2.4 LEDs & Button
YELLOW LED ON : Device is powered.
RED LED ON
GREEN LED ON : VoIP data is sent to the PC LAN cable.
BLUE LED ON
The button has two functions:
1. Press short to toggle between Recording and Not-recording;
RED LED on or off.
2. Press long (5 secs) to toggle between USB and LAN mode;
BLUE LED or

2.5 Software installation

You just have done the hardware installation of your CR-VoIP and we
continue with the software installation. The CR-VoIP should be powered.
Now place the CD in your computer and the software installation starts.
If the installation does not start automatically, then locate the file
'CRVoIPInstall.exe' on the CD and start it by double-clicking.
Follow the instructions on the screen:
•
Select your preferred language for the installation.
•
Confirm the location where the software will be installed.
•
Specify a location for the database files.
•
Select whether you want a desktop icon for the application.
Note1:
Software installation is only possible when the CR-VoIP unit is connected
to a USB port on the same PC.
Note2:
A separate installation of the WinPcap driver may be needed and is
started automatically, depending on the absence of this low-level
network interface driver.
Call Recorder VoIP II Manual EN v2.3
: Recording call data is enabled.
: VoIP data is sent to the PC USB cable (default).
GREEN LED on.
© 2017-2018 Vidicode 7
