Honeywell C6097 Technical Information

Gas pressure switch
Hide thumbs

Advertisement

Quick Links

Gas pressure switch C6097

Technical Information · GB
4 Edition 01.19
• Monitoring of gas and air pressures (positive, negative and
differential pressures)
• Switches with falling or rising pressure.
• FM and UL certified:
With lock-off and hand wheel with "WC/mbar scale
• EU certified pursuant to EN 1854: Hand wheel with mbar scale

Advertisement

loading

  Also See for Honeywell C6097

  Related Manuals for Honeywell C6097

  Summary of Contents for Honeywell C6097

  • Page 1: Gas Pressure Switch C6097

    Gas pressure switch C6097 Technical Information · GB 4 Edition 01.19 • Monitoring of gas and air pressures (positive, negative and differential pressures) • Switches with falling or rising pressure. • FM and UL certified: With lock-off and hand wheel with "WC/mbar scale...
  • Page 2: Table Of Contents

    Gas pressure switch C6097 . . . . . . . . . . . . . . . . . . .
  • Page 3: Application

    Application C6097 with CE approval. C6097 with UL listing and FM approval. Hand wheel with mbar scale. Hand wheel with "WC and mbar scale. M16 cable gland for electrical connection. 1/2" NPT conduit for electrical connection. C6097 can be supplied with lock-off function.
  • Page 4: Use

    Gas, air, flue gas or Screw terminals and Air, flue gas C6097A3095 biogas ½" NPT conduit C6097 switches with falling pressure and locks off C6097A3111 C6097B3002 Hand wheel set to increasing pressure/ Gas, air, flue gas or Screw terminals C6097B3028...
  • Page 5: Application Examples

    1 .2 .1 Low gas pressure monitoring Electronic safety shut-off valve SAV with leak tightness For monitoring the minimum gas inlet pressure check of downstream devices 1 .2 .2 Differential pressure monitoring Differential pressure switch for monitoring air filters C6097 · Edition 01.19...
  • Page 6: Air Line With Minimum Pressure And Flow Monitoring

    (PDS) checks the flow of air via the differential pressure on the orifice. If there is no air pressure supplied or if there is no differ- ential pressure on the orifice, the system will be blocked. C6097 · Edition 01.19...
  • Page 7: Certification

    C6097A3079 C6097A3095 Factory Mutual Research Class: 3510 Flow and pres- C6097A3111 –   C6097A3137 sure safety switches. Designed for applications pursu- C6097B3002 ant to NFPA 85 and NFPA 86. www.approvalguide.com C6097B3028 C6097B3051 C6097B3085 C6097B3101 C6097B3119 C6097 · Edition 01.19...
  • Page 8: Function

    In the event of a 0.8 mm diaphragm tear, the escape of gas is limited to less than 1.0 CFH of natural gas, see max. inlet pressure, page 23 (UL, FM certified pressure switches), Ad- justing range, switching hysteresis. C6097 · Edition 01.19...
  • Page 9: Positive Pressure Measurement

    2), and the lower absolute pressure to port 4 (or 3). The remaining ports must be tightly plugged. ▼ The negative pressure is measured in the upper dia- phragm chamber, port 4 (or 3). The lower diaphragm chamber is ventilated via port 1 (or 2). C6097 · Edition 01.19...
  • Page 10 Increasing negative pressure Increasing pressure Decreasing negative pressure Decreasing pressure -6 -5 -4 -3 -2 -1 0 1 Do not connect port 4 (or 3) to pipes carrying gas! For further information, see page 14 (Ports). C6097 · Edition 01.19...
  • Page 11: Connection Diagram

    On pressure switches that switch with falling pressure: 3 .5 .2 Red/green pilot LED for 24 V DC/AC or 110 – The contact switches from NO 2 to NC 1. 230 V AC 3 COM 1 NC – C6097 · Edition 01.19...
  • Page 12: Wiring

    In the case of high humidity or aggressive gas compo- nents (H S), we recommend using a pressure switch with gold contact due to its higher resistance to corro- sion. Closed-circuit current monitoring is recommend- ed under difficult operating conditions. C6097 · Edition 01.19...
  • Page 13: Project Planning Information

    (please contact manufacturer). Ozone concentrations exceeding 200 µg/m or gases containing more than 0.1 %-by-vol. H S accelerate the ageing of elastomer materials and reduce the service life. C6097 · Edition 01.19...
  • Page 14: Ports

    It is recommended that the port which is best protected from water and dirt be left open. Connect Differential for the higher for the lower Seal pressure absolute absolute pressure pressure Seal ports that C6097 1 or 2 3 or 4 are not in use C6097 · Edition 01.19...
  • Page 15: Ul, Fm Certified Pressure Switches

    If necessary, port 4 (1/8" NPT) can be used to connect the venting line. A filter pad at port 4 protects the electrical contacts in the pressure switch from dirt particles in the surround- ing air or in the medium. C6097 · Edition 01.19...
  • Page 16: Resetting Pressure Switches With Manual Reset

    C6097B3002, C6097B3028, C6097B3051 lock off if the pressure rises to the set switching point. For resetting, the pressure must have dropped to at least the set switching point minus the pressure differential between the switching pressure and possible reset. C6097 · Edition 01.19...
  • Page 17: Accessories

    Order No.: 32003042-003/U In the case of high pressure fluctuations, we recom- mend using a restrictor orifice (contains non-ferrous metals): Hole diameter Ø 0.2 mm, Order No.: 32003051-003/U, Hole diameter Ø 0.3 mm, Order No.: 32003052-003/U. C6097 · Edition 01.19...
  • Page 18: Standard Socket Set

    110/120 V AC, I = 1.2 mA, Order No.: 32003045-003/U. 5 .5 Standard coupler plug 230 V AC, I = 0.6 mA, Order No.: 32003047-003/U. For CE certified pressure switches Order No.: 32003055-003/U. For FM, UL certified pressure switches Order No.: 32003056-003/U. C6097 · Edition 01.19...
  • Page 19: Led Set, Red/Green

    24 V DC, I = 16 mA; 24 V AC, I = 8 mA, Order No.: 32003048-003/U. 110 – 230 V AC, Order No.: 32003049-003/U. Order No.: 32003040-003/U 5 .9 Cover for manual reset Order No.: 32003041-003/U C6097 · Edition 01.19...
  • Page 20: Weather Protection Cover

    A 2 x covers, 100 x 100 x 100 mm B 2 x M4 x 16 screws C 4 x nuts D 2 x washers E 2 x cap nuts F 1 x filter pad (⅛" port) Order No.: 32003050-003/U. C6097 · Edition 01.19...
  • Page 21: Technical Data

    4 to 10 mm. The set switching point may palpably change in media Cable diameter: AWG 24 to AWG 13, and ambient temperatures below -22°F (-30 °C). 0.5 to 1.8 mm (0.02 to 0.07"). ▼ C6097 · Edition 01.19...
  • Page 22: Ul, Fm Certified Pressure Switches

    ± 15% ± 15% C6097A4310 30 – 150 3 – 5 – ± 15% ± 15% C6097A4410 100 – 500 8 – 17 – ± 15% ± 15% * Adjusting tolerance = ± 15% of the scale value. Switching properties, see page 4 (Use). ▼ C6097 · Edition 01.19...
  • Page 23: Ul, Fm Certified Pressure Switches

    3.2 – 6.8 (8 – 17) – Air/gas 1/4" C6097B3119 1 – 20 (2.5 – 50) 0.3 – 0.6 (0.75 – 1.5) – Air/gas 1/4" * Adjusting tolerance = ± 15% of the scale value. For further information, see page 4 (Use). C6097 · Edition 01.19...
  • Page 24: Dimensions

    6 .5 .1 EU certified pressure switches 13,1 43 (1.7") (0.52") Rp ¼ (2.76") 30 (1.2") ø 4,2 4 x ø 3,6 (ø 0.17") (ø 0.14") M16 x 1,5 13 (0.51") 30,5 (1.2") Holes 10 mm (0.4") deep, for self-tapping screws. C6097 · Edition 01.19...
  • Page 25: Ul, Fm Certified Pressure Switches

    6 .5 .2 UL, FM certified pressure switches 13,1 43 (1.7") (0.52") 4 x ø 3,6 (2.76") 30 (1.2") ¼" NPT (ø 0.14") ø 4,2 (0.43") (ø 0.17") " NPT 13 (0.51") ½" NPT Conduit Holes 10 mm (0.4") deep, for self-tapping screws. C6097 · Edition 01.19...
  • Page 26: Converting Units

    Maintenance cycles 7 Maintenance cycles 6 .6 Converting units See www.adlatus.org At least once per annum, at least twice per annum for biogas. C6097 · Edition 01.19...
  • Page 27: Feedback

    Michael Rehkamp m.rehkamp@kromschroeder.com Osnabrück For more information The Honeywell Thermal Solutions family of products includes Honeywell Combustion Safety, Eclipse, Exothermics, Hauck, Kromschröder and Maxon. To learn more about our products, visit ThermalSolutions.honeywell.com or contact your Honeywell Sales Engineer. Honeywell Process Solutions...
