9 Led status and Alarms

9.1 LED Status Table

On the DDC30 Electronic board there are two LED that indicates the state of the Electronic cards:
LED
For All size
LD1
LD2
MULTIDRIVE-1PH 850A
STATUS
The power supply is not connected or fault on the electronic board
Fault on the electronic board
Electronic board is OK
The power supply is not connected
The power supply is connected
= OFF
= ON
= Flashing
DESCRIPTION
21
User's Manual
LD1 LD2
