INSTALLATION AND OPERATING INSTRUCTIONS
T10240
T10230
installing this product, we are here to help!
Titan 450™ Drum Winch
Titan 300™ Drum Winch
If you have any questions or difficulty
First READ THIS MANUAL.
If you still need help, call us from 9 am to 4 pm
(Central time) Monday – Friday.
(615) 462-6224
Note: At this time, we provide Phone Support in English only.
ANCHOR WINCHES
Advertisement
Table of Contents
Related Manuals for TRAC Titan 450 T10240
Summary of Contents for TRAC Titan 450 T10240
- Page 1 INSTALLATION AND OPERATING INSTRUCTIONS ANCHOR WINCHES T10240 Titan 450™ Drum Winch T10230 Titan 300™ Drum Winch If you have any questions or difficulty installing this product, we are here to help! First READ THIS MANUAL. If you still need help, call us from 9 am to 4 pm (Central time) Monday –...
-
Page 2: Safety Issues
Opening the Control Unit will void the product warranty unless instructed by a TRAC Service Technician. Use a 100-amp circuit breaker or fuse near the battery. This breaker protects the wire between winch and battery. -
Page 3: Product Specifications
Boat trailering hazards – As a precaution, when the boat is being trailered, the anchor must be secured inside the boat or tow vehicle. If the anchor were to break free while trailering, it could cause serious damage and/or injury. Anchoring hazards. -
Page 4: Installation
INSTALLATION TOOLS REQUIRED: 1. Electric Drill with 7/8” (22mm), 5/16” (10mm) and 1/8” (3mm) Drill Bits 2. Adjustable (Crescent style) wrench 3. Socket and driver MATERIALS REQUIRED 1. Mounting Hardware - For Titan 450 use countersink head bolts – for Titan 300 use hex head or round head bolts. 4 sets- 5/16 (10mm) stainless steel bolts (length = mounting surface + 1.5”... - Page 5 INSTALLING THE SWITCH PANEL This winch includes a second switch and connector cable. Determine the location of the second switch (usually at the helm). Hold the switch in the desired location and mark the center hole location and drill a 7/8” (22mm) hole for the connector to pass through. Pass the switch connector through the hole and lay the switch flat on the installation surface.
-
Page 6: Troubleshooting Guide
300 ft* 200 ft*~ 180 ft* 120 ft* 100 ft ^ ~ TRAC Anchor Rope Offerings * plus 20 ft. of chain + plus 15 ft. of chain ^ no chain SAFETY CABLE ATTACHMENT When the boat is being transported by trailer, the anchor must be placed in the boat and secured. If the anchor were to break free during trailering, it could cause serious damage and injury. - Page 7 Over-run If the rope tangles or spills over the side of the drum, apply tension on the rope while pressing the UP or DOWN button in the appropriate direction to unwind the tangle. Actuator Malfunctions Check for power present on the connector (CU side) when unplugged and FREE FALL or LOCK buttons are pressed. ...
- Page 8 TITAN 450™ 9 & 10 TITAN 300™ 9 & 10...
- Page 9 This limited warranty is provided by TRAC Outdoor Products Co (TRAC) to the original consumer purchaser (purchaser) of the TRAC Anchor Winch. This limited warranty is not transferable to any other party. TRAC will at it option repair or replace any part(s) of the TRAC Anchor Winch which may be found by TRAC to be defective within two (2) years of purchase.
