Page 1
—— Instruction Manual —— WIKLIFT DJUSTABLE ASKETBALL YSTEMS Customer Service Models BA8250X (4” Pole) and BA9250X (5” Pole) (800) 247-7668 P A R T S L I S T Item Description Item Description Vertical Pole 1/2” X 3” Hex Bolt Extension Arm 1/2”...
Thread a 5/8” Hex Nut (G) onto each “J” Bolt (E) leaving at least 2 1/2” of threads exposed above the 5/8” Hex Nut (G). Place each “J” Bolt (E) into the holes of the “J” Bolt Template (J), thread a second 5/8”...
Page 3
Drive 36” Rebar (F) into bottom of the hole equally Crank Mount Bracket spaced to form a square. Mix concrete according to instructions on the bag. It is advantageous to have the mixture “wet”. This will increase your working time and allow batches to mix in the hole.
Page 4
Use the 1/2” Pivot Bolts (R) (BA8250X bolt is 7” long, BA9250X bolt is 8” long), 1/2” Flat Washers (W), Pole Spacers (L) and 1/2” Lock Nuts (V) to attach Extension Arms (B) to Vertical Pole (A). Tighten hardware until the Extension Arms (B) stay in any position you put them yet are freely moved by hand.
Page 5
18. Install Pole Padding (II) before play. FIGURE 6 Backboard Spacer (M) Backboard Spacer (M) positioned on the inside of positioned on the outside of Extension Arm (B) when installing Extension Arm (B) when installing Model BA9250X Model BA8250X FIGURE 7...
Page 6
AA BB CC BA32 RIM (HH) HARDWARE 7 1/2' 8 1/2' 9 1/2' FIGURE 8...
Page 7
—— Instruction Manual —— BA79UGP Customer Service Cement Base Installation Instructions (800) 247-7668 P A R T S L I S T Item Description Item Description “J” Bolts 5/8” Lock Washer 36” Long Rebar 5/8” Flat Washer Template Safety Cap 5/8”...
4. A 20” diameter by 48” deep hole will require approximately 1/2 cubic yard of 3000 psi concrete (22-24 60# sacks of premix concrete). Allow for more if the hole is deeper or wider. Make sure you have enough concrete before pouring, because allowing a portion to dry before the hole is completely filled will affect the strength of the footing.
Page 9
Figure A Figure B Application Chart: Table shows backboard location in relation to center of hole when the systems are adjusted at 10’, 9’ and 8’ rim heights. System Product Code 10’ Rim Height 9’ Rim Height 8’ Rim Height 4”...
