————— Instruction Manual —————
M
ODEL
Adjustable Playground Pole System
Item
Qty
Description
A
1
H-Frame
B
1
Extension Arm
C
1
I-Rod
D
1
"J" Bolt template
E
1
Vertical Pole
F
1
Hand Crank
G
4
"J" Bolt
H
4
36" Rebar
I
12
5/8" Hex Nut
J
8
5/8" Flat Washer
K
4
5/8" Lock Washer
Note: * refers to factory installed hardware; ** refers to hardware included with H-Frame
Inspect all contents prior to installation. Report any missing parts to dealer immediately.
Read all instructions before proceeding.
Young players are at risk when they slam dunk on popular lowered height basketball systems.
1.
Select the location for the concrete base footing using the Application chart to maximize hard playing
surface under and around the goal while minimizing interference with driveway traffic when unit is
adjusted at the lowest position. See Figure A.
2.
Dig a minimum 20" diameter hole 48" deep. Be sure to bell out the bottom 12" of the hole at least an
additional 4" in diameter. A larger diameter hole will always be better than one not big enough.
See Figure A.
Center of template/concrete foundation should be a minimum of 22" from any wall, fence, etc. to avoid
Date: 02/10/10
Rev: 8
BA79K
Do Not Mount Pole to Existing Concrete Surfaces!
See your dealer for information on Safety Nets.
interference with adjusting crank on the back side of the pole.
B.A.
P A R T S L I S T
Item
Qty
**L
1
M
2
N
2
O
1
P
4
Q
3
R
1
S
1
*T
1
U
4
Warning!
Warning!
Note:
N.J.C.
File: BA79k.mp; 79kinst.dwg
1
Description
5/8' x 8" Hex Bolt / 5/8" x 9" Hex Bolt
5/8" Lock Nut
5/8" x 6 1/2" Hex Bolt
1/2" x 4" Hex Bolt
1/2" Lock Nut
1/2" x 5" Hex Bolt
Spring Assist
Height Indicator Label
1/2"-13 x 2" Hex Bolt / 1/2" Lock Nut
Safety Cap
Customer Service
(800) 247-7668
Ref#: 920192

Advertisement

loading

Summary of Contents for Bison BA79K

  • Page 1 Note: Center of template/concrete foundation should be a minimum of 22" from any wall, fence, etc. to avoid interference with adjusting crank on the back side of the pole. Date: 02/10/10 Rev: 8 B.A. N.J.C. File: BA79k.mp; 79kinst.dwg Ref#: 920192...
  • Page 2 Thread a 5/8" Hex Nut (I) on to each "J" Bolt (G) leaving at least 2 1/2" of threads exposed above the 5/8” Hex Nuts (I) Place each "J" Bolt (G) through the holes in the "J" Bolt Template (D) and thread a second 5/8"...
  • Page 3 Clean excess concrete from edge of hole and level the concrete from the edge of the "J” Bolt Template (D). Clean excess concrete from both threads and nuts. Double check the position and levelness of "J" Bolt Template (D). Allow footing to cure for seven (7) days. Remove the upper 5/8"...
  • Page 4 Installation Tip! Pivot points located at the ends of (B) and (C) must not be overtightened! If unit squeaks during height adjustment the bolts are too tight. Grease pivot points occasionally for smooth adjustment. * Factory installed on Spring Assist FIGURE C FIGURE C * * I n c lu d e d in H - F ra m e H a rd w a r e...
