Manual Supplement
00809-0200-4108, Rev AB
December 2018
Rosemount
Safety Instrumented Systems (SIS) Requirements
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 1
SIS operation and maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 3
Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 4
1.0
Overview
The safety-critical output of the Rosemount 2090 Pressure Transmitter is provided through a two-wire,
4–20 mA signal representing pressure. The Rosemount 2090 safety certified pressure transmitter is
certified to: Low Demand; Type B.
SIL 2 for random integrity @ HFT=0
SIL 3 for random integrity @ HFT=1
SIL 3 for systematic integrity
1.1
Rosemount 2090 safety certified identification
All Rosemount 2090 transmitters must be identified as safety certified before installing into SIS systems.
To identify a safety certified Rosemount 2090:
1. Check Namur Software Revision located on the metal device tag. "SW _._._".
2. Verify that option code QT is included in the transmitter model code.
1.2
Installation in SIS applications
Installations are to be performed by qualified personnel. No special installation is required in addition to
the standard installation practices outlined in this document. Always ensure a proper seal by installing
the electronics housing cover(s) so that metal contacts metal.
Environmental and operational limits are available in "Specifications and Reference Data," in the
Reference
The loop should be designed so the terminal voltage does not drop below 10.5 Vdc when the transmitter
output is set to 23 mA.
™
2090 Pressure Transmitter
Namur Software Revision Number
(1)
SW
1.0.x –1.4.x
1. NAMUR Software Revision: Located on the metal device tag
Manual.
Advertisement
Related Manuals for Emerson Rosemount 2090
Summary of Contents for Emerson Rosemount 2090
- Page 1 Rosemount 2090 safety certified identification All Rosemount 2090 transmitters must be identified as safety certified before installing into SIS systems. To identify a safety certified Rosemount 2090: 1. Check Namur Software Revision located on the metal device tag. “SW _._._”.
-
Page 2: Configuring In Sis Applications
Manual Supplement Rosemount 2090 Pressure Transmitter 00809-0200-4108, Rev AB December 2018 Position the security switch to the ( ) position to prevent accidental or deliberate change of configuration data during normal operation. Configuring in SIS applications Use any HART capable configuration tool to communicate with and verify configuration of the Rosemount 2090. -
Page 3: Sis Operation And Maintenance
Manual Supplement Rosemount 2090 Pressure Transmitter 00809-0200-4108, Rev AB December 2018 SIS operation and maintenance Proof test The following proof tests are recommended. In the event that an error is found in the safety and functionality, proof test results and corrective actions taken can be documented at Emerson.com/Rose-... -
Page 4: Product Repair
Emerson.com/Rose- mount/Safety-Products. Inspection Product repair The Rosemount 2090 is not repairable and must be replaced in case of failure. All failures detected by the transmitter diagnostics or by the proof-test must be reported. Feedback can be submitted electronically at Emerson.com/Rosemount/SafetyWeb-Apps/Report-A-Failure. -
Page 5: Failure Rate Data
Manual Supplement Rosemount 2090 Pressure Transmitter 00809-0200-4108, Rev AB December 2018 Failure rate data The FMEDA report includes failure rates and common cause Beta factor estimates. The report is available Emerson.com/Rosemount/Safety-Products. Failure values Transmitter response time: Reference Appendix A: specifications and reference data in the Reference Manual. - Page 6 Jebel Ali Free Zone - South 2 Emerson Terms and Conditions of Sale are available upon request. Dubai, United Arab Emirates The Emerson logo is a trademark and service mark of Emerson Electric Co. +971 4 8118100 Rosemount and Rosemount logotype are trademarks of Emerson.
