Hardware Installation; Tools Required; Safety Precautions - American Auto-Matrix AspectFT-Nexus Hardware Installation Manual

The following provides mounting, wiring and installation of AspectFT-Nexus and AspectFT-Facility. Please
read through this document carefully before beginning the installation procedure.
1.1 I
NTRODUCTION
Unpack your AspectFT-Nexus and AspectFT-Facility hardware and inspect the contents of the package for
damaged or missing items. Included in this package, you should find the following items:
AspectFT-Nexus and AspectFT-Facility Appliance
.
AspectFT-Nexus and AspectFT-Facility QuickStart Guide
.
1.1.1 T R
OOLS EQUIRED
The following tools and supply may be required for installation:
Slotted 2.5 mm precision screwdriver- for power and field-bus connectors
.
1/8" hex key- to fasten the cover
.
Wire-strippers - for terminating EIA-485 connections and power connections
.
1.1.2 S P
AFETY RECAUTIONS
AspectFT-Nexus & AspectFT-Facility Installation Guide (1/02/2014)
S
ECTION
H
ARDWARE
All equipment must be installed in accordance with
NEC and local codes. For more information on
local codes, please check state/local regulations in
your area.
CAUTION
Ensure that this product is installed in an operating
environment where the ambient temperature does
not exceed
temperature of the unit.
1
I
NSTALLATION
NOTE
the maximum rated ambient
1-1
