8.9 Automatic spindle lock (See Fig. H)
The automatic spindle lock allows you to use the drill / driver as a regular
screwdriver. You can give an extra twist to firmly tighten a screw, loosen
a very tight screw or continue working when the battery energy has
expired. For manual screwdriver purposes, the chuck is automatically
locked when the drill is off.
H
8.10 Using the LED light (12)
To turn on the LED light (12), first activate the drill / driver, then press
either the reverse touch pad (10) or the forward touch pad (11). LED
lighting (12) increases visibility-great for dark or enclosed areas.
When you release either the reverse touch pad (10) or the forward touch
pad (11), the LED light (12) will de-activate after 5 seconds.
8.11 Belt clip (6) (See Fig. I1, I2)
WARNING:To reduce the risk of serious personal injury,
ensure the screw holding the belt clip (6) is secure.
The side belt clip (6) is used to assist to clip the drill / driver to your waist
belt while working. To install, insert the assembly screw through the belt
clip screw hole into the retaining hole on the drill / driver, and using a
philips head screwdriver (not supplied), tighten the screw by turning in a
clockwise direction
NOTE: The belt clip (6) can be assembled onto either side of the drill /
driver.
