baner, Pune – 411045, India. 1 Sept 2018 NS IOM MANUAL...
  • Page 2 This warranty holds good only for the products manufactured by us. – KIRLOSKAR BROTHERS LIMITED – This is a proprietary document of Kirloskar Brothers Limited, YAMUNA’ Survey No. 98/ 3 to 7, Baner, Pune – 411045, India. 1 Sept 2018...
  • Page 3 DO NOT MEGGER CONTROL CABLE OF THE PUMP WITHOUT DISCONNECTING FROM THE CONTROL PANEL. This is a proprietary document of Kirloskar Brothers Limited, YAMUNA’ Survey No. 98/ 3 to 7, Baner, Pune – 411045, India. 1 Sept 2018 NS IOM MANUAL...

  • Page 4: Table Of Contents

    • Please furnish complete nameplate details, name of parts, part nos. and material of construction while ordering spare parts for the pump This is a proprietary document of Kirloskar Brothers Limited, YAMUNA’ Survey No. 98/ 3 to 7, Baner, Pune – 411045, India. 1 Sept 2018...

  • Page 5: General

    #-yet to develop. How to read – NS20/13QT 1.1/2 i (i-stands for iNS) This is a proprietary document of Kirloskar Brothers Limited, YAMUNA’ Survey No. 98/ 3 to 7, Baner, Pune – 411045, India. 1 Sept 2018 NS IOM MANUAL...
  • Page 6 80/40 100/40 150/40 200/40 250/40 150/50 250/34 How to read – NS150/26Q 30/4 This is a proprietary document of Kirloskar Brothers Limited, YAMUNA’ Survey No. 98/ 3 to 7, Baner, Pune – 411045, India. 1 Sept 2018 NS IOM MANUAL...
  • Page 7 Figure (1) & (2). This is a proprietary document of Kirloskar Brothers Limited, YAMUNA’ Survey No. 98/ 3 to 7, Baner, Pune – 411045, India. 1 Sept 2018...

  • Page 8: Safety Instructions

    This symbol refers to electrical This symbol refers safety. magnetic field safety. This is a proprietary document of Kirloskar Brothers Limited, YAMUNA’ Survey No. 98/ 3 to 7, Baner, Pune – 411045, India. 1 Sept 2018 NS IOM MANUAL...

  • Page 9: Installation

    & rubber diaphragm to make it leak proof joint. This is a proprietary document of Kirloskar Brothers Limited, YAMUNA’ Survey No. 98/ 3 to 7, Baner, Pune – 411045, India. 1 Sept 2018...
  • Page 10 7.6. and chain capacity as per chart in 3.4. We recommend use of non-return valve in delivery pipe line located before sluice valve. This is a proprietary document of Kirloskar Brothers Limited, YAMUNA’ Survey No. 98/ 3 to 7, Baner, Pune – 411045, India. 1 Sept 2018...

  • Page 11: Operation

    4.1.4 Before starting the pump, check the direction of rotation is as outlined below. This is a proprietary document of Kirloskar Brothers Limited, YAMUNA’ Survey No. 98/ 3 to 7, Baner, Pune – 411045, India. 1 Sept 2018 NS IOM MANUAL...

  • Page 12: Maintenance

    The effect of liquid handled on pump components should be checked. If abnormal corrosion, erosion is observed then the components should be replaced with that of suitable material. This is a proprietary document of Kirloskar Brothers Limited, YAMUNA’ Survey No. 98/ 3 to 7, Baner, Pune – 411045, India. 1 Sept 2018...

  • Page 13: Shut Down / Storage / Preservation

    Condition: a. store in cool, dry place with temperature below 15 degree Celsius. This is a proprietary document of Kirloskar Brothers Limited, YAMUNA’ Survey No. 98/ 3 to 7, Baner, Pune – 411045, India. 1 Sept 2018 NS IOM MANUAL...

  • Page 14: Technical Data

    3C X 50 3C X 70 295/22 3C X 95 355/22 3C X 120 414/22 This is a proprietary document of Kirloskar Brothers Limited, YAMUNA’ Survey No. 98/ 3 to 7, Baner, Pune – 411045, India. 1 Sept 2018 NS IOM MANUAL...

  • Page 15: Mechanical Seals

    18.5 3 Litre NS150/26QT 3 Litre NS100/26QT 3 Litre NS150/32N 18.5 4 Litre This is a proprietary document of Kirloskar Brothers Limited, YAMUNA’ Survey No. 98/ 3 to 7, Baner, Pune – 411045, India. 1 Sept 2018 NS IOM MANUAL...
  • Page 16 3 Litre NS50/36QM 4 Litre NS80/26QM 3 Litre NS65/32NB 4 Litre NS80/26QM 3 Litre This is a proprietary document of Kirloskar Brothers Limited, YAMUNA’ Survey No. 98/ 3 to 7, Baner, Pune – 411045, India. 1 Sept 2018 NS IOM MANUAL...
  • Page 17 NS50/26QMB 3 Litre NOTE: change oil after every 5000 hrs of pump operation. This is a proprietary document of Kirloskar Brothers Limited, YAMUNA’ Survey No. 98/ 3 to 7, Baner, Pune – 411045, India. 1 Sept 2018 NS IOM MANUAL...

  • Page 18: Overhauling

    51100 52301 35000 15300 10700 46500 52304 32000 62100 34100 33000 38300 SUC. This is a proprietary document of Kirloskar Brothers Limited, YAMUNA’ Survey No. 98/ 3 to 7, Baner, Pune – 411045, India. 1 Sept 2018 NS IOM MANUAL...
  • Page 19 9.3 (UNIT 2,3,4,5,6- iNS with QT Type Impeller and DOL type of starting) 9.4 (UNIT 2,3,4,5,6- iNS with Q Type Impeller and SDS type of starting) This is a proprietary document of Kirloskar Brothers Limited, YAMUNA’ Survey No. 98/ 3 to 7, Baner, Pune – 411045, India. 1 Sept 2018...
  • Page 20 9.5 CROSS SECTIONAL VIEW OF NS PUMP CROSS SECTIONAL VIEW OF NS PUMP QT TYPE IMPELLER UNIT I (DOL) This is a proprietary document of Kirloskar Brothers Limited, YAMUNA’ Survey No. 98/ 3 to 7, Baner, Pune – 411045, India. 1 Sept 2018...
  • Page 21 CROSS SECTIONAL VIEW OF NS PUMP N TYPE IMPELLER UNIT II (SDS) CROSS SECTIONAL VIEW OF NS PUMP UNIT III – N TYPE IMPELLER (SDS) This is a proprietary document of Kirloskar Brothers Limited, YAMUNA’ Survey No. 98/ 3 to 7, Baner, Pune – 411045, India. 1 Sept 2018...
  • Page 22 CROSS SECTIONAL VIEW OF NS PUMP UNIT III – Q TYPE IMPELLER (SDS) 9.10 CROSS SECTIONAL VIEW OF NS PUMP UNIT IV & ABOVE (SDS) This is a proprietary document of Kirloskar Brothers Limited, YAMUNA’ Survey No. 98/ 3 to 7, Baner, Pune – 411045, India. 1 Sept 2018 NS IOM MANUAL...
  • Page 23 STUD FOR BUSH AND MOT END COVER-SDS * Marked part code nos. are recommended spares. This is a proprietary document of Kirloskar Brothers Limited, YAMUNA’ Survey No. 98/ 3 to 7, Baner, Pune – 411045, India. 1 Sept 2018 NS IOM MANUAL...

  • Page 24: Outline Drawing And Dimensions Sheet

    PLUG DEL. SUC. ØH FRONT VIEW PLAN Pump UNIT NS20/13QT NS20/13QT NS32/13QT NS40/13QT This is a proprietary document of Kirloskar Brothers Limited, YAMUNA’ Survey No. 98/ 3 to 7, Baner, Pune – 411045, India. 1 Sept 2018 NS IOM MANUAL...
  • Page 25 1085 160 265 245 500 500 750 NS65/32QT 1070 158 250 275 540 540 750 This is a proprietary document of Kirloskar Brothers Limited, YAMUNA’ Survey No. 98/ 3 to 7, Baner, Pune – 411045, India. 1 Sept 2018 NS IOM MANUAL...
  • Page 26 1095 150 265 230 245 460 460 750 NS80/26Q 1095 150 265 230 245 460 460 750 This is a proprietary document of Kirloskar Brothers Limited, YAMUNA’ Survey No. 98/ 3 to 7, Baner, Pune – 411045, India. 1 Sept 2018 NS IOM MANUAL...
  • Page 27 10.3 (Unit 1&2- Q, N type Impeller NS) This is a proprietary document of Kirloskar Brothers Limited, YAMUNA’ Survey No. 98/ 3 to 7, Baner, Pune – 411045, India. 1 Sept 2018 NS IOM MANUAL...
  • Page 28 10.4 (Unit 3 & 4 - Q, N type Impeller iNS) This is a proprietary document of Kirloskar Brothers Limited, YAMUNA’ Survey No. 98/ 3 to 7, Baner, Pune – 411045, India. 1 Sept 2018 NS IOM MANUAL...
  • Page 29 610 130 350 285 143 264 150 170 250 550 370 115 19 200 450 160 320 570 100 100 50 250 43 150 200 23 200 38 This is a proprietary document of Kirloskar Brothers Limited, YAMUNA’ Survey No. 98/ 3 to 7, Baner, Pune – 411045, India.
  • Page 30 OIL FILLING PLUG G.L. G.L. FRONT VIEW PLAN OF PUMP AND CONNECTOR UNIT ONLY This is a proprietary document of Kirloskar Brothers Limited, YAMUNA’ Survey No. 98/ 3 to 7, Baner, Pune – 411045, India. 1 Sept 2018 NS IOM MANUAL...
  • Page 31 220 470 205 410 660 100 100 50 250 43 200 250 23 200 100 140 16 250 This is a proprietary document of Kirloskar Brothers Limited, YAMUNA’ Survey No. 98/ 3 to 7, Baner, Pune – 411045, India. 1 Sept 2018...
  • Page 32 11.3 NS stationary installation unit 1 & 2 This is a proprietary document of Kirloskar Brothers Limited, YAMUNA’ Survey No. 98/ 3 to 7, Baner, Pune – 411045, India. 1 Sept 2018 NS IOM MANUAL...
  • Page 33 11.4 NS stationary installation unit 3 & 4 This is a proprietary document of Kirloskar Brothers Limited, YAMUNA’ Survey No. 98/ 3 to 7, Baner, Pune – 411045, India. 1 Sept 2018 NS IOM MANUAL...
  • Page 34 11.5 NS stationary installation unit 5 & Above This is a proprietary document of Kirloskar Brothers Limited, YAMUNA’ Survey No. 98/ 3 to 7, Baner, Pune – 411045, India. 1 Sept 2018 NS IOM MANUAL...

  • Page 35: Annexure: Control Panel / Pmu Specifications

    Continuous Class of insulation: Ingress Protection IP 54 *Special panels available against request This is a proprietary document of Kirloskar Brothers Limited, YAMUNA’ Survey No. 98/ 3 to 7, Baner, Pune – 411045, India. 1 Sept 2018 NS IOM MANUAL...

  • Page 36: Spare Parts

    This is a proprietary document of Kirloskar Brothers Limited, YAMUNA’ Survey No. 98/ 3 to 7, Baner, Pune – 411045, India. 1 Sept 2018...
  • Page 37 Authorized Dealer/Authorized Service Dealers who in turn shall communicate the same to Zonal Customer Support Service representative. This is a proprietary document of Kirloskar Brothers Limited, YAMUNA’ Survey No. 98/ 3 to 7, Baner, Pune – 411045, India. 1 Sept 2018...

This manual is also suitable for:

Ns100/26qNs150/26nmNs150/26qNs100/26nNs150/26qmbNs150/26qm ... Show all

Table of Contents
