Icom IC-F1610 Service Manual page 23

[MAIN UNIT]
REF ORDER
NO. NO.
C27 4030011770 S.CERAMIC
C28 4030006860 S.CERAMIC
C29 4030006850 S.CERAMIC
C30 4030007060 S.CERAMIC
C31 4030009520 S.CERAMIC
C32 4030008560 S.CERAMIC
C33 4030011770 S.CERAMIC
C34 4030009520 S.CERAMIC
C35 4030009530 S.CERAMIC
C36 4030011770 S.CERAMIC
C37 4030008560 S.CERAMIC
C39 4030006860 S.CERAMIC
C40 4030006980 S.CERAMIC
C41 4030007030 S.CERAMIC
C42 4030007090 S.CERAMIC
C43 4030006860 S.CERAMIC
C44 4030006860 S.CERAMIC
C45 4030006860 S.CERAMIC
C46 4030006860 S.CERAMIC
C47 4030009550 S.CERAMIC
C48 4550002890 S.TANTALUM
C49 4030006900 S.CERAMIC
C50 4030006860 S.CERAMIC
C51 4030007110 S.CERAMIC
C52 4030007140 S.CERAMIC
C53 4030006860 S.CERAMIC
C54 4030007090 S.CERAMIC
C55 4030006860 S.CERAMIC
C56 4030006860 S.CERAMIC
C57 4030011600 S.CERAMIC
C58 4030011600 S.CERAMIC
C59 4030007110 S.CERAMIC
C60 4030012600 S.CERAMIC
C61 4550002890 S.TANTALUM
C62 4030007150 S.CERAMIC
C63 4030007150 S.CERAMIC
C64 4030006860 S.CERAMIC
C65 4030006860 S.CERAMIC
C66 4030006860 S.CERAMIC
C67 4030008920 S.CERAMIC
C68 4030008920 S.CERAMIC
C69 4030008920 S.CERAMIC
C70 4030008920 S.CERAMIC
C71 4030008920 S.CERAMIC
C72 4550002890 S.TANTALUM
C73 4030011600 S.CERAMIC
C74 4030011600 S.CERAMIC
C75 4550000460 S.TANTALUM
C83 4030011600 S.CERAMIC
C84 4550002890 S.TANTALUM
C85 4030008630 S.CERAMIC
C86 4030011600 S.CERAMIC
C87 4550002890 S.TANTALUM
C90 4550006250 S.TANTALUM
C91 4030006870 S.CERAMIC
C92 4030011600 S.CERAMIC
C93 4510005290 S.ELECTROLYTIC
C94 4510006260 S.ELECTROLYTIC
C95 4030011600 S.CERAMIC
C97 4030006860 S.CERAMIC
C98 4550002890 S.TANTALUM
C100 4030010240 S.CERAMIC
C101 4030006900 S.CERAMIC
C102 4030006900 S.CERAMIC
C103 4030006900 S.CERAMIC
C104 4550002890 S.TANTALUM
C105 4030006850 S.CERAMIC
C106 4030006860 S.CERAMIC
C107 4550003170 S.TANTALUM
C108 4030006860 S.CERAMIC
C112 4550003220 S.TANTALUM
C115 4510004510 ELECTROLYTIC
C116 4030006850 S.CERAMIC
C117 4030006900 S.CERAMIC
C118 4030006860 S.CERAMIC
C119 4510005750 S.ELECTROLYTIC
C121 4030006860 S.CERAMIC
C122 4030006860 S.CERAMIC
C123 4030007090 S.CERAMIC
C124 4510005750 S.ELECTROLYTIC
C125 4030007090 S.CERAMIC
C126 4030007020 S.CERAMIC
DESCRIPTION
C1608 CH 1H 060B-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 471K-T-A
C1608 CH 1H 270J-T-A
C1608 CH 1H 020B-T-A
C1608 CH 1H 300J-T-A
C1608 CH 1H 060B-T-A
C1608 CH 1H 020B-T-A
C1608 CH 1H 030B-T-A
C1608 CH 1H 060B-T-A
C1608 CH 1H 300J-T-A
C1608 JB 1H 102K-T-A
C1608 CH 1H 070D-T-A
C1608 CH 1H 150J-T-A
C1608 CH 1H 470J-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 CH 1H 2R5B-T-A
TESVA 1A 225M1-8L
C1608 JB 1E 103K-T-A
C1608 JB 1H 102K-T-A
C1608 CH 1H 680J-T-A
C1608 CH 1H 121J-T-A
C1608 JB 1H 102K-T-A
C1608 CH 1H 470J-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 CH 1H 680J-T-A
C2012 JB 1A 105M-T-A
TESVA 1A 225M1-8L
C1608 CH 1H 151J-T-A
C1608 CH 1H 151J-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1C 473K-T-A
C1608 JB 1C 473K-T-A
C1608 JB 1C 473K-T-A
C1608 JB 1C 473K-T-A
C1608 JB 1C 473K-T-A
TESVA 1A 225M1-8L
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
TESVA 1C 105M1-8L
C1608 JB 1C 104KT-N
TESVA 1A 225M1-8L
C1608 JF 1C 104Z-T-A
C1608 JB 1C 104KT-N
TESVA 1A 225M1-8L
TEMSVA 1A 106M-8L
C1608 JB 1H 222K-T-A
C1608 JB 1C 104KT-N
ECEV1EA221P
ECEV1AA471UP
C1608 JB 1C 104KT-N
C1608 JB 1H 102K-T-A
TESVA 1A 225M1-8L
C1608 JB 1H 391K-T-A
C1608 JB 1E 103K-T-A
C1608 JB 1E 103K-T-A
C1608 JB 1E 103K-T-A
TESVA 1A 225M1-8L
C1608 JB 1H 471K-T-A
C1608 JB 1H 102K-T-A
TEMSVA 1D 155M-8L
C1608 JB 1H 102K-T-A
TEMSVA 1E 105M-8L
25 MV 470 HC
C1608 JB 1H 471K-T-A
C1608 JB 1E 103K-T-A
C1608 JB 1H 102K-T-A
ECEV1EA220SP
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 CH 1H 470J-T-A
ECEV1EA220SP
C1608 CH 1H 470J-T-A
C1608 CH 1H 120J-T-A
[MAIN UNIT]
REF ORDER
NO. NO.
C127 4030007060 S.CERAMIC
C128 4030007020 S.CERAMIC
C129 4030007070 S.CERAMIC
C130 4030006860 S.CERAMIC
C131 4030006860 S.CERAMIC
C132 4030007050 S.CERAMIC
C133 4030006860 S.CERAMIC
C134 4030006860 S.CERAMIC
C135 4030006850 S.CERAMIC
C136 4030006850 S.CERAMIC
C137 4030006860 S.CERAMIC
C138 4030007030 S.CERAMIC
C139 4030006860 S.CERAMIC
C140 4030006860 S.CERAMIC
C141 4030007010 S.CERAMIC
C142 4030006860 S.CERAMIC
C143 4030007060 S.CERAMIC
C144 4030007060 S.CERAMIC
C145 4030006850 S.CERAMIC
C146 4030007060 S.CERAMIC
C147 4030006860 S.CERAMIC
C148 4030006860 S.CERAMIC
C149 4030007040 S.CERAMIC
C150 4030007010 S.CERAMIC
C151 4030007010 S.CERAMIC
C152 4030006850 S.CERAMIC
C153 4030006860 S.CERAMIC
C154 4550006250 S.TANTALUM
C155 4030006860 S.CERAMIC
C156 4030007090 S.CERAMIC
C157 4030006860 S.CERAMIC
C158 4030009500 S.CERAMIC
C159 4030006860 S.CERAMIC
C160 4030006860 S.CERAMIC
C161 4030007090 S.CERAMIC
C162 4030006860 S.CERAMIC
C163 4030009500 S.CERAMIC
C164 4030006860 S.CERAMIC
C165 4030007010 S.CERAMIC
C166 4030007010 S.CERAMIC
C167 4030007090 S.CERAMIC
C168 4030007070 S.CERAMIC
C169 4030006860 S.CERAMIC
C170 4030009650 S.CERAMIC
C171 4030007000 S.CERAMIC
C172 4030007010 S.CERAMIC
C173 4030007110 S.CERAMIC
C174 4030008180 S.CERAMIC
C176 4030007070 S.CERAMIC
C177 4030006850 S.CERAMIC
C178 4030006850 S.CERAMIC
C179 4550000550 S.TANTALUM
C181 4550003220 S.TANTALUM
C182 4510004650 S.ELECTROLYTIC
C183 4030006860 S.CERAMIC
C184 4030006860 S.CERAMIC
C185 4550002890 S.TANTALUM
C186 4030006860 S.CERAMIC
C187 4510004630 S.ELECTROLYTIC
C191 4030006860 S.CERAMIC
C197 4550006250 S.TANTALUM
C200 4550002890 S.TANTALUM
C201 4030008630 S.CERAMIC
C202 4030006870 S.CERAMIC
C203 4030011600 S.CERAMIC
C204 4550003220 S.TANTALUM
C205 4030004760 S.CERAMIC
C206 4510005290 S.ELECTROLYTIC
C207 4510004630 S.ELECTROLYTIC
C208 4550000460 S.TANTALUM
C209 4550005980 S.TANTALUM
C210 4550000460 S.TANTALUM
C211 4550000460 S.TANTALUM
C212 4030006860 S.CERAMIC
C214 4550006250 S.TANTALUM
C216 4030007050 S.CERAMIC
C217 4030006980 S.CERAMIC
C218 4030012600 S.CERAMIC
C224 4030008920 S.CERAMIC
C225 4030011330 S.CERAMIC
C226 4550003220 S.TANTALUM
C228 4030009880 S.CERAMIC
6 - 6
DESCRIPTION
C1608 CH 1H 270J-T-A
C1608 CH 1H 120J-T-A
C1608 CH 1H 330J-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 CH 1H 220J-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 471K-T-A
C1608 JB 1H 471K-T-A
C1608 JB 1H 102K-T-A
C1608 CH 1H 150J-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 CH 1H 100D-T-A
C1608 JB 1H 102K-T-A
C1608 CH 1H 270J-T-A
C1608 CH 1H 270J-T-A
C1608 JB 1H 471K-T-A
C1608 CH 1H 270J-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 CH 1H 180J-T-A
C1608 CH 1H 100D-T-A
C1608 CH 1H 100D-T-A
C1608 JB 1H 471K-T-A
C1608 JB 1H 102K-T-A
TEMSVA 1A 106M-8L
C1608 JB 1H 102K-T-A
C1608 CH 1H 470J-T-A
C1608 JB 1H 102K-T-A
C1608 CH 1H 0R5B-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 CH 1H 470J-T-A
C1608 JB 1H 102K-T-A
C1608 CH 1H 0R5B-T-A
C1608 JB 1H 102K-T-A
C1608 CH 1H 100D-T-A
C1608 CH 1H 100D-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 330J-T-A
C1608 JB 1H 102K-T-A
C1608 CH 1H 240J-T-A
C1608 CH 1H 090D-T-A
C1608 CH 1H 100D-T-A
C1608 CH 1H 680J-T-A
C1608 UJ 1H 030C-T-A
C1608 CH 1H 330J-T-A
C1608 JB 1H 471K-T-A
C1608 JB 1H 471K-T-A
TESVA 1V 224M1-8L
TEMSVA 1E 105M-8L
ECEV1EA4R7SR
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
TESVA 1A 225M1-8L
C1608 JB 1H 102K-T-A
ECEV1CA100SR
C1608 JB 1H 102K-T-A
TEMSVA 1A 106M-8L
TESVA 1A 225M1-8L
C1608 JF 1C 104Z-T-A
C1608 JB 1H 222K-T-A
C1608 JB 1C 104KT-N
TEMSVA 1E 105M-8L
C2012 JF 1E 104Z-T-A
ECEV1EA221P
ECEV1CA100SR
TESVA 1C 105M1-8L
TEMSVA 1A 475M-8L
TESVA 1C 105M1-8L
TESVA 1C 105M1-8L
C1608 JB 1H 102K-T-A
TEMSVA 1A 106M-8L
C1608 CH 1H 220J-T-A
C1608 CH 1H 070D-T-A
C2012 JB 1A 105M-T-A
C1608 JB 1C 473K-T-A
C1608 CH 1H 391J-T-A
TEMSVA 1E 105M-8L
C1608 JB 1H 682K-T-A
S.=Surface mount
