Field Scout Software - Spectrum Technologies Field Scout CM1000 Operation Manual

Field Scout Software

Meter Type
The Field Scout software
supports all of Spectrum
Technologies' portable data
logging meters. Be sure to
select the CM 1000 Meter
from the Select Meter Type
screen
Com Port
The gray software cable connects
the meter to the computer data
port. The port is located at the
bottom of the meter. Clicking the
Com Port button will bring up the
Port Selection screen. Select the
Com Port that is assigned to the
computer data port. For most ma-
chines, this will be COM 1. See
Identifying the Correct Com Port
(p. 7) for instructions on how to
determine which port to select.
Meter Settings
14
Clicking on the Meter
Settings button will bring
up the Meter Settings
screen. This screen al-
lows you to configure the
meter. The Meter Name
will be the title on the
first line of
downloaded files.
The logging function is
the
