2.1

UNPACKING AND ASSEMBLY

If you have purchased a new T7™ cart with MedLink™, the cart will arrive with the MedLink™ housing pre-installed on the cart.
The MedLink™ Cassettes will be in the housing. Remove the Cassettes from the housing and remove and discard any protective
packaging.
If you have purchased a MedLink™ Drawer system to retrofit to an existing T7™ cart the MedLink™ housing must be installed on
the T7™ cart by a Humanscale representative or an authorized service technician.
MedLink™ Drawers, shelves and dividers are shipped in a separate box. Before continuing you should locate the proper Drawer
and shelf components.
2.2

INSTALLING SHELVES INTO CASSETTES

Before inserting Drawers into a Cassette, you must first insert shelves to configure your required Drawer layout. Cassettes maybe
reconfigured at any time if the layout requirements change.
1. To insert a shelf, hold the Cassette in place on a flat surface with one hand. With the other hand, insert the shelf so that
the slots on sides of the shelf slide over the locating pins on the inside side walls of the Cassette.
2. Ensure the rear snap features are aligned with the locating holes on the inside rear wall of the Cassette.
3. When the slot and snap features are aligned with the locating features inside the Cassette, push the shelf firmly into the
Cassette. The shelf should click into place.
4. The shelf can be removed by reversing this process. Pull the shelf firmly outwards, ensuring you are pulling outwards
parallel to the shelf. The rear locating features will disengage, and you can slide the locking slot clear of the pin.
Image 2 - Installing Shelves
