  • Page 1 OWNER ’S MA NUAL B21 CAB...
  • Page 3 Owner’s Manual Ockelbo B21 CAB ® Issue 2018-08-29 AB Ockelbo Aluminiumbåtar, Magasinsgatan 7, SE-903 27 Umeå, Sweden info@ockelboboats.se www.ockelboboats.se...

  • Page 5: Table Of Contents

    T A B L E O F C O N T E N T S WELCOME ABOARD! ............... 1 1. INTRODUCTION ................3 1.1 A ’ ..................3 BOUT THIS OWNER S MANUAL 1.2 G ....................4 ENERAL DESCRIPTION 1.3 C (CIN) ..............
  • Page 6 3. GENERAL INFORMATION ............22 3.1 D ................22 IMENSIONS AND SPECIFICATIONS 3.2 D ..................... 23 ESIGN CATEGORIES 3.3 E ....................24 NGINE REQUIREMENTS 3.4 V ................25 ESSEL STABILITY AND BUOYANCY 3.5 L ......................25 OAD CAPACITY 3.6 P ........
  • Page 7 5. ELECTRIC SYSTEM ..............47 5.1 G ....................47 ENERAL DESCRIPTION 5.2 B ..................47 ATTERIES AND CHARGING 5.3 M ..................48 AIN SWITCH FOR BATTERY 5.4 E ....................48 LECTRICAL DIAGRAMS 5.5 F ..........................48 USES 6. MAINTENANCE ................50 6.1 F ........................

  • Page 9: Welcome Aboard

    We stand behind every boat we build with pride of craftsmanship and always strive to deliver the best boats available in our market segment. Ockelbo boats are always built to be extremely durable and have absolute top-class handling characteristics. An Ockelbo is built to be driven.
  • Page 10 WELCOME ABOARD!__PAGE 2...

  • Page 11: Introduction

    Please read the manual carefully and familiarise yourself with your boat before using it. At Ockelbo, we believe that you shall be free to choose a suitable outboard engine for your specific needs. For this reason, the boat manual cannot be very detailed on engine related topics.

  • Page 12: General Description

    wind with a danger of unusual waves and gusts. These are dangerous conditions that necessitate a skilled and fit crew and a well-maintained boat. If your craft is equipped with a life raft, study its instructions carefully. The boat must be equipped with the appropriate safety equipment (life vests, safety harnesses, etc.) as required for the boat type and the weather conditions.

  • Page 13: Explanation Of Safety Labels

    1.4 E XPLANATION OF SAFETY LABELS Mounted at key locations throughout your boat and duplicated in this manual are labels that advise the owner/operator of imperative safety precautions to follow when operating or servicing equipment. Study chapter 3.7 to learn their location. Learn to recognize the degree of precaution and understand the explanations of safety prior to reading this manual.

  • Page 14: Warranty

    The code was added already at the factory and will enable them to access boat and owner details from a database. The SecurMark system requires a subscription, and Ockelbo pre-pays it for the first 12 months after registration of your ownership details. We encourage you to activate SecurMark and, after the first 12 months of free service, continue to subscribe.

  • Page 15: Operating The Boat

    2. OPERATING THE BOAT WARNING Read and make sure you understand the operation and safety topics of this owner’s manual before you operate the boat for the first time. 2.1 S AFETY ROUTINES BEFORE LEAVING SHORE Familiarize yourself with this owner’s manual. Always check the following items before leaving the shore: 2.1.1 Weather and forecast Consider the wind, waves and visibility.

  • Page 16: Safety Check Of The Boat

    regular charts onboard. There is always a risk for technical malfunction of electronic devices; therefore, regular charts are also important. 2.1.8 Safety check of the boat  Check that hatches are closed and watertight.  Ventilate the stern sofa storage where the battery is installed. This is to remove any battery gases.

  • Page 17: Man - Overboard Prevention And Recovery

    2.3 M OVERBOARD PREVENTION AND RECOVERY Refer chapter 3.6 for passenger and working areas of the boat. Other areas must not be occupied when underway due to the risk of falling, potentially into the water. If a person has fallen into the water in calm seas, the person can use the rescue ladder located on the port side of the transom (see chapter 7, figure 1 and position 23).

  • Page 18: Fire Port

    Ensure that the fire-fighting equipment is readily accessible when the boat is occupied. Inform the crew members and passengers about the location and operation of the fire-fighting equipment, the fire port, escape routes and the exits. Unlock any deck hatches to enable fire fighting inside storage areas and keep the fire port free.

  • Page 19: Refuelling

    of fire inside the bilge/ below the deck area, introduce the nozzle to the fire port opening and activate the extinguisher. Replace the fire port if worn or damaged. 1. Fire port 2.4.3 Refuelling Before you start to fill the engine fuel tank, turn off the engine and naturally any cigarettes or any other open flames like stoves, candles or lamps with flames.

  • Page 20: Starting The Boat

    Start the engine according to the Owner’s Manual for the outboard engine. If the engine does not start, or functions poorly, check for instructions in the manual. If unsuccessful, contact your engine dealer (in most cases it is your Ockelbo dealer). 2.5.2 After starting the engine Check the cooling water control beam, to ensure that the cooling system is working properly (visible just below the engine hood, well above water level).
  • Page 21  Be extra careful when running the engine in neutral, when moving at low speeds and with the tailwind, and when running with a high bow, as fumes can then easier accumulate in and around the boat.  Ensure that the cabin ventilation is sufficient. Keep the roof ventilators open when the boat is in use, even with the engine shut off.

  • Page 22: Leaving Shore

    2.5.4 Leaving shore The crew releases each mooring rope etc., as per your instructions. Make sure mooring ropes or other ropes does not tangle with the propeller. Ask crew to be seated as soon as possible after leaving the mooring position. For seating positions see chapter 3.6.
  • Page 23  Sharp turns, a too low bow or sideways waves at high speeds may be very dangerous due to the risk of fast changes of directions. It may cause passengers and the operator to shift and loose grip, potentially be hurt and/or lose control of the boat.

  • Page 24: Trim Of The Engine (Boat Pitch)

    2.6.1 Trim of the engine (boat pitch) The outboard engine has a built-in trim and tilt function. The trim adjusts the angle of the propeller versus the boat transom. See also chapter 4.6. 1. Trim Up 2. Neutral 3. Trim Down The engine trim is used to adjust the bow up or down (the so-called pitch) while the boat is under speed.

  • Page 25: Trim Of The Boat Roll (Transverse Movement)

    Trim when running at speeds above planing:  When the boat is running at speeds above planing, the trim also needs to be adjusted. As speed, direction, load, wind or wave condition changes, new adjustments may be needed.  Use the trim up, to lift the bow up slowly without change of throttle position. Follow the log to notice for how long the speed is increasing.
  • Page 26 Trim tabs are very useful, but it is important to understand their major impact on boat's sea properties. Incorrect use can seriously affect the boat's performance and driving characteristics, and cause an accident. Be careful and remember that these basic instructions are not a substitute for good seamanship and experience.

  • Page 27: Anchoring , Mooring And Towing

    2.7 A NCHORING MOORING AND TOWING Mooring, anchoring and towing require specific skills and good seamanship. Always ask for advice when needed. It is the owner's and operator's responsibility to ensure that mooring, towing and anchor ropes, anchor chains and anchors are appropriate for the vessel's intended use and in good condition.
  • Page 28 Moor your boat carefully, even in sheltered places, because weather conditions can change rapidly. Do not moor the boat with the stern facing the open sea, because high waves could flood the boat and sink it. Use loose fenders between the boat hull and any close objects such as other boats when there is a risk of contact.
  • Page 29 tow line on board and how it can be released fast in case of emergencies. Note that if a tow rope snaps under heavy load, it may cause damage to persons in its way, so take necessary pre-cautions. WARNING 1. Do not stop the boat by hand and don’t put your hand or foot between the boat and the quay, bank, or other boats.

  • Page 30: General Information

    2486 mm Weight, empty boat without engine, mLT 994 kg Weight for Trailering and Lifting (boat, engine, fuel, Ockelbo standard and optional equipment as per this 1439 kg manual, liquids), mT Weight Maximum (boat, engine, fuel, Ockelbo standard and optional equipment as per this manual, liquids,...

  • Page 31: Design Categories

    Note: All dimensions in mm. All boats are hand-made and therefore some minor deviations may occur. 3.2 D ESIGN CATEGORIES There are four design categories of boats based upon their ability to withstand wind and water conditions; this boat is designed in accordance with Category C. Category A –...

  • Page 32: Engine Requirements

    Ockelbo. The said label is located at the console, under the Capacity plate. Unless Ockelbo installs the engine, it is the responsibility of the party installing the engine to comply with all specifications, rules and regulations related to outboard engines.

  • Page 33: Vessel Stability And Buoyancy

    3.4 V ESSEL STABILITY AND BUOYANCY The following maximum load has been used for assessing the stability and buoyancy comprising: Manufacturer’s maximum recommended load per ISO 14946 2049 kg This assessment has been made assuming that Weight of crew (6 x 75 kg) 450 kg Luggage / cargo 60 kg...

  • Page 34: Passenger Locations And Embarking / Disembarking

    3.6 P ASSENGER LOCATIONS AND EMBARKING DISEMBARKING Ask passengers to be seated while the boat is moving, and to hold on to handrails both when seated and when embarking/disembarking. See the figure given below. Do not use the bow area (area in front of cabin) when operating the boat at higher speeds than 10 knots, or in high wave conditions.
  • Page 35 1. BLUE: Recommended step in/out areas 1. RED: Areas that can be used at mooring, anchoring and emergencies 2. BLUE: Areas that can be used at speeds up to 10 knots 3. GREEN: Areas that can be used at all speeds DANGER Surfaces are slippery when wet or dirty.

  • Page 36: Safety Label Locations

    WARNING Do not sit in the bow area (in front of consoles) when the boat is moving at speeds higher than 10 knots, or in conditions with high waves or risk of wakes from other boats. Sudden and heavy movements may cause injuries. 3.7 S AFETY LABEL LOCATIONS Mounted at key locations throughout your boat, and duplicated in this chapter, are labels...
  • Page 37 Location: Next to the fuel filling cap Meaning: No open flames in boat when fuelling. Inspect fuel system at least annually. Location: On the surface outside of the cabin walls, along hull edge. Meaning: No step area. This is not a gunwale intended for standing or walking. The surface is narrow and slippery.

  • Page 38: Thru Hull Locations

    Location: On the bow door and on roof hatches. Meaning: Do not have these open in speeds higher than indicated on the label, as they may close fast or be damaged which in turn may cause personal or material damages. NOTE Do not remove or obstruct any safety label.

  • Page 39: Trailering

    3.9 T RAILERING Ockelbo do not offer a specific boat trailer for this boat. Your dealer can recommend or sell you a suitable trailer. Before placing your boat onto any trailer (or other support), make sure that it is designed for your boat weight and its shape.

  • Page 40: Strong Points

    Soft material / clothes between fender & straps NOTE Tightening straps too hard across the boat fender may damage the fender. Be careful and use rags or other material between fender and straps/ropes. 3.10 S TRONG POINTS Cleats Your boat comes equipped with 4 cleats, two located at the bow and two located at the stern.

  • Page 41: Lifting Of The Boat

    The positions of the lift straps are shown in the figure. When lifting the boat with lift straps, Ockelbo recommends using a forklift or lifting frame to separate the straps from the upper hull and fender. The straps need to be vertical. There may be damages on both hull and fender if these recommendations are not followed and any warranty does not cover these.
  • Page 42 *All dimensions in mm Areas for positioning of lifting straps, to ensure good balance. DANGER Never stand below the boat when it is lifted. Use only the lifting procedure specified in this manual. Using the cleats, secure eye, bow eye, handrails or other parts of the boat for lifting is dangerous and cause severe injury or death.

  • Page 43: Systems & Components

    4. SYSTEMS & COMPONENTS NOTE This chapter is based on Ockelbo-listed standard and optional equipment. Any other equipment or systems added (custom-made boats, aftermarket products and so on) are not covered here. Furthermore, it does not include outboard engine and engine control instrument details.

  • Page 44: Fuel Tank

    4.1.1 Fuel tank The boat is equipped with an aluminium fuel tank with a capacity of 160 litres. As a precaution, all the capacity may not be useable due to trim and loading conditions, so consider keeping at a minimum 20% of reserve fuel in the tank. Fuel tanks with levels less than 20% capacity can cause engine stalling problems due to fuel starvation or by allowing sediment and dirt to enter the fuel supply lines.

  • Page 45: Steering System

    For any support you may need, please contact the company who installed this system (in most cases it is your Ockelbo dealer). Maintenance may include the check of oil levels at the servo, check for leaks and lubrication of open parts/joints.

  • Page 46: Navigation Lights

    2. 112.5⁰ Starboard lantern, green 3. 360⁰ Top/anchor lantern, white For complete instructions on maintenance, we refer to the separate OEM owner’s manual that was developed specifically for this equipment. It is provided with the Ockelbo document bag. 4.4 B...
  • Page 47 automatically by free float switch when water in the bilge reaches a predetermined level. You can also manually activate the electrical bilge pump at the console switch panel by pressing and holding the bilge pump button (see chapter 7, figure 3 and position 5). Push this button and hold it to operate the bilge pump.

  • Page 48: Garmin Plotter And Transducer

    For complete instructions on operation and maintenance, we refer to the separate OEM owner’s manual that was developed specifically for this equipment. It is provided with the Ockelbo document bag. 4.5 G ARMIN PLOTTER AND TRANSDUCER The boat comes as standard with a multi-function model Garmin GPSMap 722XS (as an option there is also the model 922XS).

  • Page 49: Lectrotab Trim System

    Due to the different possibilities to install and customize the displays, you need to study the engine and engine instrumentation manuals. They are to be provided by the Ockelbo dealer or other company who installed engine and instruments. Understanding the instruments ensures that you use the engine in the most optimal, economic and safe way.

  • Page 50: Swim Ladder / Mob Rescue Ladder

    For complete instructions on operation and maintenance, we refer to the separate OEM owner’s manual that was developed specifically for this equipment. It is provided with the Ockelbo document bag. 4.8 S WIM LADDER...

  • Page 51: Adjustable Suspension Chairs

    The module consists of a radar device that is mounted under the instrument panel and connected to the plotter, as well as a radar antenna mounted on the roof rack. Due to the radar's advanced technology, please refer to the OEM manual. Your Ockelbo dealer can also help you if necessary.

  • Page 52: Doors In The Cabin

    200mm of the exhaust outlet. For complete instructions on operation and maintenance, we refer to the separate OEM owner’s manual that was developed specifically for this equipment. It is provided with the Ockelbo document bag. 4.14 D OORS IN THE CABIN The cabin is equipped with 2 doors, towards bow and stern.

  • Page 53: Music System ( Optional )

    For complete instructions on operation and maintenance, please refer to the manufacturer's own user manual that has been developed specifically for this equipment. It is available in the Ockelbo bag that comes with the boat. 4.16 T ABLE FOR AFT DECK OPTIONAL A table is available as an option.

  • Page 54: Vhf Radio ( Optional )

    For complete instructions on operation and maintenance, we refer to the separate OEM owner’s manual that was developed specifically for this equipment. It is provided with the Ockelbo document bag. 4.19 E &...

  • Page 55: Electric System

    When you leave the boat for extended periods, always switch off the main power to avoid draining the batteries. Ockelbo has equipped the boat with spare circuits to allow for auxiliary equipment (aftermarket products) to be installed. They are labelled "spare" on the fuse panel. If you choose to use them, make sure they are labelled for easy identification, and make sure that the electrical installation is professionally done.

  • Page 56: Main Switch For Battery

    Electrical diagrams are included as printed attachments to this manual. They can also be obtained from your dealer or from Ockelbo if they are lost. These diagrams can be used for technical reference and professional service technicians. If you lack professional skills for this kind of electrical system, contact your local authorized Ockelbo dealer for help.
  • Page 57 CIRCUIT BREAKERS, PUSH TO RESET BATTERY MAIN SWITCH NAVIX Main circuit breakers with battery main switch Fuse locations: Extra melt fuses and cable connectors Main panel with circuit breakers and battery main switch 5. ELECTRIC SYSTEM__PAGE 49...

  • Page 58: Maintenance

    Specialists manufacture other parts such as engine and navigation systems. To ensure the best possible instructions, we sometimes refer to the specific OEM maintenance manuals. These are provided with the boat (please check the Ockelbo document bag). This applies to the following components (reference is given to the operations chapter in...

  • Page 59: Fuel System

    6.2.1 Aluminium treatment M-400 maintenance & principle Ockelbo boats have a patented surface treatment on all aluminium surfaces, called M- 400®. The treatment bonds to the aluminium and strengthens its already impressive...

  • Page 60: Hull Below Water, Antifouling Treatment

    It is very important to choose the correct type of primer and top coat, suitable for aluminium hulls and for your local conditions. If the boat was delivered with antifouling from the factory (optional), Ockelbo have used the following products:  Primer: International Intergard 563 (white) ...

  • Page 61: Anodes For Prevention Of Galvanic Corrosion

    One of the most important maintenance tasks when owning a boat is making sure you protect the hull and engine from electrolytic corrosion. This can otherwise quickly create serious damages. Ockelbo boats are therefore equipped with sacrificial anodes, made from zinc, which is designed to corrode instead of the boat and the engine. They are mounted at the bottom recess (see the figure given below).

  • Page 62: Component Maintenance

    WARNING Neglect to replace the boat zinc anodes in time can cause major damages to the boat hull and engine! CAUTION Do not apply any paint to zinc anodes, and ensure that the surface between the anodes and the hull is metal clean when replacing and inspecting the anodes. NOTE Your engine is likely also equipped with anodes that need to be maintained, see engine manual for further details.

  • Page 63: Fender List

    6.3.3 Fender list The fender list has a D-shape and is bolted to the hull. As a fender, it will eventually have physical contact with other boats, docks and so on. Such contact will result in scratches, small deformations and some friction marks. This is natural and could be left unattended as long as the fender is functional and well attached to the hull.

  • Page 64: Winter Storage / Spring Preparations

    6.4 W INTER STORAGE SPRING PREPARATIONS Preparing boats for winter storage are subject to your location. In cold climates, always have your boat hoisted in good time before the water freezes. This is an appropriate time to perform all yearly maintenance, repair and inspection procedures. Even if your boat is used around the year, a yearly maintenance period is recommended and shall follow the same routines as specified below except when marked with a *.

  • Page 65: Measures After Winter Storage

    To ensure the best possible performance, safety and lifetime of your boat, it is important only to use high-quality spare parts that are suitable and approved for your specific boat application. Failure to do so may jeopardize safety, lifetime and performance. Ockelbo offers parts through the dealer network.

  • Page 66: Figures

    7. FIGURES Figure 1: Layout and positions of components / functions. The manual refers to these numbers when applicable. 1. Securing eye 2. Bow eye 3. Bow cleats 4. Bow seat and storages 5. Hand rails 6. Drain outlets, bow deck 7.
  • Page 67 Figure 2: Principal layout instrument panel, with Evinrude engine. Variations may occur subject to choice of engine model. 1. Music system Fusion (option) 2. VHF radio Garmin (option) 3. Plotter Garmin (option) 4. Engine instrument (Evinrude) 5. Electrical circuit switches (wipers, lanterns, bilge pump, lights, AUX) 6.

  • Page 68: Attachments

    8. ATTACHMENTS List of attached documents/drawings, to be found in the Ockelbo document bag:  Electrical diagrams  Owner’s manuals for components (as referenced to in the Ockelbo owner’s manual)  Final Quality Approval  Authorized Installation Certificate  Declaration of Conformity of recreational craft ...
  • Page 70 AB Ockelbo Aluminiumbåtar reserverar sig mot tryckfel AB Ockelbo Aluminiumbåtar reserves the right for any och förbehåller sig rätten att göra ändringar. Båten som typographical errors and reserves the right to make visas är ibland extrautrustad och alla illustrationer är changes.
