Product Specifications; Serial Port - American Auto-Matrix AspectFT-Nexus Hardware Installation Manual

1.5 P
RODUCT
1.5.1 P R
OWER EQUIREMENTS
Power Source: 19-29 VAC/VDC, 50/60Hz, 4.17A Max at nominal 24VAC voltage
.
Connection: 2 position
.
1.5.2 S P
ERIAL ORT
Each serial port is powered by 24VAC and independently protected
.
Voltage: 24VAC, ±5V
.
Frequency: 50/60Hz
.
Over Current Protection: Resettable Fuse/PTC; 0.5A hold current
.
Over Voltage Protection: 48VDC Bidirectional TVS
.
1.5.2.1 RS-485 (A
SPECT
Supported Baud Rates: 9.6kbps, 19.2kbps, 38.4kbps, 57.6kbps, 76.8kbps, 115.2kbp
.
Data Isolation: GMR Data Isolated
.
Termination: 249Ω, switch selectable
.
Biasing: 3.32kΩ (on each line), switch selectable
.
Receiver input resistance impedance: 96kΩ minimum, 160kΩ typical (1/8th unit load)
.
Bus devices rating of transceiver: up to 256
.
Protection: 12V TVS on each line
.
1.5.3 E
THERNET
Termination Count: 2 connection (2nd port for future use only)
.
Connection Type: RJ-45, female
.
Speed: 10/100/1000Mb auto-sensing
.
1.5.4 P S
RODUCT
Software: AspectFT-Studio with USB Copy Protection Key and License File
.
Browser: Windows Internet Explorer v7.0 or later, Mozilla Firefox v3.0 or later, Apple Safari v3.2 or
.
later, Goggle Chrome v1.0 or later
1.5.5 P
ERFORMANCE
RAM and Storage: 2GB DDR2 SDRAM, 64GB Solid State Hard Drive
.
CPU: Intel® Atom D510
.
System Chipset and BIOS: Intel® ICH8M, Award SPI 16 Mbit BIOS
.
1.5.6 O
PERATING
Operating Temperature: 10°C to 40° (50°F to 104°F)
.
Operating Humidity:0-80%, non-condensing
.
1.5.7 D
IMENSIONS
Approximate Dimensions: 13" x 8.5" x 4"
.
Approximate Weight: 7.5 lbs
.
Mounting: Wall mount only
.
1.5.8 A A
GENCY PPROVALS
CE Approved
.
FCC Part 15, Subpart B, Class A
.
UL Listed 916, Management Equipment, Energy (PAZX)
.
1-10
AspectFT-Nexus & AspectFT-Facility Installation Guide (1/02/2014)
S
PECIFICATIONS
FT-N O )
EXUS NLY
N
ETWORK
C
ETUP AND ONFIGURATION
C
ONDITIONS
, W , M
EIGHT AND OUNTING
