12 Connection description

12.1 Access to the Electronic boards

To have access to the electronic boards the user must removing the unit's cover
(see par.7.1)
Warning: Before operate, be sure that power and control cables are isolated from voltage
sources
PWI30 board
DDC30 board
MULTIDRIVE-1PH 850A
