Viking 22TB-IP Quick Start Manual

VIKING
QUICK START GUIDE
See Product Manual for complete installation and programming instructions.
1.0 Out-of-Box
1.1 Verify that you have received all of the parts listed
1.2 Download the product manual
Scan the QR code to
open and download
the product manual
1.3 Download and install the programming software
1. Go to www.vikingelectronics.com and enter 22TB-IP in the search box
2. Click 22TB-IP in the search results
3. Scroll down the page to Downloads, click IP Programming Software
4. Install the programming software by saving or opening the file and then clicking on
setup Viking IP Programming.exe
5. Follow the prompts on your screen to complete software installation

2.0 Power Source

Select PoE Switch or PoE Injector that meets the following requirements:
1. IEEE 802.3af / 802.3at / 802.3bu compliant
2. Capable of providing at least 13 Watts (class 0 or class 3)
Note: CAT5e (or higher) cable recommended
Electronics, Inc.
X 1
22TB-IP Speaker
- OR -
22TB-IP
SIP Multicast Talk-Back
Speaker
December 18, 2018
X 8
1. Go to www.vikingelectronics.com and
enter 22TB-IP in the search box
2. Click 22TB-IP in the search results
3. Click Product Manual to open and
download the PDF
Gel-Filled Butt Connectors
