Rosemount Manifolds
Figure 3. Rosemount 304 Conventional Manifolds
Table 7. Rosemount 304 Conventional Manifolds
Packing
PTFE
Graphite - wafer
Graphite - flanged (SST)
Graphite - flanged (CS)
Graphite (ASME B31.1)
(1)
PTFE
(1)
FKM O-ring
1.
Maximum working pressure limited to 1500 psi with G2 option.
Instrument connections
Table 8. Manifold - Transmitter Interface
Model
Rosemount 305 Integral Manifold
Rosemount 306 In-line Manifold
Rosemount 304 Conventional
Manifold
14
Seat
Integral
Integral
Integral
Integral
Integral
POM
POM
Connection
Mounted directly to coplanar sensor module of transmitter, 1.3-in. (287 mm) center-to-center
process isolators
1
/
–14 male NPT for In-line transmitters
2
Mounted to traditional transmitter flange, 2
61518, Type B shut-off device (without spigot)
Pressure and temperature ratings
6000 psi @ 200 °F (414 bar @ 93 °C)
4000 psi @ 400 °F (276 bar @ 204 °C)
6000 psi @ 200 °F (414 bar @ 93 °C)
1500 psi @ 750 °F (103 bar @ 399 °C)
6000 psi @ 200 °F (414 bar @ 93 °C)
1500 psi @ 1000 °F (103 bar @ 538 °C)
6000 psi @ 200 °F (414 bar @ 93 °C)
1500 psi @ 800 °F (103 bar @ 427 °C)
6000 psi @ 100 °F (414 bar @ 38 °C)
3030 psi @ 1000 °F (201 bar @ 538 °C)
4500 psi @ 212F (310 bar @ 100 C)
4500 psi @ 212 F (310 bar @ 100 C)
1
/
-14 female NPT for Rosemount Wireless Pressure Gauge
2
1
/
-in. (54 mm) center-to-center connection per IEC
8
August 2016
