- Page 1 English Français Deutsch Italiano Español Nederlands Infrared Ear Thermometer Gentle Temp 520 (MC-520-E) ® Türkçe Instruction Manual IM-MC-520-E-03-01/2018 9042329-5C...
-
Page 2: Table Of Contents
Contents Thank you for purchasing the OMRON Gentle Temp 520 Infrared Ear Thermometer. Intended Use: The OMRON Gentle Temp 520 offers comfortable, safe, accurate and quick temperature measurement from the eardrum. Intended Operator: At least 11 years old (5 years intensive reading experience), no maximum. -
Page 3: Important Safety Information
Important Safety Information To assure the correct use of the product basic safety measures should always be followed including the precautions listed below. Warning: • Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury. •... - Page 4 Important Safety Information • Do not attempt measurements when the unit is wet as inaccurate readings may result. • Check the symbol on the display before and after the measurement so that the measurement is taken in the appropriate mode. •...
-
Page 5: Overview
1. Overview Main unit: Display: Infrared sensor Probe Probe cap Buzzer Probe cover detector Battery icon START button Memory icon Display Probe cover icon ON/MEM button Ear temperature Battery cover pick hole Temperature mode Battery compartment Connection ring Probe cover... -
Page 6: Preparation
2. Preparation Removing the Insulating Tape Pull the insulating tape out from the battery compartment by catching hold of the outer part for the first time. Switching between °C and °F This unit is set in °C as default. While the power is off, press and hold the START button. While holding it down, press and hold the ON/MEM button until °F appears on the display with 2 beeps. -
Page 7: Setting The Buzzer
2. Preparation Setting the Buzzer The buzzer is set on as default. Press the ON/MEM button to turn on the unit. Press and hold the ON/MEM button for 3 seconds. The “ ” symbol flashes on the display. Release the ON/MEM button. The “... -
Page 8: Attaching A Probe Cover
2. Preparation Attaching a Probe Cover Always use a new and undamaged Probe Cover MC-EP2 (MC-EP2-E). Gently twist off the probe cap. Note: Do not forcibly remove the probe cap. Place a new probe cover on the connection ring. Place Adhesive Side Upward Note: The adhesive side of probe cover should be upward. -
Page 9: Using The Unit
3. Using the Unit Taking a Reading Notes: • Make sure the probe cover is attached correctly. • It is recommended that you measure 3 times with the same ear. If the 3 measurements are different, select the highest temperature. Press the ON/MEM button. - Page 10 3. Using the Unit Measuring the temperature of an infant Measuring on a Measuring on The ear is too small lying baby. a sitting baby. to insert the probe. Lightly support Lightly support the While slightly pulling the child’s body. child’s body and the ear back, cover the slightly pull the ear...
- Page 11 3. Using the Unit Press the START button. The measurement is complete in 1 second with a long beep. The “ ” symbol will flash for 5 seconds. Note: You can take another measurement after 2 beeps. Make sure “ ” symbol remains lit. Remove the unit from the ear and check the measurement result.
-
Page 12: Using The Memory Function
3. Using the Unit Using the Memory Function This unit automatically stores the results up to 9 sets after each measurement. Note: If the memory is full, the unit will delete the oldest reading. Press the ON/MEM button to turn on the unit. Press the ON/MEM button again. -
Page 13: Troubleshooting And Maintenance
4. Troubleshooting and Maintenance The Icons and Error Messages In case of any of the below problems occur during measurement, first check that no other electrical device is within 30cm. If the problem persists, please refer to the table below. Error Display Cause Remedy... - Page 14 Remedy Remove the battery, wait for 1 minute and repower it. If Error 5-9, the system is not functioning the message reappears, please contact the OMRON properly. retail outlet or distributor for having the device checked. Temperature taken is higher than 42.2°C Check the integrity of the probe cover and take a new (108.0°F).
-
Page 15: Maintenance
4. Troubleshooting and Maintenance Maintenance • Please check the device if damaged after it is dropped. If unsure, please contact the OMRON retail outlet or distributor for having the device checked. • The probe is the most delicate part of the unit. Use care when cleaning the Infrared sensor to avoid damage. - Page 16 4. Troubleshooting and Maintenance Remove the battery with a pointed object. Note: Do not use metal tweezers or a screwdriver. Insert the new battery under the metal hook on the left side and press the right side of the battery down until it clicks. Note: Replace the new battery with the plus (+) side on the top.
-
Page 17: Technical Data
5. Technical Data Product Category: Ear Thermometers Product Description: Infrared Ear Thermometer Model (code): Gentle Temp 520 (MC-520-E) Sensing Unit: Thermopile Temperature Display: 4-digit, °F display in 0.1 degree increments 3-digit, °C display in 0.1 degree increments ± 0.2°C (± 0.4°F) within 35.5°C to 42.0°C (95.9°F to 107.6°F), Measurement Accuracy: ±... - Page 18 • The specification may be changed without prior notice. • This OMRON product is produced under the strict quality system of OMRON HEALTHCARE Co. Ltd., Japan. • This device fulfills the provisions of the EC directive 93/42/EEC (Medical Device Directive) and the European Standard EN12470:2003, Clinical thermometers - Part 5: Performance of infra-red ear thermometers( with maximum device).
- Page 19 5. Technical Data Description of symbols that, depending on a model, can be found on the product itself, product sales package or IM Applied part - Type BF Serial number Degree of protection against electric shock (leakage current) Ingress protection degree provided IP XX LOT number by IEC 60529...
- Page 20 MC-520-E manufactured by OMRON HEALTHCARE Co., Ltd. conforms to EN60601-1-2:2015 Electro Magnetic Compatibility (EMC) standard. Further documentation in accordance with this EMC standard is available at OMRON HEALTHCARE EUROPE at the address mentioned in this instruction manual or at www.omron-healthcare.com. Refer to the EMC information for MC-520-E on the website.
-
Page 21: Some Useful Information
6. Some Useful Information Temperature measurements taken within the ear The Gentle Temp 520 Infrared Ear Thermometer detects the infrared heat given off by the eardrum and surrounding tissues, and it converts this heat into an equivalent ear temperature. The Gentle Temp 520 is less threatening to a child than a rectal thermometer. It’s faster, safer and easier to use than an oral thermometer. - Page 22 6. Some Useful Information As ambient temperature, sweat, or saliva easily affects body temperature measured under the arm or the tongue, readings may be lower than the core temperature. Tympanic temperature measurement accurately reflects the brain temperature and can lead to a quicker detection of fever.
-
Page 23: Ear Temperature Compared To Other Types Of Body Temperature
6. Some Useful Information Ear temperature compared to other types of body temperature The normal temperature varies according to different locations on the body. Questions and answers How many times can I measure consecutively? You can measure consecutively up to three times. The main unit will then be warmed up and may not be able to measure correctly. - Page 24 6. Some Useful Information Is the temperature measured in the right ear different from that measured in the left ear? Among healthy people, there should be no significant difference in the measurement results. Differences may be caused by the following reasons: 1) The infrared sensor is not inserted in the same way.
-
Page 25: Optional Accessories
Optional Medical Accessories (within the scope of EC Medical Device Directive 93/42/EEC) Probe Cover MC-EP2 (MC-EP2-E) (Including 40 probe covers and 1 connection ring) Connection Ring Probe Cover Note: Please check with your local OMRON representatives for appropriate optional accessories. - Page 26 Manufacturer Fabricant Fabrikant OMRON HEALTHCARE Co., Ltd. Hersteller 53, Kunotsubo, Terado-cho, Muko, KYOTO, Fabricante Üretici 617-0002 JAPAN Produttore EU-representative Mandataire dans l’UE Vertegenwoordiging in de EU OMRON HEALTHCARE EUROPE B.V. EU-Repräsentant Scorpius 33, 2132 LR Hoofddorp, Representante en la UE...
