Installation Of Condensate Piping - Johnson Controls R SERIES Installation And Maintenance Manual

Item
A
Model
950
DHR24NKB21S
(37-3/8)
950
DHR30NKB21S
(37-3/8)
950
DHR36NKB21S
(37-3/8)
950
DHR42NKB21S
(37-3/8)
For the units: 48k
Item
A
Model
1040(41)
DHR48NKB21S

2.3.8 Installation of Condensate Piping

(1) Keep piping as short as possible and slope it downwards at a gradient of at least 1/100 so that air
may not remain trapped inside the pipe.
(2) Keep pipe size equal to or greater than that of the connecting pipe.
(3) Install the condensate piping as shown and take measures against condensation. Improperly
rigged piping could lead to leaks and eventually property damage.
Extension condensate
piping (commercially
available)
B C D
840 780 680
(33-1/8) (30-3/4) (26-3/4)
840 780 680
(33-1/8) (30-3/4) (26-3/4)
840 780 680
(33-1/8) (30-3/4) (26-3/4)
840 780 680
(33-1/8) (30-3/4) (26-3/4)
D
A
Figure 3-1-49
Table 3-1-10
B
910(35-7/8) 842(33-1/8)
Insulating tube
(commercially
available)
Figure 3-1-50
E F
160 240
(6-1/4) (9-1/2)
160 320
(6-1/4) (12-5/8)
160 320
(6-1/4) (12-5/8)
160 320
(6-1/4) (12-5/8))
B
Bottom face of ceiling
C D
788(31)
Insulating tape
(accessory)
22
Unit: mm (inch)
G H
917 215 993
(36-1/8) (8-1/2) (39-1/8)
917 215 993
(36-1/8) (8-1/2) (39-1/8)
917 215 993
(36-1/8) (8-1/2) (39-1/8)
917 215 993
(36-1/8)) (8-1/2) (39-1/8)
Unit: mm (inch)
E F
170(6-3/4) 290(11-3/8)
Indoor unit
condensate hose
I
