PARTS LIST

Key Part
Number Number
- 2M-Y8602
- 2M-Y8420
1 2M-Z9183
2 2E-Z9310
2E-Z9310
2E-Z9310
2E-Z9310
3 C3-Y7952
4 2R-Y7844
5 C3-Y7953
6 C3-Y7377
7 C3-Y7446
8 C3-Y8187
9 C3-Y7475
10 C3-G8074
11 C3-G8073
12 2L-Y8863
13 2L-Y8812
14 2L-Y4916
15 C3-G8021
C3-G8022
C3-G1410
2E-Z0151
16 2K-Y2968
2K-Y6764
17 C3-Y7940
18 2A-6904
2P-Y3404
2C-1557
19 2E-Y2849
20 2P-6475
21 2N-Y8502
2N-Y8503
22 2K-Y1139
23 2Q-Y7830
24 2I-Y7836
25 2I-Y7840
26 2Q-Y8606
27 2E-Y8212
2E-Y9433
28 2S-8337
2S-Y2238
2S-Y8712
2S-Y8346
29 2B-Y7829
30 2C-1823
31 2C-9398
32 2E-T1042
2E-Z0089
33 2A-Y8645
34 2C-Y8646
35 2A-Y8032
36 2C-Y8147
IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED
INCLUDE MODEL AND SERIAL NUMBER
Some items are included for illustrative purposes only and in certain instances may not be available.
G8, G12 120V/240V/230CE
MODEL
Number
Per
Unit
1 LABEL STRIPE YELLOW/BLUE (Not Shown)
1 LABEL STRIPE BLACK (Not Shown)
1 LABEL FRONT
2 SWITCH (LIGHTED) after serial number G8010126
3 SWITCH (LIGHTED) before serial number G8010126
2 SWITCH (LIGHTED) after serial number G1206539
3 SWITCH (LIGHTED) before serial number G1206539
1 BRACKET CATCH
2 CATCH MAGNETIC
1 COVER BRACKET
2 BRACKET HINGE LEFT
2 BRACKET HINGE RIGHT
1 LOWER DOOR
2 DOOR PULL ASSEMBLY (INC.IN DOOR ASSYS.)
1 LEFT DOOR ASSEMBLY
1 RIGHT DOOR ASSEMBLY
1 OIL MEASURE CUP 2 CUP (PLASTIC)
1 CORN MEASURE CUP 2 CUP (PLASTIC)
1 SCOOP - POPCORN (PLASTIC)
1 CORD ASSEMBLY 120V
1/1 CORD ASSEMBLY 240V
1 CORD ASSEMBLY 120V
1/1 CORD ASSEMBLY 230CE
1 BUSHING-STRAIN RELIEF 120V
1 BUSHING 120V/240V
1 DRAWER CORN
4 FOOT
4 PLUG - FOOT
4 SCREW - FOOT
1 BLOCK TERMINAL
4 CLIP-TY
1 ELEMENT-80 WATT 120V
1 ELEMENT-90 WATT 240V/230CE
1 BUSHING HEYCO
2 GLASS SIDE (TEMPERED)
6 CHANNEL GLASS (TOP/BOTTOM)
6 CHANNEL GLASS (UPRIGHT)
1 GLASS FRONT
1 SOCKET LAMP
1 SOCKET LAMP 230CE
1 LAMP-150W 120V
1 LAMP - 250W 120V-120V
1/1 LAMP 150W 230CE/240V
1 LAMP 250W 240V
1 LAMP SHIELD
10 WASHER LOCK
4 SCREW
1 RECEPTACLE 120V
1 OUTLET STRAIGHT BLADE 230CE/240V
1 PIN STOPPER-SHORT
1 SCREW
1 PIN STOPPER
1 SCREW
Star Manufacturing International, Inc.
Description and Model Designation
14
November 1, 2007 Rev. M
G12
G12
G8
G8
G12
G12
G8
G8 / G12
G12
G8 / G12
G8
G12
G8
G12
G8 / G12
G12
1
PAGE
2
OF
