Manual de servicio
Split Acondicionador de Aire
DSA-095L
Modelo:
DSA-125L,125P
DSA-185L,185P
DSA-245L,245P
Aviso:
En este manual,algunas partes pueden cambiar sin previo aviso en la lista
de partes si usted necesita la ultima informacion por favor dirigirse a
PPL(Parts Price List)Centro de informacion de
servicio(http.//svc.dwe.co.kr).
http;//svc.dwe.co.kr
Dic 2005
