Keypad Operation

The ON/OFF button turns the meter on
and off. When the meter is turned on,
ON/OFF
it will display the battery status for 3
seconds. The screen will then display
the amount of memory available and
the status of the GPS connection. The meter then goes
into normal reading mode.
CAUTION: If the meter is inactive for 20 minutes, it
will automatically turn off to conserve power. When
the meter is powered off, either with the ON/OFF but-
ton or due to inactivity, the AVG and N values are re-
set to zero (see Normal Reading Mode, p.
BATTERY AT 85%
V5.0
LOGGER 28% FULL
NO GPS FOUND
LOGGER 35% FULL
GPS=YES DGPS=YES
INDEX=275 BRT=4
AVG=283 N015 LOG
8
10)
Battery status screen
Logger and GPS status
screens
Data screen
(normal reading mode)
