Viking 40-IP Quick Start Manual

VIKING
QUICK START GUIDE
See Product Manual for complete installation and programming instructions.
1.0 Out-of-Box
1.1 Verify that you have received all of the parts listed
1.2 Download the product manual
Scan the QR code to
open and download
the product manual
1.3 Download and install the programming software
1. Go to www.vikingelectronics.com and enter 40-IP in the search box
2. Click 40-IP in the search results
3. Scroll down the page to Downloads, click IP Programming Software
4. Install the programming software by saving or opening the file and then clicking on
setup Viking IP Programming.exe
5. Follow the prompts on your screen to complete software installation

2.0 Power Source

Select PoE Switch or PoE Injector that meets the following requirements:
1. IEEE 802.3af / 802.3at / 802.3bu compliant
2. Capable of providing at least 13 Watts (class 0 or class 3)
Note: CAT5e (or higher) cable recommended
3.0 Network Port Settings
• Make sure the port is not in trunk mode
• Make sure port is capable of 100mbps full duplex
• Disable Spanning Tree Protocol (STP) or enable Portfast
Electronics, Inc.
40-IP Speaker
1
Qty:
1. Go to www.vikingelectronics.com and
- OR -
2. Click 40-IP in the search results
3. Click Product Manual to open and
40-IP
SIP Multicast Speaker
January 17, 2019
enter 40-IP in the search box
download the PDF
4-position terminal block
1
Qty:
