VB1000 / VB2000
P A R T S L I S T
Item
Qty
Description
A
2*
VB10 Aluminum or
VB20 Steel Standards
B
2
VB51P-XX Pole Padding
C
2
VB23-CV Floor Plates
(If Applicable)
D
2
VB23 or VB235 Floor Sockets
(If Applicable)
E
4
Cable Covers
(If Applicable)
F
1
VB1250K Net with Storage Bag
G
2
Volleyball Antennas
(VB13)
H
1
Winch
I
1
Top Net Cable Attachment Screw
Inspect all contents prior to installation. Report any missing parts to dealer
immediately.
Read all instructions before proceeding!
The telescoping poles are under spring pressure, make sure the knurled knob is tight and/or the de-
tent pin that positions the inner pole is in place at all times to eliminate the risk of possible injury.
Date: 8/9/2018
Rev: 15
—— Instruction Manual ——
Aluminum/Steel Volleyball Systems
( Either in packages or components ordered separately )
B.A.
N.J.C.
Item
Qty
Description
J
2
Nylon Net Collars
K
3
Carabineer
L
1
3/16" Allen Wrench
M
1
Knurled Knob
N
6
Rope Ratchet
(Provided with Net)
O
1
1/8" Allen Wrench
P
1
1/4" Allen Wrench
Q
1
Positive Lock Pin
Caution:
File:\\bisonserver\publisher\VB1000-2000.pub
1
Customer Service
(800) 247-7668
Ref#: 960127
Advertisement
Table of Contents
Related Manuals for Bison VB1000
Summary of Contents for Bison VB1000
- Page 1 —— Instruction Manual —— VB1000 / VB2000 Aluminum/Steel Volleyball Systems Customer Service ( Either in packages or components ordered separately ) (800) 247-7668 P A R T S L I S T Item Description Item Description VB10 Aluminum or Nylon Net Collars...
- Page 2 Figure 1 ROPE GUIDE INNER POLE TOP NET CABLE ATTACHMENT SCREW (I) POSITIVE LOCK PIN (Q) OUTER POLE KNURLED KNOB (M) Net (F) Rope Ratchet for the Net (N) Nylon Net Collar (J) Figure 2...
- Page 3 Initial Standard Height Adjustment NOTE: The Bison Centerline systems have been designed to “set and play”, after initial set-up all net height guess work is eliminated. The inner pole has machined marks provided for men's, women's and junior’s official height. The outer pole has an adjustable bottom foot factory pre-set for 10” floor sockets. Please read and follow the instructions below carefully to make fine tuning adjustments if needed.
- Page 4 NOTE : Excessive tightening of top rope is not necessary. Crank the winch until poles start to flex. Further tensioning results in lowering of the top rope. Achieve proper height using the inner pole adjustment and to achieve proper net tensioning use the rope ratchets. Height Adjustment for a Single Court System Starting with a loose top net cable, loosen the Knurled Knobs (M), remove the Positive Lock Pins (Q) and adjust the inner poles to the desired height indicated by the height markings machined on the inner poles...
- Page 5 Height Adjustment for a Side by Side Court System Both Nets the Same Height Remove tension from both nets with the Winches (H). Adjust all three poles by loosening the Knurled Knobs (M), removing the Positive Lock Pins (Q) and then adjusting the inner poles to the desired height and then retightening the Knurled Knobs (M) and replace the pins if adjusted to one of the official heights.
- Page 6 Custom Floor Socket Sleeves & Deep Socket Adapters 1. If you have purchased the Bison VB10/20 3” Standards (A), for use in existing sockets that are not 3” diameter call Bison Customer Service department at 1-800-247-7668 for custom floor socket sleeves available at no additional cost.
- Page 7 Court Diagram...
