Summary of Contents for NextBase InCar Cam 3052 Lite
- Page 2 To download more languages of instruction manual, please visit www.next-base.com >PRODUCTS >INCAR CAM > 3052> DOWNLOAD.
-
Page 3: Table Of Contents
TABLE OF CONTENTS PRECAUTIONS ..........................01 PRODUCT SPECIFICATION ....................... 02 PACKAGE CONTENTS ....................... 03 PRODUCT FEATURES........................ 03 CONTROLS ..........................04 INSTALLATION ..........................05 VIDEO MODE ..........................06 MENUS AND SETTINGS ......................07 WIFI CONNECTIOM ........................08 TROUBLE SHOOTING ........................ 09 PRECAUTIONS Please read this manual carefully before operation and keep it for future reference. -
Page 4: Product Specification
PRODUCT SPECIFICATION Model Number / Name NBDVR3052/ NEXTBASE iN-CAR CAM 3052 Power Requirements 5V / 2A (USB socket) Power Supply 12-24Vdc Car Power Cable (supplied) Fuse Type: 20mm Glass Fast Blow 2A Output: 5Vdc Sensor Resolution 2.0M Pixel (2,000,000 Pixel) Lens Type / Angle / Aperture 5G / 140°... -
Page 5: Package Contents
Manual 3M VHB PRODUCT FEATURES Thank you for purchasing this NEXTBASE iN-CAR CAM product, in this section we will outline some of the features available with this device. 1.5" 4:3 LCD Colour Screen Ease of use and viewing the playback of both videos and photos. -
Page 6: Controls
CONTROLS 1. Micro USB Port MEMORY CARD SLOT Connect car power cable. Insert micro SD card here. 9. SPEAKER 2. LED INDICATOR 10. MICROPHONE 3. RESET 11. MOUNTING POINT Press to reset the iN-CAR CAM. Attached supplied windscreen mount here. 4. -
Page 7: Installation
INSTALLATION 12-24V DC The above diagram is for illustration purposes only. 1. Open dust cover and insert a suitable memory card in to the device, taking care to follow correct orientation markings (gold contacts facing the back of the device). Push the memory card until it clicks into place and close dust cover. Do not remove or insert the memory card when the iN-CAR CAM is turned on. -
Page 8: Video Mode
VIDEO MODE The key below explains the various information displayed on the screen when your iN-CAR CAM is in Video mode, some icons will only be displayed once the relevant function has been selected within the Video menu, as described further down this page. -
Page 9: Menus And Settings
MENUS AND SETTINGS MENUS AND SETTING 1. Loop Recording Select duration of recording length for the individual video files, the iN-CAR CAM will fill the SD Card then loop back to the beginning, overwriting the saved files (unless protected). Default Setting: 3 Minutes 2. -
Page 10: Wifi Connectiom
MENUS AND SETTINGS Adjust the date / time as required. Adjust the sequence of Year/ Month/ Date. Default Setting: Year/ Month/ Date Delete videos or photos file you recorded. 17. Protect Setting videos or photos file to be protected file or unprotected file, protected file cannot be removed during Loop Recording. -
Page 11: Trouble Shooting
I can’t hear sound of my record please try other playback software. We suggest using GOM Player. video when I open video in my Or you can download NEXTBASE DVR Playback software computer. form “www.next-base.com” for playing your record videos.
