ABB ACH 500 Series Programming Manual page 107

Parameter
30 PROTECTION/INFORMAT
30.1 FAULT FUNCTION
30.1.1 SERIAL FAULT FUNC
30.1.2 AI <MIN FUNCTION
30.1.3 MOT TEMP FLT FUNC
30.1.4 MOTOR THERM TIME
30.1.5 MOTOR LOAD CURVE
30.1.6 ZERO SPEED LOAD
30.1.7 BREAK POINT
30.1.8 STALL FUNCTION
30.1.9 STALL CURRENT
30.1.10 STALL TIME/FREQ
30.1.11 UNDERLOAD FUNC
30.1.12 UNDERLOAD TIME
30.1.13 UNDERLOAD CURVE
30.2 AUTOMATIC RESET
30.2.1 NUMBER OF RESETS
30.2.2 TIME WINDOW
30.2.3 TIME BETW. RESET
ATTEMPTS
30.2.4 OVERVOLTAGE
30.2.5 UNDERVOLTAGE
30.2.6 OVERCURRENT
30.2.7 AI SIGNAL <MIN
ACH 500 Programming Manual
Alternative Settings
STOP; PRE SPEED7
NO; WARNING; FAULT; PRE SPEED7; LAST SPEED
NO; WARNING; FAULT
300s – 10000s
50% – 150%
40% – MOTOR LOAD CURVE
1 Hz – 500 Hz
NO; WARNING; FAULT
0 – 1.5 x I
N
10s/15 Hz; 20s/25 Hz; 30s/35 Hz
NO; WARNING FAULT
0 – 600s
1 – 5
0 – 5
1s – 180s
0s – 120s
NO; YES
NO; YES
NO; YES
NO; YES
Appendix A – Complete Parameter Settings
Custom
Setting
A-7
