- Page 1 SPLIT TYPE ROOM AIR CONDITIONER For split Wall Mounted Series R410a NEW ERP Model type for S# 9000BTU 12000BTU 18000BTU 24000BTU 2013...
- Page 2 ¡ ¢ £ ¤ ¥ ¢ ¦ § ¨ ¦ ¤ © ¦ § ¥ ¤ ¥ ¥ ¤ ¡...
- Page 3 ¡ ¢ £ ¤ ¥ ¢ ¦ § ¨ ¦ ¤ © ¦ § ¥ ¤ ¥ ¥ ¤ ¡...
- Page 4 ¡ ¢ £ ¤ ¥ ¢ ¦ § ¨ ¦ ¤ © ¦ § ¥ ¤ ¥ ¥ ¤ ¡...
- Page 5 ¡ ¢ £ ¤ ¥ ¢ ¦ § ¨ ¦ ¤ © ¦ § ¥ ¤ ¥ ¥ ¤ ¡ "...
- Page 6 &...
- Page 7 ¡ ¢ £ ¤ ¥ ¢ ¦ § ¨ ¦ ¤ © ¦ § ¥ ¤ ¥ ¥ ¤ ¡...
- Page 8 ¡ ¢ £ ¤ ¥ ¢ ¦ § ¨ ¦ ¤ © ¦ § ¥ ¤ ¥ ¥ ¤ ¡...
- Page 9 ¡ ¢ £ ¤ ¥ ¢ ¦ § ¨ ¦ ¤ © ¦ § ¥ ¤ ¥ ¥ ¤ ¡ €...
- Page 10 Technical Manual of AUX Room Air Comditioner SPLIT TYPE WALL MOUNTED AIR-CONDITIONER INSTALLATION INSTRUCTIONS...
- Page 11 Technical Manual of AUX Room Air Comditioner Convenient to adopt measures to reduce noises.
- Page 12 Technical Manual of AUX Room Air Comditioner Outdoor Unit Size of Shape (mm) 600 250 490 760 260 540 800 300 690(590) 902 322 795 900 330 860...
- Page 13 Technical Manual of AUX Room Air Comditioner...
- Page 14 Technical Manual of AUX Room Air Comditioner...
- Page 15 Technical Manual of AUX Room Air Comditioner Note: please refer the following table when you connect the pipes. A d d e d r e f r i g e r a n t Standard pipe length(m) Max pipe length(m) Max installation fall(m) quantity per meter(g)
- Page 16 Technical Manual of AUX Room Air Comditioner Unscrew the screw, take off the control panel cover from the unit. Connect the cable to their terminals according to their number. The grounded wire connection: 1.loosen the grounded screw of electrical shelf. 2.Connect the grounded wire with the grounded screw then setscrew in the mark formerly.
- Page 17 Technical Manual of AUX Room Air Comditioner Make sure whether the outlet air temperature subtract from inlet sgives more than 10...
-
Page 18: Safety Precautions
Technical Manual of AUX Room Air Conditioner Safety Precautions Incorrect operation due to ignoring instruction will cause harm or damage. The seriousness is classified by the following indications WARNING This symbol indicates the possibility of death or serious injury. CAUTION This symbol indicates the possibility of injury or damage to properties only. - Page 19 Technical Manual of AUX Room Air Conditioner...
- Page 20 Technical Manual of AUX Room Air Conditioner...
- Page 21 Technical Manual of AUX Room Air Conditioner...
- Page 22 Technical Manual of AUX Room Air Conditioner...
-
Page 23: Care And Maintenance
Technical Manual of AUX Room Air Conditioner Care and Maintenance Cleaning Cleaning the indoor unit 1.Turn off the air-conditioner and remove the electrical plug from the outlet. 2.Wipe the indoor unit with dry cloth or wet cloth which is dipped by cold water. Note : Don t use water above 45 to wash the panel, or it could cause deformation or depigment. - Page 24 Technical Manual of AUX Room Air Conditioner Troubleshooting Phenomenon Is the remote controller out of effective distance to the indoor unit? Remote controller is not available Is the battery exhausted? Are there any obstructions between the controller and the signal receptor? Is the setting temperature suitable? Is the air inlet or outlet obstructed? Cooling (Heating)efficiency is not...
- Page 25 Technical Manual of AUX Room Air Conditioner Installation Guide Guide for customer The installation must be done by professional referring to the Installation instructions . The wiring must be done by qualified electrician according to the electrical safety requirements. The customer should have a qualified power supply which coincides with the tag of air conditioner, the normal voltage should be in the range of 90-110% of its rated voltage.
-
Page 26: The Closing State Of Remote Controller
Technical Manual of AUX Room Air Conditioner The closing state of remote controller: Mode display Auto Cool Dry Heat Emission display Fan speed display Anion function display Temperature display Power display Feeling display Up/Down wind display Sleep display Timer/Clock display Timer On/Off display... - Page 27 Technical Manual of AUX Room Air Conditioner button This button can set room temperature. Press it once ,the temperature increases 1 .Press it continu- ously, the temperature increases at the speed of 4 This function is invalid when the appliance at the Fan and Auto mode.
- Page 28 Technical Manual of AUX Room Air Conditioner The opening state of remote controller: HEALTH SLEEP FEELING POWER TIMER/CLOCK The air condition have some assistant function as follow. The 'HEALTH' and 'FEELING' button function are optional, please check whether your air conditioner has those functions before you use.
- Page 29 Technical Manual of AUX Room Air Conditioner button This button can adjust clock time and the timer time. Adjusting clock time and timer time Press it once ,the time increases one minute. Press it for 1 to 3 seconds, time display will increase at the speed of 2min/s. For 3 to 5 seconds, it will increase at the speed of 10min/s.
- Page 30 Technical Manual of AUX Room Air Conditioner TIMER/CLOCK button Setting the ON/OFF timer time When remote controller is at the on/off state, Press this button , the LCD flickers the symbol. Press the button to set the timer time. After finishing it, press this button again in 10 seconds to affirm.
- Page 31 Technical Manual of AUX Room Air Conditioner 3.Press the button, you can set the temperature range from 16 to 32 4.Press the FAN button, you can select fan speed. You can select fan speed from Quiet High You can select fan speed from High Auto 2.Press the...
- Page 32 Technical Manual of AUX Room Air Conditioner 2.Press the FAN button, you can select fan speed . You can select fan speed from Quiet You can select fan speed from High 2.Press the FAN button, you can select fan speed . You can select fan speed from Quiet High...
- Page 33 Technical Manual of AUX Room Air Conditioner 2.Adjust time through pressing the button. 3.Press the TIMER/CLOCK button again, the Timer OFF setting is finished. Notice: It is general sketch map of outline for remote controller. Please refer to the real one you buy for specific location of buttons, and if the relevant keys are not indicated, it means absence of corresponding function.
- Page 34 ¡ ¢ £ ¤ ¥ ¢ ¦ § ¨ ¦ ¤ © ¦ § ¥ ¤ ¥ ¥ ¤ ¡ ’ • ‘ “ ” ˆ ˆ ‰ “ ™ ˆ ƒ „ … † ‡ ƒ – — ˜...
- Page 35 ¡ ¢ £ ¤ ¥ ¢ ¦ § ¨ ¦ ¤ © ¦ § ¥ ¤ ¥ ¥ ¤ ¡ ...
