8.6 Two-speed gear control (3) (See Fig. E)
This drill / driver has a two-speed gear control (3) designed for drilling
or driving at either LOW speed (as mark by number 1) or HIGH speed
(as marked by number 2). The two-speed gear control is a slide switch
located on top of the drill / drive. When using the drill / driver in
the LOW speed range, the speed will decrease and the drill will have
greater power and torque. When using the drill in the HI speed
range, the speed will increase and the drill will have less power and
torque.
1. To select LOW gear push the two speed gear selector (3) forwards,
towards the chuck at the front of the drill / driver. The number "1"
will be displayed.
2. To select the HIGH gear push the two speed gear selector (3)
backwards, towards the rear of the drill / driver. The number "2"
will be displayed.
Gear I
Low speed range: for screwdriving or working with large drilling
diameter
Gear II
High speed range: for working with small drilling diameter
WARNING: To prevent gear damage, always allow the
chuck to come to a complete stop before changing the
direction of rotation or the two-speed gear control.
