- Page 1 GETTING STARTED GUIDE NI 9866 1-Port, LIN Module 한국어 日本語 Français Deutsch 简体中文 ni.com/manuals...
-
Page 2: Safety Guidelines
This document explains how to connect to the NI 9866. The NI 9866 module requires the latest software to be installed. The latest version of the software is at ni.com/downloads. Before you begin, complete the software and Note hardware installation procedures in your chassis documentation. -
Page 3: Safety Guidelines For Hazardous Locations
Safety Guidelines for Hazardous Locations The NI 9866 is suitable for use in Class I, Division 2, Groups A, B, C, D, T4 hazardous locations; Class I, Zone 2, AEx nA IIC T4 and Ex nA IIC T4 hazardous locations; and nonhazardous locations only. -
Page 4: Special Conditions For Hazardous Locations Use In Europe And Internationally
II 3G and is suitable for use in Zone 2 hazardous locations, in ambient temperatures of -40 °C ≤ Ta ≤ 70 °C. If you are using the NI 9866 in Gas Group IIC hazardous locations, you must use the device in an NI chassis that has been evaluated as Ex nC IIC T4, Ex IIC T4, Ex nA IIC T4, or Ex nL IIC T4 equipment. -
Page 5: Wiring The Ni 9866
Caution accessible only by the use of a tool. Wiring the NI 9866 The NI 9866 has one 9-pin male D-Sub connector that provides connections to a LIN bus. The port has two common pins (COM) that are internally connected to the module’s isolated reference and serve as the reference ground for LIN signal. - Page 6 You must use a UL listed ITE power supply Caution marked LPS with the NI 9866. The NI 9866 requires an external power supply of +8 to +18 V to operate. Supply power to the NI 9866 V pin from the LIN bus.
- Page 7 Table 1. Pin Assignments for the NI 9866 Connector Signal Name No Connection (NC) SHLD NI 9866 Getting Started Guide | © National Instruments | 7...
-
Page 8: Cabling Requirements For The Ni 9866
The maximum allowable cable length is 40 m, per the LIN specification. Number of LIN Devices The maximum number of devices on a LIN bus is 16, per the LIN specification. 8 | ni.com | NI 9866 Getting Started Guide... -
Page 9: Termination Resistors
API with the NI-XNET Session Interface:LIN:Termination property. NI 9866 Hardware Overview The NI 9866 has one full-featured LIN port that is isolated from the other modules in the system. The port has a LIN controller that is fully compliant with the LIN 1.3/2.0/2.1/2.2 Specification. - Page 10 Figure 1. NI 9866 Hardware Overview Ext Pwr Supply Required Transceiver Controller NI 9866 Specifications The following specifications are typical for the range -40 °C to 70 °C unless otherwise noted. 10 | ni.com | NI 9866 Getting Started Guide...
-
Page 11: Lin Characteristics
Contact NI for Bellcore MTBF or MIL-HDBK-217F specifications Power Requirements ............Power consumption from 1 W max (active mode) chassis ............Thermal dissipation 1.25 W max (active mode) (at 70 °C) NI 9866 Getting Started Guide | © National Instruments | 11... -
Page 12: Physical Characteristics
This category is for measurements of voltages from specially protected secondary circuits. Such voltage measurements included signal levels, The maximum voltage that can be applied or output without creating a safety hazard. 12 | ni.com | NI 9866 Getting Started Guide... -
Page 13: Safety And Hazardous Locations Standards
• IEC 61010-1, EN 61010-1 • UL 61010-1, CSA 61010-1 • EN 60079-0:2012, EN 60079-15:2010 • IEC 60079-0: Ed 6, IEC 60079-15; Ed 4 NI 9866 Getting Started Guide | © National Instruments | 13... -
Page 14: Hazardous Locations
Zone 2, AEx nA IIC T4 ............Canada (C-UL) Class I, Division 2, Groups A, B, C, D, T4; Class I, Zone 2, Ex nA IIC T4 ............Europe (DEMKO) Ex nA IIC T4 Gc 14 | ni.com | NI 9866 Getting Started Guide... - Page 15 10% RH to 90% RH, (IEC 60068-2-78) noncondensing ............Storage humidity 5% RH to 95% RH, (IEC 60068-2-78) noncondensing ............Pollution Degree ............Maximum altitude 2,000 m Indoor use only. NI 9866 Getting Started Guide | © National Instruments | 15...
-
Page 16: Shock And Vibration
• EN 61326 (IEC 61326): Class A emissions; Basic immunity • EN 55011 (CISPR 11): Group 1, Class A emissions • AS/NZS CISPR 11: Group 1, Class A emissions 16 | ni.com | NI 9866 Getting Started Guide... -
Page 17: Online Product Certification
94/9/EC; Potentially Explosive Atmospheres (ATEX) Online Product Certification Refer to the product Declaration of Conformity (DoC) for additional regulatory compliance information. To obtain product certifications and the DoC for this product, visit ni.com/ NI 9866 Getting Started Guide | © National Instruments | 17... -
Page 18: Environmental Management
At the end of the product life cycle, all EU Customers NI products must be disposed of according to local laws and regulations. For more information about how to recycle NI products in your region, visit ni.com/ environment/weee. 18 | ni.com | NI 9866 Getting Started Guide... -
Page 19: Worldwide Support And Services
NI Application Engineers. Visit ni.com/services for NI Factory Installation Services, repairs, extended warranty, and other services. NI 9866 Getting Started Guide | © National Instruments | 19... - Page 20 For telephone support outside the United States, visit the Worldwide Offices section of ni.com/niglobal to access the branch office websites, which provide up-to-date contact information, support phone numbers, email addresses, and current events. 20 | ni.com | NI 9866 Getting Started Guide...
