Dealer/Installer: Give manual to homeowner.
Installer: Read "Safe Installation" on p. 2 and all instructions before beginning. For proper assembly and installation,
instructions must be followed completely.
Homeowner: Read "Safe Use" on back cover before using. Save these instructions.
CURVE STEP / CURVE STEP SYSTEM
ASSEMBLY, INSTALLATION AND USE MANUAL
STEP TO BE INSTALLED ON INSIDE OF POOL ONLY
Assembly video available online: www.conferplastics.com
Model CCX-IG
Curve Step
Note: 40 lbs. of sand required!
To reduce the risk of drowning, entrapment, falls, paralysis, electrocution, or other
serious injury or death:
MODEL CCX-IG
WEIGHT LIMIT 400 LBS.
U.S. patent 8,936,134
Model CCX-IG System
Curve Step System
Note: 70 lbs. of sand required!
Made in the USA
