Parts
Dimensions In Inches
Retracted: 31.89"
extended: 70.89"
Specifications
Dynamic Load
Static Load
Speed at Full Load:
Stroke Length:
Retracted Length
Weight:
Input Voltage:
Output Voltage:
Overload Protection:
Duty Cycle:
Color:
IP Grade:
Operational Temperature:
Certification:
Tube Material:
Control Options:
Control box
28.98
0.39
5.67
10%
Wireless remote
1.26
1.97
1.18
5.55
m6
7.09
130 lbs
150 lbs
0.98"/sec
39"
31.89"
42 lbs
120V~ 60Hz, 86W
24VDC 2A
Yes
(2 minutes on, 18 minutes
off)
Black
IP20
-5ºC~+20C (23ºF~104ºF)
CE and UL
Powder painted steel tube
RF remote/ Wired remote
2
