Rosemount Manifolds

Dimensional drawings

Rosemount 305 Manifold
Figure 7. Rosemount 305RC 2-Valve Coplanar Style Manifold
4.20
(107)
7.72
(196)
8.97
(228)
4.00
(102)
max open
1
A. / –14 NPT on manifold for process connection,
2
Note: Manifold handle assembly may vary slightly from image shown. All valve handle assemblies provide the same function and meet all stated drawing
dimensions.
Dimensions are in inches (millimeters).
Figure 8. Rosemount 305RC 3-Valve Coplanar Style Manifolds
4.20
(107)
7.72
(196)
8.97
(228)
5.00
(127)
max open
A. Drain/vent valve
1
B. / –14 NPT on manifold for process connections, 2
2
Note: Manifold handle assembly may vary slightly from image shown. All valve handle assemblies provide the same function and meet all stated drawing
dimensions.
Dimensions are in inches (millimeters).
18
4.51
(115)
7.20
(183)
A max open
1
/ –18 NPT for test/vent connection
4
4.51
(115)
A
9.20
(234)
B
max open
1
/ -in. center-to-center
8
5.17
(131)
5.17
(131)
August 2016
