Life GE UNI R Instructions For Installation, Use And Maintenance Manual

Control unit for two-leaf gates
Hide thumbs
Table of Contents

Advertisement

Quick Links

GE UNI R
CENTRALE DI COMANDO PER CANCELLI A DUE ANTE.
CONTROL UNIT FOR TWO-LEAF GATES.
CENTRALE DE COMMANDE POUR PORTAILS À 2 BATTANTS.
UNIDAD DE CONTROL PARA CANCELAS DE DOS HOJAS.
ISTRUZIONI E AVVERTENZE PER L`INSTALLAZIONE, L`USO E LA MANUTENZIONE.
INSTRUCTIONS AND WARNINGS FOR INSTALLATION, USE AND MAINTENANCE.
INSTRUCTIONS ET CONSEILS POUR L'INSTALLATION, L'UTILISATION ET L'ENTRETIEN.
INSTRUCCIONES Y ADVERTENCIAS PARA LA INSTALACIÓN, EL USO Y EL MANTENIMIENTO.
VERSIONE 04/2007

Advertisement

Table of Contents
loading

Related Manuals for Life GE UNI R

Summary of Contents for Life GE UNI R

  • Page 1 GE UNI R CENTRALE DI COMANDO PER CANCELLI A DUE ANTE. CONTROL UNIT FOR TWO-LEAF GATES. CENTRALE DE COMMANDE POUR PORTAILS À 2 BATTANTS. UNIDAD DE CONTROL PARA CANCELAS DE DOS HOJAS. ISTRUZIONI E AVVERTENZE PER L`INSTALLAZIONE, L`USO E LA MANUTENZIONE.
  • Page 2 Tab. 2: Descrizione contenuto scatola centralina GE UNI R. Tab. 2: Description of the content of a GE UNI R control unit pack. Tab. 2: Description contenu boîtier centrale GE UNI R. Tab. 2: Descripción del contenido de la caja del cuadro de control GE UNI R.
  • Page 3 GE UNI R GE UNI R AERIAL RG58-50ohm COMMANDS COMMON N.C. STOP N.O. OPEN N.O. CLOSE N.O. STEP N.C. PHOTO1 N.C. PHOTO 12 Vac 15VA ELECTRIC LOCK 24 Vac 3W max INDICATOR LIGHT OUTPUT 24 Vac mA max MOTOR2 OPEN...
  • Page 4 Istruzione di montaggio GEBOX. GEBOX assembly instructions Instructions de montage GEBOX Instrucciones de montaje GEBOX.
  • Page 5 RICAMBI. SPARE PARTS RECHANGE RECAMBIOS 1AB0060000 5RI0700000 5RI0690000 3CE1350000 ����� 1AH00101 3CL18200...
  • Page 6 Address: Via I Maggio, 37 - 31043 FONTANELLE (TV) Italia Numero Verde Telephone: Telephone: + 39 0422 809 254 800-046826 Telefax: Telefax: + 39 0422 809 250 http www.homelife.it e-mail: info@homelife.it...

  • Page 7: Table Of Contents

    CONTROL UNIT FOR TWO-LEAF GATES GE UNI R Instructions and warnings for installation, use and maintenance MANUAL DESTINED FOR USE BY PROFESSIONAL FITTERS ONLY Installation may only be performed by professional fi tters INDEX INSTALLATION OF AUTOMATIONS WITH STOP 3.3.2 Pre-fl...
  • Page 8 INSTALLATION OF AUTOMATIONS WITH STOP PLATES PHASE 1 a) Adjust the opening (A) and closure (B) stop switches or check the quality of the application’s mechanical plates. 45° b) Position the leafs at 45°. LOCKING UNLOCKING PHASE 2 Switch on the system’s power supply and check that the two red LEDs fl...
  • Page 9 PHASE 4 CARD INITIALISATION a) Switch off power supply. � � b) Simultaneously press and hold down and switch on the power supply to the system to light the third LED. � � � � � � � � � � � � c) Release keys , the two red LEDs will now fl...
  • Page 10 PHASE 6.1 IDENTIFICATION OF STAGGERING AND OPENING STOP PLATE (a) � � � � � � a) Give the step command (A) and release; the leaf (1) will open. When it reaches the point at which one also wishes to open leaf (2) (opening staggering) give the step command (A) and release: leaf (2) will open.
  • Page 11 ERGO: ADJUSTING THE OPENING AND CLOSURE MECHANICAL STOP PLATES CLOSURE: Adjust screw (A) abutting on the lever (B). OPENING: Adjust the retainer plate (D) abutting on the lever (B). OPTIMO: ADJUSTING THE OPENING AND CLOSURE MECHANICAL STOP PLATES Adjust the position of the (1) CLOSURE and (2) OPENING mechanical plates.
  • Page 12 INSTALLATION OF AUTOMATIONS WITH ELECTRIC STOP SWITCHES PHASE 1 a) Release the operator. b) Adjust the opening (A) and closure (B) stop plates. c) Position the leafs at 45° 45° d) Relock the operator. LOCKING UNLOCKING PHASE 2 Switch on the system’s power supply and check that the two red LEDs fl...
  • Page 13 PHASE 4 CARD INITIALISATION a) Switch off power supply. � � � � � � � � � � � � � � � � � � � � b) Simultaneously press and hold down and switch on the power supply to the system to light the second LED. �...
  • Page 14 PHASE 6 IDENTIFICATION OF STAGGERING AND OPENING STOP PLATE a) Give the step command (A) and release; the leaf (1) will open. When it reaches the point at which one also wishes to open leaf (2) (opening staggering) give the step command (A) and release: leaf (2) will open.

  • Page 15: Setting Up The Electric System And Connection

    WIRING AND CONNECTIONS • Before commencing wiring and connection work, read the SAFETY INSTRUCTIONS AND WARNINGS and INSTALLATION INSTRUCTIONS AND WARNINGS Chaps. • All wiring and connection operations must be carried out with the control unit disconnected from the electricity supply (and from the buf fer battery if present);...

  • Page 16: Control Unit Connections

    Control unit connections Fitters must make the connections of the 230 Vac 50 Hz electricity supply, the motors and the various automation devices. Connections between the control unit and the transformer have already been performed by the Manufacturer. • Once the connections to the control unit have been made, the Fitter must use bands to join adjacent wires into groups of 2, 3 or 4 in order to prevent them coming away from the terminal board: bands must be attached as close as possible to the terminals, no more than 10mm away, taking care not to damage wire insulation.

  • Page 17: Indicator Leds

    24 - 25 COURTESY LIGHT: 230 Vdc 40W max. output for connecting a courtesy light that switches on at the start of each movement (opening or closure) and is characterised by an adjustable on time. FLASHING OR COURTESY LIGHT POWER SUPPLY COMMON. 230Vac 50Hz POWER SUPPLY, fusable input L2.

  • Page 18: Starting Up

    STARTING UP Description of the keyboard The keyboard on the control unit makes it possible to set all the functions necessary for a safe and controlled functioning of the automation. • It is constituted by a membrane keyboard divided by a central column of keys, (from ) into two vertical areas: the right-hand keyboard (black/blue) and and the left-hand keyboard ( grey/yellow).

  • Page 19: Radio Control Identifi Cation

    Radio control identifi cation The control unit is fi tted with a built-in radio receiver with a 1000 code memory and 2 channels with a 433.92 MHz frequency with LIFE Rolling Code and Auto code encoding. 2.2.1 STEP command identifi cation...

  • Page 20: Resetting All Identifi Ed Radio Controls

    2.2.4 Resetting all identifi ed radio controls 1) Press on the control unit twice, the two right LEDs and the two left LEDs will fl ash alternately whilst the SPLENDOR fl ashing light emits a triple fl ash. 2) Simultaneously press , check the alternate fl...

  • Page 21: Initialisation

    All the operations performed by the operator and gate during travel recognition are the Fitter’s responsibility. ATTENTION: LIFE cards are multipurpose and may be used for several applications; therefore, on activation they require the identifi cation of the type of automation that they will serve.
  • Page 22 ATTENTION If the gate does not move or struggles to move, it is necessary to raise the force value when the gate is immobile: 1) Press followed by FORCE 2) Press to increase the basic force values: the LEDs will light. 3) Press to exit.
  • Page 23 OPTIMO: ADJUSTING THE OPENING AND CLOSURE MECHANICAL STOP PLATES Adjust the position of the (1) CLOSURE and (2) OPENING mechanical plates. 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2.3.2 Operators with electric stop switches: direction, travel and speed identifi...

  • Page 24: Card Initialisation

    ADJUSTMENTS 3.1.1 Card initialisation All the values previously stored on the card are erased and the automation is defi ned. OPERATORS WITHOUT ELECTRIC STOP SWITCHES a) Switch off power voltage. b) Simultaneously press and hold down switch � � � � the power supply back on.

  • Page 25: Resetting The Travel

    3.1.3 Resetting the travel The travel values and function modes are erased; the previously set function values remain. a) Switch off power voltage. b) Press and hold down and simultaneously switch the � � � � � � � � � � power supply back on.
  • Page 26 3.2.3 2-step automatic Automatic closure is enabled. In this mode, by pressing the ‘step’ key on the remote control the gate changes its motion according to the sequence 1 – OPEN 2 CLOSE; for example, if the gate is opening and one selects the step command on the remote control, the gate stops and starts to close; conversely, if the gate is closed, when the step command is given it opens.

  • Page 27: Blackout

    Functions 3.3.1 Blackout The RG UNI R card reacts differently to temporary power failure depending on whether the leaf is open, closed or in an intermediate position: Blackout NOT ACTIVATED: • Leaf closed: the operator reverts to normal operation. • Leaf open: after receiving two consecutive commands from the user the operator reverts to normal operation.

  • Page 28: Photo 1

    3.3.5 PHOTO 1 This function makes it possible to set for the inputs to the terminals 6 - 7 and 6 – 11 one of the following functions: PHOTO, PHOTO 1, PHOTO 2, STOP AND PAUSE. Press followed by PHOTO 1: if green LED (DX) is lit: programming outputs 6-7.

  • Page 29: Force

    3.3.8 Force The force function regulates the thrust and therefore the speed of the operator. Force is adjusted using the FORCE Press followed by FORCE The force value is set by pressing LEDS ON LEDS ON FORCE VALUE MINIMUM � � � � � �...

  • Page 30: Deceleration In Opening And Closure

    3.3.11 Deceleration in opening and closure. These functions regulate the distance travelled by the gate in deceleration in the fi nal stretches of opening and closure. To set DECELERATION IN CLOSURE press followed by To set DECELERATION IN OPENING press followed by The various distances are set by pressing LEDS ON...

  • Page 31: Fuses

    Fuses 3.4.1 Frontal fuses The frontal fuse is the fuse on the primary 230 volt power supply, and provides protection against the overload on the auto-transformer, external light circuits and operator. Technical features: miniature fuse 5x20 T3,15A, IEC 60127 or EN 60127 certifi ed. If, despite being powered, the automation does not work, it is necessary to check the operator control unit’s frontal fuse.

  • Page 32: Troubleshooting

    GENERAL INFORMATION It is strictly forbidden to copy or reproduce this instruction manual without written permission to do so and subsequent verifi cation by LIFE home integration. Translation into other languages of all or part of the manual is strictly forbidden without previous written authorisation from and subsequent verifi cation by LIFE home integration. All rights on this document are reserved.

  • Page 33: Information On The Manufacturer

    INFORMATION ON THE MANUFACTURER LIFE home integration is the manufacturer of the GE UNI R control unit (referred to for short as “control unit”) and the owner of all rights concerning this document. The Manufacturer’s information as required GE UNI R control unit (referred to for short as “control unit”) and the owner of all rights concerning this document. The Manufacturer’s information as required...

  • Page 34: Safety Instructions And Warnings

    TESTING AND TRIAL RUN • The testing and trial run must be performed by a COMPETENT PERSON supervised and aided by a PROFESSIONAL FITTER. It is the responsibility of the person who tests and sets up the automation (of which the control unit is a part) to perform the checks required in accordance with the risks existing and to check conformity with the relevant legislation and standards, in particular with EN standard 12445, which governs the methods for performing trials on gate automations and EN standard 12453 that specifi...

  • Page 35: General

    LIFE home integration Via 1 Maggio, 37 31043 FONTANELLE (TV) – Italy declares that the following product: GE UNI R control unit satisfi es the essential requisites established in the following directives: • Low voltage directive 73/23/EEC and subsequent amendments, •...
