Window Type
MAW
Frequency: 60Hz
Capacity: 5000 ~ 15000BTU/h
Warning notices: Before using
this product, please read this
manual carefully and keep it
for future reference.
The design and specifications
are subject to change without
prior notice for product
improvement. Consult with
your dealer or the manufacturer
for details.
version A - 12 - 2018
version A - 09 - 2018
USER MANUAL
MAW05M1BWT
MAW05R1BWT
MAW06R1BWT
MAW08R1BWT
MAW10R1BWT
MAW12R1BWT
MAW15R1BWT
www.midea.com
en
Advertisement
Table of Contents
Related Manuals for Midea MAW Series
Summary of Contents for Midea MAW Series
-
Page 1: User Manual
The design and specifications MAW05R1BWT are subject to change without MAW06R1BWT prior notice for product MAW08R1BWT improvement. Consult with MAW10R1BWT your dealer or the manufacturer for details. MAW12R1BWT MAW15R1BWT version A - 12 - 2018 version A - 09 - 2018 www.midea.com... - Page 2 Owner’s Manual Safety Precautions ..................3 Operating Instructions ................. 8 Installation Instructions ................19 Care and Cleaning ..................20 Troubleshooting Tips .................. 24 Remote Control Instructions ..............27 and Return Policy ... Warranty ..............34 Read This Manual Inside you’ll find many helpful hints on how to use and maintain your air conditioner properly.
-
Page 3: Safety Precautions
Safety Precautions To prevent injury to the user or other people and property damage, the instructions shown here must be followed. Incorrect operation due to ignoring of instructions may cause harm or damage. The level of risk is shown by the following indications. This symbol indicates the possibility of death or serious injury. - Page 4 WARNING • Do not damage or use an alternate power cord. It may cause fire and electric shock. If the power cord is damaged, it must be replaced by the manufacturer or an authorized service center or a similarly qualified person in order to avoid a hazard. •...
- Page 5 CAUTION • Do not use for any purpose other than room comfort. Do not use this air conditioner to preserve precision devices, food, pets, plants, and art objects. It may cause deterioration. • Turn off the main power switch if the unit is not to be used for an extended time. •...
- Page 6 NOTE WARNING - Electrical Information The complete electrical rating of The power supply cord with this air conditioner contains a current your new room air conditioner is detection device designed to reduce stated on the serial plate. Refer to the rating when checking the electrical the risk of fire.
-
Page 7: Operation Of Current Device
WARNING - Prevent Accidents To reduce the risk of fire, electrical shock, or injury to persons when using your air conditioner, follow basic precautions, including the following: • Be sure the electrical service is adequate for the model you have chosen. This information can be found on the serial plate, which is located on the side of the cabinet and behind the grille. -
Page 8: Operating Instructions
Operating Instructions Normal Sounds MAW05M1 High Pitched Chatter Trickling Sound Sound of Rushing Air In front of the unit, you may hear the sound of during normal rushing air being moved by the fan. Gurgle/Hiss Vibration Gurgling or hissing Unit may vibrate and noises may be heard due to refrigerant evaporator during... - Page 9 Operating Instructions Normal Sounds MAW15R1 High Pitched Chatter Sound of Rushing Air Pinging or Switching In front of the unit, you may hear the sound of rushing air being during normal moved by the fan. Gurgle/Hiss Vibration Gurgling or hissing Unit may vibrate and noises may be heard due to refrigerant...
-
Page 10: Air Conditioner Operation
Air Conditioner Operation WARNING To reduce the risk of fire, electrical shock, personal injury or property, read the SAFETY PRECAUTIONS before operating this appliance. NOTE The cooling mode has an automatic 3 minutes time delayed start if the unit is turned off and on quickly. - Page 11 Air Conditioner Features - MAW05M1 NOTE The controls featured in this manual are representative of many available models. Your model’s features and appearance may vary slightly. THERMOSTAT The thermostat is used to set the desired room temperature when the unit is being operated in the COOL MODE.
- Page 12 Air Conditioner Features - MAW05R1 ELECTRONIC CONTROL OPERATING INSTRUCTIONS Before you begin, thoroughly familiarize yourself with the control panel as shown below and all its functions, then follow the symbol for the functions you desire. The unit can be controlled by the unit control alone or with the remote controller. DISPLAYS TO TURN UNIT ON OR OFF: TEMPERATURE...
- Page 13 SLEEP FEATURE: TO SELECT THE OPERATING MODE: Press Sleep button to initiate the To choose operating mode, press sleep mode. In this mode the selected Mode button. Each time you press the temperature will increase by 2°F/1 button the unit cycles through the modes, (or 2)°C 30 minutes after the mode Auto, Cool, Dry, and Fan.
- Page 14 TIMER: AUTO START/STOP FEATURE: Displays: • When the unit is on or off, first press Displays the Timer button. The TIMER ON indicator light illuminates indicating the Auto Start program has initiated. • When the time of TIMER ON is Shows the set temperature in “°C”...
-
Page 15: Key Pad Features
Air Conditioner Features - MAW06R1 to MWA12R1 NOTES • The relative humidity of room should be less than 80%. If the unit is used in a condition with a relative humidity over 80%, there will be condensed water on the surface of the unit. - Page 16 Auto Mode Remote Check Timer Selector Display Signal Speed Filter Receptor Energy Temp/Timer Power Temp/Timer Sleep Saver Control Button Control Mode (UP/DOWN) Button Operating on FAN mode: • Use this function only when cooling is not Press or hold either left ( ) or right ( desired, such as for room air circulation button until the desired temperature is...
- Page 17 at which time the compressor turns back revert back to display the previous on and Cooling Starts. temperature setting or room temperature when the unit is on. (when the unit is off, (SLEEP) Button there is no display.) In this mode the selected temperature will •...
-
Page 18: Additional Information
Additional Information Now that you understand the operating procedure, here are more features in your control that you should become familiar with. • The Cool circuit has an automatic 3 minute time delayed start if the unit is turned off and on quickly. This prevents overheating of the compressor and possible circuit breaker tripping. -
Page 19: Installation Instructions
Installation Instructions Your air conditioner is designed to install WARNING - Before You Begin in standard double hung windows with opening widths of 23 to 36 inches (584mm Read these instructions completely and to 914mm) (See Fig. D). carefully. • IMPORTANT - Save these Fig. - Page 20 NOTE Save carton and these Installation Instructions for future reference. The carton is the best way to store unit during winter, or when not in use. 1. PREPARE THE WINDOW Lower sash must open sufficiently to allow a clear vertical opening (see dimension H in Table 1).
- Page 21 C: Align the hole in the top rail with those in the top of the unit as shown in Fig. F. D: Secure the top rail to the unit with the 3/8” (9.5mm) screws as shown in Fig. G. Fig.C Fig .B NOTE For safety reasons, all...
- Page 22 2. While keeping a firm grip on the air Measure from the cabinet edge conditioner, carefully place the unit into the window opening so the bottom of H:About ” to ” the air conditioner frame is against the for 5K) window sill (Fig.
- Page 23 MAW05M MAW05R1 to MAW12R1 B2: For Vinyl-Clad windows: Drive 1/2” (12.7 mm) Fig. 8B Fig. 8C locking screws through the frame lock and into the window sash (Fig. 8B). NOTE: Before driving the screws, use a drill to Fi 8 drill 5 holes through the holes in the frame lock and frame extensions...
-
Page 24: Care And Cleaning
Care and Cleaning CAUTION Clean your air conditioner occasionally to keep it looking new. Be sure to unplug the unit before cleaning to prevent shock or fire hazards. Air Filter Cleaning The air filter should be checked at least once a month to see if cleaning is necessary. Trapped particles in the filter can build up and cause an accumulation of frost on the cooling coils. -
Page 25: Troubleshooting Tips
Troubleshooting Tips Before calling for service, review this list. It may save you time and expense. This list includes common occurrences that are not the result of defective workmanship or materials in this appliance. Problem Solution Wall plug disconnected. Push plug firmly into wall outlet. House fuse blown or circuit breaker tripped. - Page 26 Problem Solution Air movement sound. This is normal. If too loud, set to a slower FAN setting. Noise when unit is cooling Window vibration - poor installation. Refer to installation instructions or check with installer. Water dripping Improper installation. Tilt air conditioner slightly to the outside to INSIDE when allow water drainage.
-
Page 27: Remote Control Instructions
Remote Control Instructions Handling the Remote Controller LOCATION OF THE REMOTE CONTROLLER Use the remote controller within a distance of 16.4 ft (5 meters) from the air conditioner, pointing it towards the receiver. Reception is confirmed by a beep. CAUTION •... -
Page 28: Remote Control Specifications
Remote Control Specifications Model RG15B1/E Rated Voltage 3.0V (Lithium battery CR2025) Lowest Voltage of CPU Emitting Signal 2.4 V Signal Receiving Range 16.4 ft (5 m) Environment -5 °C ~ 60 °C (23°F ~ 140°F) NOTES • Button design is based on typical model and may vary slightly from the actual one you purchased. -
Page 29: Function Buttons
Function Buttons ON/OFF Button Operation starts when this button is pressed and stops when the button is pressed again. MODE Button NOTE: If the unit Press this button to has ENERGY SAVER select the desired function, it will initiate operation mode. automatically the Energy Saver function TEMP UP Button... - Page 30 How to Use the Buttons AUTO OPERATION Ensure the unit is plugged in and power is available. Press the ON/OFF button to start the air conditioner. 2. Press the MODE button to select Auto. 3. Press the TEMP UP (+)/DOWN (-) button to set the desired temperature.
- Page 31 DEHUMIDIFYING OPERATION Ensure the unit is plugged in and power is available. Press the ON/OFF button to start the air conditioner. 2. Press the MODE button to select Dry. 3. Press the TEMP UP (+)/DOWN (-) button to set the desired temperature. NOTES In the Dehumidifying mode, you cannot adjust the fan speed, as it is controlled automatically.
- Page 32 COMBINED TIMER (Setting both ON and OFF timers simultaneously) AUTO STOP >AUTO START (On > Stop > Start operation) This feature is useful when you want to stop the air conditioner after you go to bed, and start it again in the morning when you wake up or when you return home.
- Page 33 ENERGY SAVER OPERATION In this mode, the fan will continue to run for 3 minutes after the compressor shuts off. The fan then cycles on for 2 minutes at 10 minute intervals until the room temperature is above the set temperature, at which time the compressor turns back on and cooling resumes.
- Page 34 Operating Instructions. 2) Damages caused by services performed by persons other than authorized Midea costumer service; or external causes such as abuse, misuse, inadequate power supply or acts of God.
