Rosemount Manifolds
Table 3. Rosemount 306 Pressure Manifold Ordering Information
★ The Standard offering represents the most common options. The starred options (★) should be selected for best delivery.
The Expanded offering is subject to additional delivery lead time.
Material recommendations for NACE
SG
Sour gas (meets NACE MR0175/ISO 15156, MR0103/ISO 17495)
Typical integral manifold model number: 306 R T 2 2 BA 1 1
1.
Only available with 316 SST materials of construction and graphite-based packing.
2.
Not available with block-and-bleed manifold type
3.
Materials of Construction comply with recommendations per NACE MR0175/ISO 15156 for sour oil field production environments. Environmental limits apply to certain
materials. Consult latest standard for details. Selected materials also conform to NACE MR0103/ISO 17495 for sour refining environments.
4.
Includes PTFE tape on drain/vent valves and plugs.
5.
Includes graphite tape on plugs.
6.
Not available with graphite-based packing material code 2.
7.
Only allowed with material of construction code 2.
8
(3)(7)
August 2016
EmersonProcess.com/Rosemount
★
