FIELD ADJUSTMENT GUIDE
Precision ap
Nutri-Pro Pull-Type 3-Section Anhydrous Shank
Date: November 7, 2016
Document #
PAUS200C-0010A
Models Affected:NP1330AA
General Information
Proper servicing and adjustment is key to the long life of all farm equipment. With careful and sys-
tematic inspection of equipment, costly maintenance, time and repair can be avoided. The follow-
ing information will assist with recommended servicing and adjustments:
1 of 6
Document
#PAUS200C-0010A
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for GREAT PLAINS Nutri-Pro NP1330AA
Summary of Contents for GREAT PLAINS Nutri-Pro NP1330AA
- Page 1 FIELD ADJUSTMENT GUIDE Precision ap Nutri-Pro Pull-Type 3-Section Anhydrous Shank Date: November 7, 2016 Document # PAUS200C-0010A Models Affected:NP1330AA General Information Proper servicing and adjustment is key to the long life of all farm equipment. With careful and sys- tematic inspection of equipment, costly maintenance, time and repair can be avoided. The follow- ing information will assist with recommended servicing and adjustments: 1 of 6 Document...
- Page 2 Folding The Applicator (Pull-Type): Note: Before folding the applicator, ensure that the tractor is pointed into the wing and all NH3 flow has stopped. 2) Close the weight-transfer shut-off valve. 3) Fully extend the lift cylinders. Install the transport locks on the lift-assist and center section cylinders.
- Page 3 Adjusting Weight Transfer: Adjust the weight transfer system to achieve consistent coulter depth along with keeping the wings level with the center section. If insufficient weight is transferred, outside (wing) coulters may run higher than the center section and if too much weight is transfered, the center section may run too high.
- Page 4 Frame Mounted Coulter Adjustment: Coulters are factory installed and are configured for in-row operation at knife or tine shoe depth. They can be set for fixed or limited caster- ing. Coulter depth can be adjusted per the following: 1) Loosen the U-bolt nuts (14) and slide the shaft (15) up or down.
- Page 5 Sealer Adjustment: The sealers are designed to close the trenches behind the knives or tines and manage residue. The sealer wheels and discs are free to move downward from their normal operating position to provide consistent action. There are four to six sealer adjustments available, depending on the sealer type.
- Page 6 Rear Eye Bolt Adjustment: Side to side levelness at the rear of the applicator is controlled by the eye bolts located on the lift-assist cylinder bases. On pull-types the rear height is con- trolled by the cylinders, slaved to the hydraulic depth stop 3.5”...
